To manage the ARP entries:
1. To move certain type of entries, select the type of entries to remove from the Remove
From Table menu. The choices listed specify the type of ARP Entry to be deleted:
• All Dynamic Entries
• All Dynamic and Gateway Entries
• Specific Dynamic / Gateway Entry. Selecting this allows you to specify the required
IP address.
• Specific Static Entry.
• None. Select if you do not want to delete any entry from the ARP Table.
2. If you select Specific Dynamic/Gateway Entry or Specific Static Entry in the Remove
from Table list, you can enter the IP address of an entry to remove from the ARP table.
3. Click Cancel to cancel the configuration on the screen and reset the data on the screen to
the latest value of the switch.
4. If you change any of the settings on the page, click Apply to send the updated configuration
to the switch.
The ARP Entry Statistic table displays the following information:
Field Description
Total Entry Count The total number of entries currently in the ARP table. The number includes both
dynamically learned entries and statically configured entries.
Peak Total The highest value reached by the Total Entry Count. This value is reset whenever the
Entries ARP table Cache Size configuration parameter is changed.
Active Static The total number of active ARP entries in the ARP table that were statically
Entries configured. After a static ARP entry is configured, it might not become active until
certain other routing configuration conditions are met.
Configured Static The total number of static ARP entries that are currently in the ARP table. This
Entries number includes static ARP entries that are not active.
Maximum Static The maximum number of static ARP entries that can be manually configured on in
Entries the ARP table
