- Page 1 KOBE Brand Range Hood Model No. CH0030SQB CH0036SQB CH0042SQB CH0048SQB CH-100 SERIES – 18” HEIGHT INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
-
Page 2: Table Of Contents
- READ AND SAVE THESE INSTRUCTIONS - CONTENTS Important Safety Instructions... 1 Components Of Package... 3 Installation... 4 Operating Instructions... 11 Maintenance ... 12 Specifications... 13 Measurements & Diagrams... 14 Parts List... 16 Circuit Diagram... 21 Disclaimer... 23 Warranty... 24 Product Registration... -
Page 3: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS wi ll not be held responsible for any damages to personal property or real estate or any bodil y injuries whether caused directly or indi rectly by the range hood. - Page 4 What to Do In The Event Of a Range Top Grease Fire SMOTHER FLAMES with a close fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 5: Components Of Package
OPTIONAL RECIRCULATING KIT ALSO AVAILABLE. FOR MORE INFORMATION, PLEASE CONTACT KOBE RANGE HOODS AT (626) 309-1356. ORIGINAL KIT (Sold Separately) Option of: Model No. CH0030DC-12 for 30” hood KOBE Duct Cover – 1 ... -
Page 6: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation Calculate the length of the installation, before installing the hood. (All calculation is measure in inches.) TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top to Hood Bottom (Recommended 27”... - Page 7 SA F E T Y W A R N IN G HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF IT IS NECESSARY TO REMOVE ANY PARTS FOR INSTALLING, CLEANING OR SERVICING. NOTE: BE CAREFUL WHEN USING ELECTRICAL SCREWDRIVER, DAMAGE TO THE HOOD MAY OCCUR.
-
Page 8: Under The Cabinet Installation
UNDER THE CABINET INSTALLATION Preparation before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. Decide the location of the venting pipe from the hood to the outside. Refer to Figure 1. A straight, short venting run will allow ... - Page 9 Ductwork Installation Use aluminum or steel pipe to connect the plastic exhaust on the hood to the ductwork above. Use duct tape to make all joints secure and air tight as shown on Figure 4. To convert ductwork to 7” round, attached 7”...
-
Page 10: Stand Alone Installation
STAND ALONE INSTALLATION ***This installation only applied with the purchase of an optional duct cover: Preparation before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. Decide the location of the venting pipe from the hood to the outside. - Page 11 Align hood-mounting bracket to the two screws on the wall and hook hood into place. Tighten screws to secure hood to the wall. For safety purposes, extra knockout holes on the back of the hood are provided. Knockout the holes. Remove the baffle filters and attach screws to the wall by accessing underneath the hood.
- Page 12 Slide the duct cover onto the hood. Attach screws from underneath the hood to the duct cover. Install Accessories Refer to Figure 15 Slide the baffle filter into the hood. Push the baffle filter upward. Slide forward. Pull downward.
-
Page 13: Operation Instructions
OPERATION INSTRUCTIONS This KOBE hood is equipped with four electronic controls with a 10-second standby startup & 30- second delay shutoff, powerful centrifugal squirrel cage with baffle filters, and bright 12-volt 20-watt halogen lights. The four electronic controls are Light Control, Speed Control A, Speed Control B and the Power Control (On/Off). -
Page 14: Maintenance
MAINTENANCE For the optimal level of operation, clean the range hood surface and baffles regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. *** Regular care will help preserve its fine appearance. 1. Use only mild soap or detergent solutions. Dry surfaces using soft cloth. 2. -
Page 15: Specifications
30-Second Delay Shutoff 12V 20W x 2 – 30”, 36” 12V 20W x 3 – 42”, 48” (CH0030SQB) 29-3/4” x 24” x 18” (CH0036SQB) 35-3/4” x 24” x 18” (CH0042SQB) 41-3/4” x 24” x 18” (CH0048SQB) 47-3/4” x 24” x 18”... -
Page 16: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS All measurements in ( ) are millimeters. All inch measurements are converted from millimeters. Inch measurements are estimated. MODEL NO.: CH0030SQB CH0036SQB CH0042SQB - FOR STAND ALONE (WITH OPTIONAL DUCT COVER) - MODEL NO.: CH0030SQB... - Page 17 ***Rear Knockout Holes ***Hood-Mounting Bracket...
-
Page 18: Parts List
PARTS LIST MODEL NO.: CH0030SQB CH0036SQB CH0042SQB CH0048SQB DESCRIPTION 7” Round Adapter 6” Round Plastic Exhaust Hood Casing Control Unit Control Board Halogen Light Unit (12V 20W Max.) Motor Lamp Socket Cover Lamp Socket Safety Screen Capacitor Panel Transformer (Light) - Page 19 ORIGINAL KIT DESCRIPTION Hood-Mounting Bracket Screw (3/16” x 3/8”) Duct Cover Screw (3/16” x 3/8”) RECIRCULATING KIT DESCRIPTION Hood-Mounting Bracket Screw (3/16” x 3/8”) T-Head Box Box Bracket Box Panel Left Right Screw (3/16” x 3/8”) Aluminum Pipe 6” Round Plastic Exhaust Recirculating Duct Cover Screw (3/16”...
- Page 20 MODEL NO.: CH0030SQB CH0036SQB...
- Page 21 MODEL NO.: CH0042SQB...
- Page 22 MODEL NO.: CH0048SQB...
-
Page 23: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: CH0030SQB CH0036SQB... - Page 24 MODEL NO.: CH0042SQB CH0048SQB...
-
Page 25: Disclaimer
DISCLAIMER 1. CAREFULLY INSPECT ALL ITEMS FOR DAMAGES BEFORE ACCEPTING DELIVERY. NOTE ANY DAMAGES ON THE FREIGHT BILL OR EXPRESS RECEIPT. REQUEST NAME AND SIGNATURE OF THE CARRIER’S AGENT AND KEEP COPY TO SUPPORT YOUR CLAIM. Upon acceptance of items, owner assumes responsibility for its safe arrival. Damages should be reported to carrier and a claim filed. -
Page 26: Operating Instructions
WARRANTY KOBE Range Hoods, Inc. warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the repair or replacement at its option and subject to the terms and conditions stated below, of any component part, which its examination shall disclose to be so defective. -
Page 27: Consequential Damage
Some states do not allow limitations on the duration of implied warranties. This warranty gives you specific legal rights, and may also have rights, which vary from state to state. SERVICE For service contact: KOBE Range Hoods, Inc. 4934 Walnut Grove Avenue Suite 202 San Gabriel, CA 91776 U.S.A... -
Page 28: Product Registration
KOBE Range Hoods Agent or KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection.
