Audio System X 100.2 Owner's Manual page 4

X
75.6
(channel 5 + 6)
LPF
switch
on/off
RCA INPUT
mode
4 CH / 6 CH
HEAD UNIT
X X
70.4 / . 75.6
HP
filter
1x o. 40x
HP
filter
LPF
switch
on/off
1x o. 20x
The x series amplifier offers RCA-Inputs, which are connected through cinch cables with the
preamplifier-outputs of the head unit.
With the aid of the variable high- and lowpassfilter and the gain-controller you are able to adjust the
amplifier on to your prefered taste of hearing, the circumstances of the vehicle and to the speakers.
Another special feature is the FSA (Front Stage Adjuster). Ths is a analog phase correction for the left
front channel. By adjusting the FSA volume you can set the sound and voices in front of you.
In this regard, AUDIO SYSTEM
specialized service center, dealer or a specialist.
Optional the x 75.6 und X 100.2 can be installed to a wire remote controller RTC, which allows you
to rule the amplifier in front of the car (only if the LPF is switched „ON").
.
RCA
Variable
phase-shift
Wired Remote
Control RTC
(optional)
FSA on/off
switch
(channel 1 - 4)
FSA on/off
FSA HI / LOW
switch
volume switch
RCA INPUT
mode
4 CH / 6 CH
recommends to adjust your amplifier through a
Germany
-4-
connection
HPF
LPF
switch switch
on/off on/off
FSA HEAD UNIT
volume
X
100.2
HI / LOW
switch
HEAD UNIT
