Air Live SNMP-FSH2602G User Manual

24+2 snmp/web switch 24 x 10/100base-tx ports optional gigabit/100basefx modules snmp, web, telnet, console port configurations mib ii, bridge mib, rmon ons
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SNMP-FSH2602G
24+2 SNMP/Web Switch
24 x 10/100Base-TX Ports
Optional Gigabit/100BaseFX modules
SNMP, WEB, Telnet, Console Port Configurations
MIB II, Bridge MIB, RMON ons
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Air Live SNMP-FSH2602G

Summary of Contents for Air Live SNMP-FSH2602G

  • Page 1 SNMP-FSH2602G 24+2 SNMP/Web Switch 24 x 10/100Base-TX Ports Optional Gigabit/100BaseFX modules SNMP, WEB, Telnet, Console Port Configurations MIB II, Bridge MIB, RMON ons User’s Manual...

  • Page 2: Fcc Warning

    Contents in this manual are subject to changes without prior notice. About this User’s Manual This User’s Manual aims at helping users to know the key features of SNMP-FSH2602G Management Switch and to install it in a Local Area Network (LAN). Chief Editor: Dr. Albert Yeh...

  • Page 3: Table Of Contents

    User’s Name and Password .................... 3 LED Table........................3 INSTALLATION OF THE SWITCH............4 Installation Procedures..................... 4 Unpack the Package......................5 Hardware Overview......................6 Front Panel ........................6 The Rear & Side Panel....................6 Module Installation......................7 Module Type........................8 SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 4: Table Of Contents

    Module LED ........................15 1000Base-T Module LEDs ................... 15 Fiber Module LEDs ...................... 15 LED Table........................16 WEB MANAGEMENT................17 In-Band and Out-of-Band Management............... 17 Setup your computer for Web management ..............17 The Concept of Subnet....................17 SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 5 Ingress and Egress Control .................... 29 Trunking ..................... 31 (Administrator menu) Aggregator setting......................31 Aggregator Information ....................32 State Activity ........................ 33 Filter Database ................... 34 (Administrator menu) IGMP Snooping ......................34 Static MAC Address ..................... 34 SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 6 TERMINAL MANAGEMENT ..............50 In-Band and Out-of-Band Management............... 50 Configure for Telnet management ................50 The Concept of Subnet....................50 Configure your computer’s IP ..................50 Remote Management ....................52 Telnet to the switch....................... 53 SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 7 Port Static Priority......................74 802.1p Priority Configuration..................75 MAC Address Configuration..................76 Static MAC Address ..................... 76 Filtering MAC Address....................79 Protocol Related Configuration..................81 STP Spanning Tree Protocol..................82 SNMP..........................84 Trap Managers ......................87 SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 8 System Information....................... 98 Reboot Switch........................99 Default........................... 99 Restart ........................... 99 TFTP Update Firmware....................100 TFTP Update Firmware ....................100 Restore Configure File....................101 Backup Configure File....................101 APPENDIX A PRODUCT SPECIFICATIONS ..........103 APPENDIX B TROUBLESHOOTING.............106 SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 9 Figure 5-2 Remote Management through direct Internet ..........52 Figure 5-3 Remote Management through Broadband Router........53 Fig. 5-4 RS-232 Cable ....................54 Fig. 5-5 Console Port ....................55 Fig. 6-3 RS-232 Cable ....................55 SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 10 Table 2-1 Module Specification Table ................8 Table 2-2 Cabling type for 10/100BASE-TX and 1000Base-T........11 Table 3-1 LED Table ....................16 Table 4-1 IGMP Snooping Messages ................34 Table 4-2 Span Tree Setting Parameters..............42 viii SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 11: Product Overview

    Phenomenal Power The SNMP-FSH2602G is compliant with RFC1213 (RMON groups 1, 2, 3, 9), RFC1493 (Bridge MIB), and RFC1643(Ether-Like MIB) SNMP standards. It features a full array of management function including Spanning Tree, IGMP Snooping, LACP Trunking, 802.1Q Port-Based VLAN, 802.1p Priority, Access and Security control, GVRP Automatic VLAN Assignment, 802.1v...

  • Page 12: Quick Setup

    “192.168.223.100 in Web browser or Telnet program to manage the switch. If users can’t find the switch at the default IP address, please connect the switch to the console port. Use the console port management to change the switch’s IP configuration. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 13: Console Port Information

    No connection is made 100M ● Green 100 Mbps Connection 10 Mbps Connection 1000Base-T Module Top LED ● Orange 100Mbps Connection 1000Mbps ● Green 10Mbps Connectiont Middle LED Bottom LED ● Green Blinking Transmitting/Receiving SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 14: Installation Of The Switch

    Chapter 4 for further instruction. Telnet Management: for instruction on management using Telnet, please see Chapter 5 for further instruction. Console Port Management: for instruction on management through console port, please see Chapter 5 for further instruction. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 15: Unpack The Package

    2 Installation of the Switch Unpack the Package Before you begin the installation of SNMP-FSH2602G Management Switch, make sure that you have all the necessary accessories that come with your package. Follow the steps below to unpack your package contents: 1.

  • Page 16: Hardware Overview

    The Rear & Side Panel The rear panel and side panel is where you can locate the power switch, AC power connector, and cooling fans. Cooling FAN Power Switch Power Connector Fig. 2-3 Rear & Side Panel SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 17: Module Installation

    2 Installation of the Switch Cooling Fans : The SNMP-FSH2602G is equipped with 2 cooling fans located on the sides of the switch. When facing front, the left cooling fan is designated as FAN 1 and the right cooling fan is designated as FAN2. When a fan has failed, the fan status LED on the front panel will light-up red to indicate a failure of the corresponding fan.

  • Page 18: Module Type

    “Auto” mode. The Gigabit Fiber ports on both sides must be set to operate in the same detection mode to work. The SNMP-FSH2602G’s fiber module is default to “forced 1000Mbps” mode. To operate with fiber port in “auto” mode, please change the mode through web Mini-GBIC Adapter: The mini-GBIC adapter module provides 2 empty Mini-GBIC slots for users to install industrial standard Mini-GBIC modules.

  • Page 19: Installation Site Preparation

    2 Installation of the Switch Installation Site Preparation You can mount SNMP-FSH2602G Fast Ethernet Switch either on desktop or on a 19-inch rack. If you plan to mount the switch on desktop, please choose a steady, level surface in a well-ventilated area that is free from excessive dust.

  • Page 20: Desktop Installation

    Fig. 2-5 Attaching the Switch to a 19-inch rack Desktop Installation SNMP-FSH2602G Management Switch has four rubber pads attached on each corner of its underside. These pads serve as cushioning against vibration and prevent the switch from sliding off its position. They also allow adequate ventilation space when you place the switch on top of another device.

  • Page 21: Cabling Requirements

    (CAT 5E recommended) Auto MDI/MDI-X function The SNMP-FSH2602G is equipped with Auto-MDI/MDI-X function, which allows you to use straight-thru cable even when connecting to another switch/hub. Simply use the straight-through cable for all types of 10/100/1000BASE-TX connections, either to a PC or to a networking device such as other hub or switch.

  • Page 22: Connecting To Power

    Fig 2-8 Pair Wires Connecting to Power SNMP-FSH2602G management switch features a universal auto-select power supply unit, which allows a power connection to a wide range of input voltages from 90 to 260V @ 50 ~ 60Hz.

  • Page 23: Led Indicators

    LED indicators of your Switch. Comprehensive LEDs The front-panel LED indicators of SNMP-FSH2602G comprise 3 sets of LEDs: System Status LEDs, Station Port LEDs, and Module LEDs. Each set of LEDs gives specific information concerning the system status or the station port status:...

  • Page 24: Fan1 Led

    Station Port LEDs for Port 1 ~ 24 The SNMP-FSH2602G is equipped with 2 LEDs on the sides of each RJ-45 station port. This design allows users to view the status of each port quickly. The left LED indicates the Link/Action Status.

  • Page 25: Module Led

    Link/Act LED giving a solid green light indicates that a data link has been established between the corresponding port and the device. If no connection is made, it will be off. While the port is transmitting or receiving data, you will see a blinking green light. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 26: Led Table

    100Mbps Connection Top LED 1000Mbps ● Green 10Mbps Connectiont Middle LED Bottom LED ● Green Blinking Transmitting/Receiving Fiber Modules ● Green Connection Established Link/Act Blinking Transmitting/Receiving No connection is made Table 3-1 LED Table SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 27: Web Management

    4 Web Management Web Management The SNMP-FSH2602G switch supports in-band management through web browser. In this session, you will learn how to access the switch’s powerful management functions through the web browser. You will also learn how to manage the switch remotely through Internet. Please note that the current firmware requires use of Internet Explorer for web configuration.

  • Page 28: Figure 4-1 Manual Ip Setting

    IP is not used by other network device. If the switch’s IP address is of factory’s default value. We recommend enter the following for computer’s IP: IP Address: 192.168.223.101 Subnet Mask: 255.255.248.0 Gateway: 192.168.223.254 SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 29: Remote Management

    *Note2: If IP address of the switch is lost, please use console port management to find the switch’s IP address. *Note3: The SNMP-FSH2602G has DHCP client ability. This allows DHCP server (or router) to assign IP automatically. However, we do not recommend turning on the DHCP client because the DHCP server assign the IP randomly.

  • Page 30: Connect Through Broadband Router

    Step 2: Enter the switch’s IP address in the Address field and press enter. Step 3: When prompt for User’s name and Password, enter the following information: User’s Name: admin Password: You should see the following welcome screen after the process is completed: SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 31: Menu Bar

    Port-25 will show the status of the single module port. Port Status All Port Status Click on “Port Status” of the left menu bar will bring up the general status for all the ports and modules. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 32: Single Port Status

    Config: Display the state of user setting. Atual: Display the negotiation result. Single port status User can also click the any port directly on the front panel of Home Page to get single port Status which is shown below. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 33: Port Statistics

    TXBadPKT – Number of bad packets sent RXGoodPKT – Number of good packets received RXBadPKT – Number of bad packets received TXAbort – Number of Aborted Packets Collison - Number of Collisions DropPKT - Number of Dropped Packets SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 34: Administrator

    IP randomly. Therefore, users will need to use the Console Port to find the IP address after assignment. The DHCP client should be used only when connecting directly to Cable Modem (for remote management) whose service provider uses DHCP for IP assignment. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 35: Switch Setting (Administrator Menu)

    Default config value version: Display write to default EEPROM value version. Module Info settings All information in this field are read only, user can’t modify its contents, it is only to display the module card information. Figure 4-8 Module Info SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 36: Advanced Settings

    The threshold is the percentage of the port's total bandwidth used by broadcast traffic. When broadcast traffic for a port rises above the threshold you set, broadcast storm control becomes active. The valid threshold value are 5%, 10%, 15%, 20%, 25% and off. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 37: Priority Queue Service Settings

    Disable – In half duplex, collision-retry maximum is 48 times and packet will be dropped if collision still happen. Enable – In half duplex, if happen collision will retry forever. 802.1x Protocol Enable or disable 802.1x protocol. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 38: Console Port Information (Administrator Menu)

    Force of per port. Speed: User can set 100Mbps or 10Mbps speed on Port1~Port24; set 1000Mbps, 100Mbps or 10Mbps speed on Port25~Port26 (depend on module card mode). SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 39: Ingress And Egress Control

    100Kbps sending speed (upstream). This type of control is called “bandwidth management.” Separate bandwidth management for incoming and outgoing traffic is important because broadband connection such as ADSL has different upstream and downstream speed. Application SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 40 Ingress at minimum rate. This will allow other people quickly download from the server, but restrict on upload. How to Setup Step 1: Under the web configuration, choose Administrator->Port Control Step 2: Please select the port where you want to control the rate SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 41: Trunking (Administrator Menu)

    All ports support LACP dynamic trunking group. If connecting to the device that also supports LACP, the LACP dynamic trunking group will be created automatically. Work ports: Allow max four ports can be aggregated at the same time. If LACP static trunking SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 42: Aggregator Information

    If following screen is shown, it indicates no group is active. LACP is not working. If the following screen is shown, This indicate static Trunking groups has been made. If the following page is shown, it indicates LACP trunking group has been made. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 43: State Activity

    A link has two N/A LACP ports will not perform dynamic LACP trunking because both ports are waiting for and LACP protocol packet from the opposite device. If you are active LACP’s actor, when you are select trunking port, the active status will be created automatically. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 44: Filter Database (Administrator Menu)

    (Administrator menu) IGMP Snooping The SNMP-FSH2602G switch supports multicast IP, one can enable IGMP protocol on web management’s switch setting advanced page, then display the IGMP snooping information in this page, you can view difference multicast group, VID and member port in here, IP multicast addresses range from 224.0.0.0 through 239.255.255.255.

  • Page 45: Mac Filtering

    VLANs. Type the VID (tag-based VLANs) to associate with the MAC address. Click the Add. MAC filtering MAC address filtering allows the switch to drop unwanted traffic. Traffic is filtered based on the destination addresses. Figure 4-16 MAC filtering SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 46: Vlan Configuration (Administrator Menu)

    Layer 2 switch. However, all the network devices are still plug into the same switch physically. The SNMP-FSH2602G switch supports port-based, 802.1Q (tagged-based) and protocol-base VLAN in web management page. In the default configuration, VLAN support is disabled. You can enable the VLAN function by choosing “Port Based VLAN”...

  • Page 47: 802.1V Protocol-Based Vlan

    802.v protocol VLAN classification, it is possible to group VLAN by protocol through multiple switches SNMP-FSH2602G switch will support protocol-based VLAN classification by means of both built-in knowledge of layer 2 packet formats used by selected popular protocols, such as Novell IPX and AppleTalk’s EtherTalk, and some degree of programmable protocol matching capability.

  • Page 48: Configuring 802.1Q And 802.1V Vlan

    Figure 4-18 Configure 802.1Q/V VLAN Basic Create a VLAN and add tagged member ports to it. From the main menu, click Administrator VLAN configuration, click Add then you will see the page as follow. SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 49 (ex: TRK1, TRK2…), and you can configure it is the member of the VLAN or not. Click Next. Then you can view the page as follow： SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 50: Port Vid

    VLAN but that don’t support tagging. SNMP-FSH2602G switch each port allows user to set one PVID, the range is 1~255, default PVID is 1. The PVID must as same as the VLAN ID that the port belong to VLAN group, or the untagged traffic will be dropped.

  • Page 51: Spanning Tree (Administrator Menu)

    On the Spanning Tree configuration page are explained as following: The spanning tree information about the Root Bridge in the following screen. The spanning tree status about the switch is shown in the following screen. Setting Spanning Tree SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 52: Figure 4-19 Set Spanning Tree

    Specifies the path cost of the port that switch uses to determine which port are the forwarding ports the lowest number is forwarding ports, the rage is 1-65535 and default value base on IEEE802.1D 10Mb/s = 50-600 100Mb/s = 10-60 1000Mb/s = 3-10 SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 53: Port Sniffer (Administrator Menu)

    System Options： Use this page to define management stations as trap managers and to enter SNMP community strings. User can also define a name, location, and contact person for the switch. Fill in the system options data, and then click Apply to update the changes on this page. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 54: Security Manager (Administrator Menu)

    If no trap manager is defined, no traps are issued. Create a trap manager by entering the IP address of the station and a community string. Security Manager (Administrator menu) On this page, user can change user name and password with following steps. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 55: Introduction To 802.1X Authentication Protocol

    Authenticator: The authenticator is the device between the client and the Radius server. It is typically an AP or switch. When a client needs to access certain service, the authenticator will forward the request to the authentication server and wait for the SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 56: Configuration (Administrator Menu)

    Hotspot provider: Wireless ISP installs Access Point in airport, café, and many public areas. They charge customer based on the usage. 802.1x gives service provider a feasible way for authentication. With the SNMP-FSH2602G switch, the APs do not have to support 802.1x. The authenticator function will be handled by the switch.

  • Page 57: Per Port Configuration

    Tx Period： Used to determine when an EAPOL PDU is to be transmitted (Default value is 30 seconds). Supplicant Timeout： Used to determine timeout conditions in the exchanges between the supplicant and authentication server(Default value is 30 seconds). SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 58: Tftp Update Firmware

    After update finished, press <reboot> to restart switch. TFTP Restore Configuration Use this page to set ftp server address. You can restore EEPROM value from here, but you must put back image in ftp server, switch will download back flash image. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 59: Tftp Backup Configuration

    Use this page to set tftp server ip address. You can save current EEPROM value from here, then go to the TFTP restore configuration page to restore the eeprom value. Reset System Reset Switch to the default configuration Reboot Reboot the Switch in software reset SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 60: Terminal Management

    5 Terminal Management Terminal Management The SNMP-FSH2602G switch supports terminal management through Telnet or Console Port. Console Port management allows out-of-band management and serve as a backup when Web/Telnet management fails. For station that does not have Internet Explorer, users can use Telnet for in-band management.

  • Page 61: Figure 5-1 Manual Ip Setting

    IP is not used by other network device. If the switch’s IP address is of factory’s default value. We recommend enter the following for computer’s IP: IP Address: 192.168.223.101 Subnet Mask: 255.255.248.0 Gateway: 192.168.223.254 SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 62: Remote Management

    *Note2: If IP address of the switch is lost, please use console port management to find the switch’s IP address. *Note3: The SNMP-FSH2602G has DHCP client ability. This allows DHCP server (or router) to assign IP automatically. However, we do not recommend turning on the DHCP client because the DHCP server assign the IP randomly.

  • Page 63: Telnet To The Switch

    Step 2: type “o <switch’s IP address> and press enter Step 3: When prompt for User’s name and Password, enter the following information: User’s Name: admin Password: You should see the following welcome screen after the process is completed: SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 64: Console Port Management

    Making RS-232 Cable Connection to the Host PC The way to make a RS-232 cable connection is simple. Just prepare a proper RS-232 cable and, with it, connect the console port of your SNMP-FSH2602G and the COM port (either COM1or COM2) of your host PC.

  • Page 65: Using Windows Hyperterminal

    Note: After you have established a RS-232 cable connection between SNMP-FSH2602G and your host PC, if your SNMP-FSH2602G or the host PC is not powered on, you should power them up before you can configure smart console functions. Using Windows HyperTerminal After you have properly established a RS-232 cable connection between the console port of SNMP-FSH2602G and the host PC.
  • Page 66 Step 3: Ether any name you would like to have for this connection (in this example, we use SNMP-FSH2602G as name for the connection) and choose an icon. Click OK. Step 4: The Connect to dialog box appear. Since the HyperTerminal connection is made through console port instead of a phoneline, you need only to configure the Connect using: drop-down combo box (that means the settings of the rest of the combo box or list boxes can simply be ignored).
  • Page 67 Configure the various port settings such as followings: Bits per second: 9600 Data bits: 8 Parity: None Stop bits: 1 Flow Control: None Click OK. Step 6: Press <Enter> when the blank screen appears SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 68: Main Menu

    5 Terminal Management Step 7: When prompted for User’s name and password. Enter “admin” as username and “123” as password. After the host PC has successfully connected to SNMP-FSH2602G, you will see the Switch Setup Main Menu appears. Main Menu Once getting into the terminal management main screen, the Telnet and Console Port management will share the same configuration method.

  • Page 69: Switch Configuration

    <Previous Page>: Return to previous page to configure. <Next page>: Go to the next page to configure it. Port Configuration This page can change every port status. Press Space key to change configures of per item. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 70: Trunk Configuration

    Trunk Configuration This page can create max seven trunk groups. User can arbitrarily select up to four ports from port 1~port 26 to build a trunking group. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 71: Vlan Configuration

    VLAN members and Port configuration they will be toggled on or off simultaneously. NOTE: If VLAN group exist, all of the members of static trunk group must be in same VLAN group. VLAN Configuration SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 72: Vlan Configure

    It matches that Ingress Filtering Rule 1 on web. Forwarding only packets with VID matching this port’s configured VID. Press Space key to choose “forward” or “drop” the frame that VID not matching this port’s configured VID. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 73: Create A Vlan Group

    Protocol VLAN: Press Space key to choose protocols type. Member: Press Space key to choose VLAN member. There are three types to selected: UnTagged：this port is the member port of this VLAN group and outgoing frames are NO SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 74: Edit / Delete A Vlan Group

    User can modify the protocol VLAN item and the member ports are tagged or un-tagged and remove some member ports from this VLAN group. After edit VLAN, press <Save> key to save all configures value. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 75: Groups Sorted Mode

    In this page, user can select VLAN groups sorted mode: sorted by name sorted by VID. The Edit/Delete a VLAN group page will display the result. In the Edit/Delete a VLAN Group page, the result of sorted by name. SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 76 5 Terminal Management In the Edit/Delete a VLAN Group page, the result of sorted by VID. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 77: Misc Configuration

    5 Terminal Management Misc Configuration MAC Age Interval Type the number of seconds that an inactive MAC address remains in the switch’s address table. The valid range is 300~765 seconds. Default is 300 seconds. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 78: Broadcast Storm Filtering

    NOTE: Make sure “Max bridge transit delay bound control” is enabled before enabling Low Queue Delay Bound, because Low Queue Delay Bound must be work under “Max bridge transit delay bound control” is enabled situation. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 79: Port Security

    MAC addresses that can use the secure port. Actions-> Select <Edit>. Press Space key to choose enable / disable item. Press Ctrl+A to go back action menu line. Select <Save> to save all configure value. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 80: Collision S Retry Forever

    Collision s Retry Forever Collisions Retry Forever: Disable – In half duplex, if happen collision will retry 48 times and then drop frame. Enable – In half duplex, if happen collision will retry forever (Default). Administration Configuration SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 81: Change Username

    Change Username Use this page; user can change web management user name. Type the new user name, and then press <Save> item. Change Password Use this page; user can change web management login password. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 82: Device Information

    5 Terminal Management Device Information This page is provided to the user to configure the device information. IP Configuration User can configure the IP setting and fill in the new value. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 83: Port Mirror Configuration

    On the action menu line you can press <Next Page> to configure port9 ~ port26, press <Previous Page> return to last page. NOTE: Only has one sniffer mode in switch at the same time. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 84: Priority Configuration

    5 Terminal Management Priority Configuration Port Static Priority This static priority based on port, if you set the port is high priority, income frame from this port always high priority frame. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 85: 802.1P Priority Configuration

    Press Space key to select the priority level mapping to high or low queue. High/Low Queue Service Ration H：L: User can select the ratio of high priority packets and low priority packets. Press Ctrl+A go back action menu line. Select <Save> to save all configure value. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 86: Mac Address Configuration

    This saves the switch from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again. In this page user can add / modify / delete a static MAC address. SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 87 Press Ctrl+A to go back action menu line. Then select <Save> to save all configure value. Edit static MAC address Press <Edit> key. Choose the MAC address that you want to modify and then press enter. SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 88 Press Ctrl +A to go back action menu line, and then select <Save> to save all configure value. Delete static MAC address Press <Delete> key. Choose the MAC address that you want to delete and then press enter. Pressing <Enter> once will complete deletion on delete mode. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 89: Filtering Mac Address

    Vlan ID: If tag-based (802.1Q) VLAN are set up on the switch, type the VID to associate with the MAC address. Press Ctrl+A to go back action menu line, and then select <Save> to save all configure value. SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 90 Choose the MAC address that you want to modify and then press enter. Press <Edit> key to modify all the items. Press Ctrl+A to go back action menu line, and then select <Save> to save all configure value. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 91: Protocol Related Configuration

    Press <Delete> key to delete a filter MAC address. Choose the MAC address that you want to delete and then press enter. When pressing <Enter> once will complete deletion on delete mode. Protocol Related Configuration SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 92: Stp Spanning Tree Protocol

    When STP enabled, to ensure that only one path at a time is active between any two nodes on the network. STP Enable This page is show the users how to enable or disable Spanning Tree function. Press Space key to select enable or disable. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 93: Stp System Configuration

    You can view spanning tree information about the Root Bridge on the left. On the right, user can set new value for STP parameter. NOTE: All about the parameter description please see the sections Web configuration’s explanation of Spanning Tree. Perport Configuration SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 94: Snmp

    System Name: Type a name to be used for the switch. System Contact: Type the name of contact person or organization. System Location: Type the location of the switch. Press Ctrl+A go back action menu line. Press <Save> to save the configure value. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 95: Community Strings

    Write Access: Enable the rights is read only or read-write. Restricted: Read only, enables requests accompanied by this string to display MIB-object information. Unrestricted: Read write, enables requests accompanied by this string to display MIB-object information and to set MIB objects. SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 96 Press <Edit> key, choose the item that you want to modify and then press Enter. Community Name: Type the new name. Write Access: Press <Space> key to change the right is restricted or unrestricted. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 97: Trap Managers

    A trap manager is a management station that receives traps, the system alerts generated by the switch. If no trap manager is defined, no traps are issued. Create a trap manager by entering the IP address of the station and a community string. SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 98 Press <Edit> key, and then choose the item that you want to modify. IP: Type the new IP address Community Name: Type the community name. Press Ctrl +A go to actions line, press <Save> key to save all configure. SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 99 5 Terminal Management Delete trap manager Press <Delete> key. Choose the trap manager that you want to delete and then press enter. When pressing <Enter> once will complete deletion on delete mode. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 100: Gvrp

    Note: GVRP must also be enabled on participating network nodes. IGMP The Internet Group Management Protocol (IGMP) is an internal protocol of the Internet Protocol (IP) suite. This page you can enable / disable the IGMP support. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 101: Lacp (Link Aggregation Control Protocol)

    Press Space key to choose Enabled / Disabled. Press Ctrl+A go back action menu line. Select <Save> to save configure value. LACP (Link Aggregation Control Protocol) This page can configure and view all the LACP status. SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 102 Press Ctrl+A go back action menu line. Press <Save> to save the configure value. NOTE: If user set LACP mode in the trunk group, all of the member ports of this trunk group will set "Active" automatic. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 103: Lacp Status

    When you’re setting trunking group, you can see the relational information here. Static trunk group LACP trunk group <Quit>: Exit this page and return to previous menu. <Previous Page>: Return to previous page to view. <Next page>: Go to the next page to view. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 104: 802.1X Protocol

    This page can configure and view all the 802.1x status. 802.1x Enable 1.Select <Edit>. 2.Press Space key to choose Enabled / Disabled. 3.Press Ctrl+A go back action menu line. 4.Select <Save> to save configure value. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 105: X System Configuration

    5. Server Port: The UDP port number used by the authentication server to authenticate. 6.Accounting Port: The UDP port number used by the authentication server to retrieve accounting information. 6. Press Ctrl+A go back action menu line. 7. Press <Save> to save configure value. Note: SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 106: X Misc Configuration

    2 times). Reauth Period： used to determine a nonzero number of seconds between periodic reauthentication of the supplications(Default value is 3600 seconds). Press Ctrl+A go back action menu line. Press <Save> to save configure value. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 107: Status And Counters

    OutRate: Display the output rate control (100K/unit) setting value. Enabled: Display the port is enabled or disable depended on user setting. Enable will be display “Yes”, disable will be display “No”. If the port is unlink will be treated as “No”. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 108: Port Counters

    Module 1 Type: Display the module 1 type :1000Tx or 100Fx ext. Depend on module card mode. Module 1 information: Display the information saved in eeprom of module1. Module 2 Type: Display the module 2 type :1000Tx or 100Fx ext. Depend on module card mode. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 109: Reboot Switch

    5 Terminal Management Module 2 information: Display the information saved in eeprom of module2. Reboot Switch Default Reset switch to default configuration. Restart Reboot the switch in software reset. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 110: Tftp Update Firmware

    This page provides user use TFTP to update firmware. Start the TFTP server, and copy firmware update version image file to TFTP server. Press <Edit> on this page. TFTP Server: Type the IP of TFTP server. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 111: Restore Configure File

    This page user can save current EEPROM value to image file. Then go to the update configure page to restore the EEPROM value. Start the TFTP server. Press <Edit> on this page. TFTP Server: Type the IP of TFTP server. SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 112 Remote File Name: Type the image file name. Press Ctrl+A go to action line. Press <Save> key, it will start to upload the image file. When save successfully, the image file upload finished too. Restart switch. SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 113: Appendix A Product Specifications

    Appendix A Product Specifications SNMP-FSH2602G Management Switch Appendix A Product Specifications Hardware • 24 x 10/100Base-TX Nway, auto-sensing ports Auto MDI/MDI-X to eliminate needs for cross-over cabling Single Module Slot for optional 1-port or 2-port 1000Base-T(copper), 1000Base-SX(Fiber), 1000Base-LX(Fiber) Gigabit modules...
  • Page 114 802.1v protocol-based VLAN classification Supporting Protocols: IP, ARP, AppleTalk, AppleTalk AARP, Novell IPX, Banyan Vines, DECnet MOP, DECnet DPR, DECnet, LAT, DECnet LAVC, IBM SNA, X.75 Internet, X.25 Layer 3 GVRP Auto VLAN Configuration IP Multicast SNMP-FSH2602G Management Switch User’s Manual V2.0...
  • Page 115 Built-in Power Supply Input: 90-260VAC, 50/60Hz Consumption: 36 Watts max. Dimension • 440mm (W) X 184mm (D) X 44mm (H) Weight • 2 KG Regulation • FCC Part 15 Class A CE mark, Class A SNMP-FSH2602G Management Switch User’s Manual V2.0...

  • Page 116: Appendix B Troubleshooting

    • If you find out where the problem is but cannot solve it by yourself, or you simply cannot locate what is at fault, please contact your local dealer for technical support. SNMP-FSH2602G Management Switch User’s Manual V2.0...
