  • Page 1 Smart Switch Series Software Manual NETGEAR, Inc. 4500 Great America Parkway Santa Clara, CA 95054 USA Phone 1-888-NETGEAR July 2005 July 2005...

  • Page 2: Statement Of Conditions

    Defective or damaged merchandise can be returned to your point-of-purchase representative. NETGEAR maintains a World Wide Web home page that you can access at the uniform resource locator (URL) http:// www.NETGEAR.com. A direct connection to the Internet and a Web browser such as Internet Explorer or Netscape are required.

  • Page 3: Table Of Contents

    System> Password Page ...3-4 Switch Menu ...3-4 Switch> Port Configuration Page ...3-4 Switch> Port Configuration: Set speed ...3-5 Switch> Port Configuration: Set flow control ...3-5 Switch> Statistics Page ...3-5 Switch> Statistics> Refresh ...3-6 Switch> Statistics> Clear Counter ...3-6 Switch> VLAN Page ...3-6 Switch>...
  • Page 4 Switch> VLAN> IEEE802.1Q Tag VLAN ...3-7 Switch> Trunking Page ...3-9 Switch> Monitor Page ...3-10 Switch> Advanced> Jumbo Frame ...3-10 Switch> Advanced> Spanning Tree Page ... 3-11 Switch> Advanced> SNMP ... 3-11 Firmware Menu ...3-12 Firmware> Configuration Backup Page ...3-12 Firmware> Factory Reset Page ...3-12 Logout ...3-13...

  • Page 5: About This Guide

    Smart Switch Series Switch software. It is intended to provide an understanding of the configuration options of Smart Switch Series Switch software. It is assumed that the reader has an understanding of the relevant switch platforms. It is also assumed that the reader has a basic knowledge of Ethernet and networking concepts.

  • Page 6: Typographical Conventions

    This manual is written for the Smart Switch Series Switch according to these specifications: Table 1-1. Manual Specifications Product Version Manual Publication Date Note: Product updates are available on the NETGEAR, Inc. Web site at http://www.netgear.com/support/main.asp. Smart Switch Series Switch July 2005 July 2005...

  • Page 7: Switch Management Overview

    Protocols Management Access Overview Your NETGEAR Smart Switch contains software for viewing, changing, and monitoring the way it works. This management software is not required for the switch to work. You can use the 10/ 100 Mbps ports and the built-in Gigabit ports without using the management software. However,...
  • Page 8 Web browser • Can be accessed from any location via the switch’s IP address • Password protected • Ideal for configuring the switch remotely • Compatible with Internet Explorer and Netscape Navigator Web browsers • Intuitive browser interface • Most visually appealing •...
  • Page 9 Smart Switch Series Software Manual Switch Management Overview July 2005...

  • Page 10: Getting Started

    Click Discover of the Smartwizard Discovery utility to find your switch. You should see a something similar to Figure 2-1. Select your switch by clicking on it. Then click on Web Access, as highlighted in Figure 2-2. Figure 3-1: Smartwizard Discovery Utility > Discover...
  • Page 11 Figure 3-2: Smartwizard Discovery > Web Access To manage your switch via your web browser, click Web Access. The main page below will display. The default password is password. Figure 3-3: Web Management main page Getting Started Smart Switch Series Software Manual...

  • Page 12: For A Network Without A Dhcp Server

    Enter your IP address, Gateway and Subnet. Then, type your password and click Set. Make sure your PC and your switch are in the same subnet. Note: You can always assign a Static IP address to your switch no matter if your network has a DHCP server or not.
  • Page 13 To manage your switch via your web browser, click Web Access. The main page below will display. The default password is password. Figure 3-5: Web Management main page Getting Started Smart Switch Series Software Manual July 2005...
  • Page 14 Smart Switch Series Software Manual Getting Started July 2005...

  • Page 15: Web-Based Management Interface

    Your NETGEAR Smart Switch series provides a built-in browser interface that lets you configure and manage it remotely using a standard Web browser such as Microsoft Internet Explorer or Netscape Navigator. This interface also allows for system monitoring of the switch. The help page will cover many of the basic functions and features of the switch and its web interface.

  • Page 16: System Menu

    • Password System> Switch Status Page The Switch Status page displays the port settings for both 10/100 Mbps and 10/100/1000 Mbps ports. To configure the ports, go to the Switch> Port Configuration page. • ID: The port number on the switch •...

  • Page 17: System> Ip Access List Page

    The default setting is all host IP addresses allowed. Note: Once this new IP access is enabled, you can only access the switch via this IP. Make sure that your new IP is the same of current PC.

  • Page 18: System> Password Page

    You can configure the status per port by clicking a port ID at the port setting menu. • ID: The port number on the switch. Click this number to configure the port. • Speed: Indicates the communication mode set for the port. The default setting for all ports is Auto-negotiation (Auto).

  • Page 19: Switch> Port Configuration: Set Speed

    • Click Apply to activate the new setting. Switch> Statistics Page The Statistics Table shows the statistics types for one port over time. • ID: The port number on the switch • Tx: Transmitted packet/s. • Rx: Received packet/s. Web-Based Management Interface...

  • Page 20: Switch> Statistics> Refresh

    Switch> VLAN Page A Virtual Local Area Network (VLAN) is a means to electronically separate ports on the same switch from a single broadcast domain into separate broadcast domains. By using VLAN, users can group by logical function instead of physical location.

  • Page 21: Switch> Vlan> Port-Based Vlan

    Member: Indicates which port/s belong to a VLAN group Switch> VLAN> Port-based VLAN Multiple port-based VLAN groups are supported on the switch, and any one port can belong to different VLAN groups. The number of supported port-based VLAN groups varies according to the switch model.

  • Page 22: Switch> Vlan> Ieee802.1Q Tag Vlan

    Smart Switch Series Software Manual Switch> VLAN> IEEE802.1Q Tag VLAN Depending on your model switch there are up to 64 static Tag VLAN groups supported on your switch. The VLAN tagging option is a standard set by the IEEE to facilitate the spanning of VLANs across multiple switches (Reference: Appendix A and IEEE Std 802.1Q-1998 Virtual...
  • Page 23 Click Apply. PVID Setting All untagged packets entering the switch will by default be tagged with the port’s Primary VLAN Identification (PVID). This screen allows you to specify the PVID for each port. Take VLAN 2 for example: ports 5, 6, 7, and 8 have been checked as tagged ports for this VLAN.

  • Page 24: Switch> Trunking Page

    A bank is a set of eight ports, such as ports 1 to 8, ports 9 to 16, ports 17 to 24, or port 25 and port 26, on the same switch unit. Up to four trunks can be operating at the same time.

  • Page 25: Switch> Monitor Page

    Ethernet frame size, so you will need to ensure that all of your networking gear can support these non-standard Jumbo Frames to prevent them from being dropped. By clicking 'Help' button on this page, you can see the maximum frame size the switch can carry. Web-Based Management Interface...

  • Page 26: Switch> Advanced> Spanning Tree Page

    The switch will only respond to requests from computers with the IP address in the list. You can also select the traps which the switch will send to the hosts in the following trap events. The setting of a host will not be active until it is set to “Enable” in the Admin field.

  • Page 27: Firmware Menu

    You can backup the system and switch settings to your workstation. This can help you to reconfigure the switch quickly if you have to re-set to factory defaults. Additionally, if you want to try out different configurations on the switch, this feature will enable you to quickly return to a previous configuration.

  • Page 28: Logout

    Smart Switch Series Software Manual Note: Please be aware that the switch will reboot after a successful reset. Logout When finished with all configuration and settings, click Logout to disconnect the current browser connection. The login page will pop up.

  • Page 29: Software Upgrade

    The application software for the Smart Switch is upgradeable, enabling your switch to take advantage of improvements and additional features as they become available. The upgrade procedure and the required equipment are described in the following section. The upgrade procedure is as follows: Save the new firmware to your computer.
  • Page 30 Smart Switch Series Software Manual Software Upgrade July 2005...

  • Page 31: Ieee 802.1Q Virtual Local Area Network (Vlan)

    Appendix B IEEE 802.1Q Virtual Local Area Network (VLAN) A Local Area Network (LAN) can generally be defined as a broadcast domain. Hubs, bridges or switches in the same physical segment or segments connect all end node devices. End nodes can communicate with each other without the need for a router.

  • Page 32: Ieee 802.1Q Vlans

    VLAN membership properties. A ‘U’ for a given port means that packets leaving the switch from that port will be Untagged. Inversely, a ‘T’ for a given port means that packets leaving the switch from that port will be tagged with the respective VLAN ID in which it participated in.
  • Page 33 The following scenarios will produce results as described below: (1). If an untagged packet enters Port 1, the switch will tag it with a VLAN tag value 10. The packet will have access to Port 2 and Port 3. The outgoing packet will be stripped away its tag becoming an untagged packet as it leaves Port 2.
  • Page 34 Smart Switch Series Software Manual IEEE 802.1Q Virtual Local Area Network (VLAN) July 2005...

  • Page 35: Appendix C Port-Based Vlan

    Port-based VLAN will help efficiently confine the broadcast traffic to the switch ports. This switch allows up to 26 port-based VLAN groups, any one port can belong to different VLAN groups. The default VLAN group port-based VLAN that have all ports belonging to VLAN 1.

  • Page 36: Scenarios

    Smart Switch Series Software Manual • Setting up first VLAN group (IT), VLAN ID = 01, with membership of all ports. Since VLAN ID 01 has been setup by default, you will have to remove the ports that belong to all other VLAN group except port 25.

  • Page 37: Appendix D Cabling Guidelines

    Appendix D Cabling Guidelines This appendix provides specifications for cables used with a NETGEAR Smart Switch Series Switch. Fast Ethernet Cable Guidelines Fast Ethernet uses UTP cable, as specified in the IEEE 802.3u standard for 100BASE-TX.The specification requires Category 5 UTP cable consisting of either two-pair or four-pair twisted insulated copper conductors bound in a single plastic sheath.

  • Page 38: Category 5 Cable

    Smart Switch Series Software Manual Category 5 Cable Category 5 distributed cable that meets ANSI/EIA/TIA-568-A building wiring standards can be a maximum of 328 feet (ft.) or 100 meters (m) in length, divided as follows: 20 ft. (6 m) between the hub and the patch panel (if used) 295 ft.

  • Page 39: Specifications

    The crossover function is usually implemented internally as part of the circuitry in the device. Computers and workstation adapter cards are usually media-dependent interface ports, called MDI or uplink ports. Most repeaters and switch ports are configured as media-dependent interfaces with built-in crossover ports, called MDI-X or normal ports. Auto Uplink technology automatically senses which connection, MDI or MDI-X, is needed and makes the right connection.

  • Page 40: Patch Panels And Cables

    Smart Switch Series Software Manual Figure D-2 illustrates crossover twisted pair cable. Figure D-2: Crossover Twisted-Pair Cable Patch Panels and Cables If you are using patch panels, make sure that they meet the 100BASE-TX requirements. Use Category 5 UTP cable for all patch cables and work area cables to ensure that your UTP patch cable rating meets or exceeds the distribution cable rating.

  • Page 41: Using 1000Base-T Gigabit Ethernet Over Category 5 Cable

    Return loss measures the amount of reflected signal energy resulting from impedance changes in the cabling link. The nature of 1000BASE-T renders this measurement very important; if too much energy is reflected back on to the receiver, the device does not perform optimally. Cabling Guidelines Smart Switch Series Software Manual July 2005...

  • Page 42: Near End Cross Talk (Next

    Smart Switch Series Software Manual Unlike 10BASE-T and 100BASE-TX, which use only two of the four pairs of wires within the Category 5, 1000BASE-T uses all four pairs of the twisted pair. Make sure all wires are tested ⎯ this is important.
  • Page 43 4, 5, 7, 8 Internal termination, not used for data transmission Table E-2 lists the pin assignments for the 100/1000 Mbps RJ-45 plug and the RJ-45 connector. Cabling Guidelines Smart Switch Series Software Manual UPLINK ASSIGNMENT ON PORT 8 Output Transmit Data + Output Transmit Data –...

  • Page 44: Conclusion

    Smart Switch Series Software Manual Table-D-3. 100/1000 Mbps RJ-45 Plug and RJ-45 Connector Pin Assignments CHANNEL Conclusion For optimum performance of your 1000BASE-T product, it is important to fully qualify your cable installation and ensure it meets or exceeds ANSI/EIA/TIA-568-A:1995 or ISO/IEC 11801:1995 Category 5 specifications.

  • Page 45: Default Settings

    This appendix provides default settings for the NETGEAR Smart Switches. You can always configure the switch to default settings by using the Factory Reset function from a Web browser. Table A-1. Default Settings FEATURE Port Speed Port Duplex Flow Control (half duplex)
  • Page 46 Smart Switch Series Software Manual Default Settings July 2005...
  • Page 47 Numerics 802.1x Port-Based Authentication 3-16, 4-25 Address Aging 3-26 Admin field 3-9 Advanced Security 3-16, 4-20, 4-25 Advanced Tools 4-21 Advanced> Spanning Tree 4-35 Advanced Options 4-19 Advantages of VLANs A-1 Auto MDI/MDI-X D-2 Auto Uplink D-2 Bridge Priority 3-24 Broadcast Control 3-21, 4-21 Cat5 cable D-2 Class of Service 4-21...
  • Page 48 CLI Configure System Restore 5-30 CLI Configure System Save 5-30 CLI Configure System Stat-Reset 5-34 CLI Configure System Username 5-31 CLI Configure System Web 5-30 CLI Configure Trap 5-25 CLI Exit 5-3 CLI Help 5-2 CLI Manual Syntax 5-1 CLI Ping 5-2 CLI Show 5-3 CLI Show DiffServ 5-4 CLI Show Interfaces 5-4...
  • Page 49 Inbound Errors 4-6 Inbound Non-unicast Packet rate 4-5 Inbound Non-unicast Packets 4-6 Inbound Octet Rate 4-5 Inbound Octets 4-6 Inbound Unicast Packet Rate 4-5 Inbound Unicast Packets 4-6 IP Configuration 3-8, 4-13 Last Saved option 3-19, 4-29 MAC 4-21 MAC > Address Aging 4-38 MAC Address Manager 3-25 MAC Address Table 3-6 MAC>...
  • Page 50 Static Multicast Administration 3-27 Static Multicast Membership 3-28 Statistics 3-5, 4-8 Statistics Rest 3-6 STP 4-21 Support for Standard MIBs 3-29, 4-40 Switch Statistics 4-5 System Configuration 4-12 system tools 3-11 TIP 3-2 Tools Menu 4-16 Traffic Management 3-19, 4-21, 4-31...

This manual is also suitable for:
