KOBE Brand Range Hood
Model No.:
CH0130SQB (30'')
CH0136SQB (36'')
CH0142SQB (42'')
CH0148SQB (48'')
CH-101 SERIES – 18'' HEIGHT
INSTALLATION INSTRUCTIONS
AND OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CH0130SQB (30") and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KOBE CH0130SQB (30")

  • Page 1 KOBE Brand Range Hood Model No.: CH0130SQB (30'') CH0136SQB (36'') CH0142SQB (42'') CH0148SQB (48'') CH-101 SERIES – 18'' HEIGHT INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
  • Page 3: Table Of Contents

    - READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS...ERROR! BOOKMARK NOT DEFINED. COMPONENTS OF PACKAGE ... 3 INSTALLATION ... 4 UNDER THE CABINET INSTALLATION ...6 STAND ALONE INSTALLATION ...9 OPERATING INSTRUCTIONS ... 12 MAINTENANCE...ERROR! BOOKMARK NOT DEFINED. SPECIFICATIONS ... 16 MEASUREMENTS &...
  • Page 4: Important Safety Instructions

    KOBE RANG E HOO DS authorized agents. supervision of KOBE RANGE HOODS authorized agents will auto matically void the warranty. KOBE RANG E HOODS will not be held responsible for any da mages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood.
  • Page 5 What to Do In The Event Of a Range Top Grease Fire • SMOTHER FLAMES with a close fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
  • Page 6: Components Of Package

    Screw Package for Duct Cover - 1 Model No. CH0048DC-12 for 48” hood KOBE Duct Cover – 1 Screw Package for Duct Cover - 1 OR CONTACT KOBE RANGE HOODS AT (626) 350-1355. 3/16" X 3 /8 " (8 pc)
  • Page 7: Installation

    INSTALLATION PLEASE READ ENTIRE INSTRUCTION BEFORE PROCEEDING Calculation before Installation To calculate installation, please refer to Table 1. (All calculation in inches.) TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top to Hood Bottom (Recommended 27”...
  • Page 8 SAFETY WARNING HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF IT IS NECESSARY TO REMOVE ANY PARTS FOR INSTALLING, CLEANING OR SERVICING. NOTE: BE CAREFUL WHEN USING ELECTRICAL SCREWDRIVER, DAMAGE TO THE HOOD MAY OCCUR. Installation Table of Contents UNDER THE CABINET INSTALLATION...6 Preparation Before Installation ...6 Hood Installation ...6...
  • Page 9: Under The Cabinet Installation

    UNDER THE CABINET INSTALLATION Preparation Before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM OPENING. Decide the location of the venting pipe from the hood to • the outside. Refer to Figure 1. A straight, short vent run will allow the hood to •...
  • Page 10: Ductwork Installation

    Ductwork Installation 7. Use 8” aluminum or steel pipe (follow building codes in your area) to connect the ducting transition on the hood to the ductwork above. secure joints as shown in Figure 5. Wiring to Power Supply S A F E T Y W A R N I N G TO PREVENT THE RISK OF ELECTRICAL SHOCK OR INJURY, ALL RANGE HOODS SHOULD BE PROPERLY GROUNDED...
  • Page 11 15. Install heating lamps (not provided), 120 Volts 175 Watts max. each. 16. Turn power ON in control panel. Check all lights and fan operation. 17. Make sure to leave this manual for the homeowner Figure 8...
  • Page 12: Stand Alone Installation

    ***Follow these installations only if installing with an optional duct cover: Preparation Before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. Decide the location of the venting pipe from the • hood to the outside. Refer to Figure 9. A straight, short vent run will allow the hood to •...
  • Page 13: Wiring To Power Supply

    Align hood-mounting bracket to the two screws on the wall and hook hood into place. Tighten screws to secure hood to the wall. For safety purpose, extra knockout holes on the back of the hood are provided for a more secure installation.
  • Page 14: Duct Cover Installation

    Duct Cover Installation Use 8” aluminum or steel pipe (follow building codes in your area) to connect the ducting transition on the hood to the ductwork above. Use duct tape to seal and secure joints as shown in Figure 15. Slide the duct cover onto the hood. Use 3/16”...
  • Page 15: Operating Instructions

    OPERATING INSTRUCTIONS This KOBE hood is equipped with touch-sensor screen and features 3 minute delay shutoff, powerful centrifugal squirrel cage with baffle filters, bright 12-volt 20-watt halogen lights and heating lamp capability (heating lamps not included). The touch-sensor screen has Heat Lamp Control, Light Control, Speed Control (QuietMode™, Low, Medium and High), and Power Control.
  • Page 16 Turn Off After 3 Minute Delay Gently touch the symbol flashes and after 3 minutes sign lit. Speed Control: There are four speeds: QuietMode™, Low, Medium, and High. To activate the speed, touch • the control under the speed sign. For example, if turning on hood at low speed, gently touch symbol under the symbol under the speed control (if, for example, halogen lights are also on), touch the...
  • Page 17: Maintenance

    MAINTENANCE SAFETY WARNING NEVER PUT YOUR HAND INTO AREA HOUSING THE FAN WHILE THE FAN IS OPERATING. For optimal operation, clean range hood and all baffle/spacer/filter/oil tunnel/oil container regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. *** Regular care will help preserve the appearance of the hood.
  • Page 18 To Replace Light Bulb CAUTION: HALOGEN LIGHT UNIT MAY BE HOT! WAIT UNTIL UNIT IS COOL. 1. Make sure all controls are off, and range hood is unplugged. 2. Place a flat-head screwdriver between light cover and housing 3. Gently pull defective bulb straight out maximum.
  • Page 19: Specifications

    SPECIFICATIONS MODEL / SIZE DESIGN CONSUMPTION / AMPERE VOLTAGE NUMBER OF MOTORS FAN TYPE: CENTRIFUGAL EXHAUST CONTROLS HALOGEN LIGHTS HEATING LAMPS HOOD DIMENSION (W X D X H) OPTIONAL ACCESSORIES (W X D X H) HOOD WEIGHT (lbs) Blower Air Capacity (cfm)* Sone** *In House Test.
  • Page 20: Measurements & Diagrams

    MEASUREMENTS & DIAGRAMS Inch measurements converted from millimeter. Inch measurements are estimated. MODEL NO: CH0130SQB CH0136SQB CH0142SQB CH0148SQB - FOR UNDER THE CABI NET -...
  • Page 21 - FOR UNDER THE CABI NET – (Cont.)
  • Page 22 - FOR STAND ALONE (WITH OPTIONAL DUCT COVER) – MODEL NO: CH0130SQB CH0136SQB CH0142SQB CH0148SQB...
  • Page 23 - FOR STAND ALONE (WITH OPTIONAL DUCT COVER) – (Cont.)
  • Page 24 Hood-Mounting Bracket 1" (25.4) 1/4" (6.5) 6" (152) 7 - 1/2" (190.5) BAFFLE FILTER & STAINLESS STEEL SPACERS 30" HO O D 42" HO O D 36" HO O D 48" HO O D...
  • Page 25: Parts List

    PARTS LIST MODEL NO: CH0130SQB CH0136SQB CH0142SQB CH0148SQB BODY COMPONENTS Hood Casing Ducting Transition Screws (3/16” x 3/8”) Blower Assembly Field Wiring Box Cover Field Wiring Box Heat Lamp Socket Screws (3/16” x 3/8”) Heat Lamp Socket Box Oil Tunnel Heat Lamp Support Halogen Light Support Halogen Light...
  • Page 26 Optional Duct Cover (Sold Separately)
  • Page 27 Blower Assembly DESCRIPTION Screws (3/16” x 3/8”) Air Flow Grill Left Locknut Left Squirrel Cage Motor Right Squirrel Cage Right Locknut Air Chamber MODEL / SIZE PART NO. CH101-4.1 CH101-4.2 CH101-4.3 CH101-4.4 CH101-4.5 CH101-4.6 CH101-4.7 CH101-4.8...
  • Page 28 Electrical Assembly DESCRIPTION 21.1 Bolt 21.2 Electrical Box 21.3 Screws (3/16” x 3/8”) 21.4 Power Board 21.5 Electrical Box Cover 21.6 Setup Board 21.7 Screws (3/16” x 3/8”) 21.8 Capacitor 21.9 Transformer 21.10 Bolt Gasket 21.11 Screw Cap 21.12 Rubber Gasket 21.13 Screws (3/16”...
  • Page 29 Switch Assembly DESCRIPTION 20.1 Screen Support 20.2 Touch Screen 20.3 Switch Box 20.4 Switch Board 20.5 Switch Box Cover 20.6 Screws (1/8” x 1/2”) 20.1 20.2 MODEL / SIZE 20.3 20.4 20.5 PART NO. CH101-20.1 CH101-20.2 CH101-20.3 CH101-20.4 CH101-20.5 CH101-20.6 20.6...
  • Page 30: Circuit Diagram

    CIRCUIT DIAGRAM MODEL NO.: CH0130SQB CH0136SQB...
  • Page 31 MODEL NO.: CH0142SQB CH0148SQB...
  • Page 32: Disclaimer

    DISCLAIMER 1. CAREFULLY INSPECT ALL ITEMS FOR DAMAGES BEFORE ACCEPTING DELIVERY. NOTE ANY DAMAGES ON THE FREIGHT BILL OR EXPRESS RECEIPT. REQUEST NAME AND SIGNATURE OF THE CARRIER’S AGENT AND KEEP COPY TO SUPPORT YOUR CLAIM. Upon acceptance of items, owner assumes responsibility for its safe arrival. Damages should be reported to carrier and a claim filed.
  • Page 33: Warranty

    WARRANTY KOBE Range Hoods, Inc. warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the repair or replacement at its option and subject to the terms and conditions stated below, of any component part, which its examination shall disclose to be so defective.
  • Page 34: Consequential Damage

    Some states do not allow limitations on the duration of implied warranties. This warranty gives you specific legal rights, and may also have rights, which vary from state to state. For service contact: KOBE Range Hoods 10505 Valley Blvd. Suite 302 EI Monte, CA 91731 U.S.A...
  • Page 35: Product Registration

    KOBE Range Hoods Agent or KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection.
  • Page 36 KOBE Range Hoods 10505 Valley Blvd Suite # 302 El Monte, CA 91731 USA http://www.KOBERangeHoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country.
