OPERATING THE 2X1 DVIKVM DL SWITCH
2.
Locate DIP switch 3. By default, this DIP switch will be in the OFF (down)
position.
DIP 3 in the OFF
position
3.
Adjust DIP switch 3 to the desired position.
DIP switch 3
OFF (default)
ON
NOTE: When DIP switch 3 is set to the ON position, then the 2x1
DVIKVM DL Switch will no longer receive IR commands from the IR
Remote Control unit. DIP switch 3 must be set to the OFF (toggle
mode) position to enable IR control.
Mode
Toggle mode
Discrete mode
12
