- Page 1 1 9 8 8 t h e s o u n d High-Performance Car- amplifier owner‘s manual C0-95.2 C0-65. 4 designed and engineered by audio system Germany...
- Page 2 features Congratulation on your purchase of your new c Series amlifier. IMPORTANT: Before installation your power amplifier, we recommend to read the owner´s manual carefully and to follow the instructions regarding connection and fitting exactly. ATTENTION: Pay attention to advices and instructions of the car manufacturer. Important: Your proof of purchase is evidence of warranty claim for repair or replacement.
-
Page 3: Power Connection
power connection CO-95.2 / co-65.4 1. Battery disconnection First disconnect the power supply of +12V FUSE the vehicle. This works out the best by removing the ground cable of the battery. 2. Ground connection Connect the GND (ground) connection of the amplifier with the car chassis. Keep this cable as short as possible (not longer than 50 cm) and use a to REMOTE Turn-on... -
Page 4: Rca Connection
Optional a wire remote controller RTC can be installed to adjust the output level. In this regard, AUDIO SYSTEM germany recommends to adjust your amplifier through a specialized service center, dealer or a specialist. -
Page 5: Speaker Connection
speaker connection co-95.2 1-Channel Bridged speaker impedance 4 ~ 8 Ohm 2-Channel Stereo speaker impedance 2 ~ 8 Ohm CH 1 CH 2 Tri-Mode speaker impedance 4 ~ 8 Ohm coil CH 1 CH 2... - Page 6 speaker connection co-65.4 2-Channel Mono CH 1 CH 2 speaker impedance 4 ~ 8 Ohm CH 3 CH 4 CH 3/4 mono CH 1/2 mono 4-Channel Stereo CH 1 CH 2 speaker impedance 2 ~ 8 Ohm CH 3 CH 4 CH 1 CH 3 CH 4...
-
Page 7: Troubleshooting
Trouble Shooting This power amplifier is featured with an efficient protection system to prevent any damages like over-heating, overvoltage, short-circuit and DC at the loudspeaker output. Occuring an error the protection-LED will light in red. In order to check the problem, first turn down all levels of the head unit, afterwards turn it off. -
Page 8: Specifications
THD@RMS Watts ------------------------------------------------------------ < 0,051% ---------------------------------------------------------------------- Channel Separation 75 dB ------------------------------------------------------------------ Fuse Rating 25 A x 2 ----------------------------------------------------------------------- Input Sensitivity 200 mV ~ 8 V (+/- 5%) Dimensions 280(L) x 47(H) x 171(W) mm designed and engineered by audio system Germany...
