- Page 1 POE-FSH2422G-390 24-Port Full Power 802.3af PoE Web Smart Switch User’s Manual...
- Page 2 OvisLink Corp. has made the best effort to ensure the accuracy of the information in this user’s guide. However, we are not liable for the inaccuracies or errors in this guide. Please use with caution. All information is subject to change without notice All Trademarks are properties of their respective holders. AirLive POE-FSH2422G-390 User’s Manual...
-
Page 3: Fcc Statement
IMPORTANT NOTE FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. AirLive POE-FSH2422G-390 User’s Manual... -
Page 4: Table Of Contents
4.3 Get into the Web Management............19 4.4 Administrator ...................20 4.5 Authentication Configuration (Administrator menu)......21 4.6 System IP Configuration (Administrator menu) .......21 4.7 System Status (Administrator menu) ..........22 4.8 Load default setting (Administrator menu)........23 4.9 Firmware Update (Administrator menu) ..........23 AirLive POE-FSH2422G-390 User’s Manual... - Page 5 4.31 STP Bridge Settings (Spanning Tree)..........39 4.32 STP Port Settings (Spanning Tree) ..........40 4.33 Loopback Detection Settings (Spanning Tree) ........42 4.34 Backup/Recovery ................42 4.35 Miscellaneous..................43 4.36 SNMP ....................44 4.37 Logout .....................45 Appendix A: Product Specifications ............46 Appendix B: Troubleshooting..............48 AirLive POE-FSH2422G-390 User’s Manual...
-
Page 6: Introduction
Introduction 1.1 Overview The POE-FSH2422G-390 is a Power Control POE Switch, and total power is 390W. This switch provides 24 10/100Mbps RJ-45 ports and can support 2 Combo Gigabit RJ-45/SFP to uplink. This web-smart switch includes auto-MDI/MDIX crossover detection function. 24 of those ports are all built with PoE functionality, providing the ultimate choice in network flexibility. -
Page 7: Guide To The Chapters
For detailed installation instruction, please see chapter 2 for more information. Power-On the switch The POE-FSH2422G-390 Switch has a built-in power supply to operate with 100 ~ 240V AC, 50 ~ 60Hz power source. The AC power cord connector is located at the rear of the unit and the On/Off switch is next to the connector. -
Page 8: Installation Steps
This section lists the installation procedures in steps. Each step’s instruction is thoroughly explained in the subsequent sections of this chapter. Step 1 Connect your device's PoE port to the switch's POE port (see Figure A). The Gigabit ports are not PoE ports. AirLive POE-FSH2422G-390 User’s Manual... - Page 9 Your PoE device should get the power from the switch now. If you want to change settings via web management. Please follow the instructions below. Step 5 Set your PC's IP address to 192.168.2.50. Step 6 Open your web browser and enter "192.168.2.1" to get into the switch's web management. AirLive POE-FSH2422G-390 User’s Manual...
-
Page 10: Comparison Chart
(L x W x H) (L x W x H) Weight 2.54 kg 4.7 kg Operating 0 to 45℃ Temperature Storage -20 to 90℃ Temperature Humidity 10 to 90% RH (non-condensing) Certifications FCC Class A, CE AirLive POE-FSH2422G-390 User’s Manual... -
Page 11: Installation Of The Switch
IP address, password, and LED table for user’s reference. 2.1 Unpack the Package Before you begin the installation of POE-FSH2422G-390 Management Switch, make sure that you have all the necessary accessories that come with your package. Follow the steps below to unpack your package contents: Clear out an adequate space to unpack the package carton. -
Page 12: Hardware Overview
These ports also support the automatic MDI/MDIX crossover detection function, providing true “plug and play” capability. Just plug-in the network cable to the hub directly and regardless if the end node is a NIC (Network Interface Card) or switch and hub. AirLive POE-FSH2422G-390 User’s Manual... -
Page 13: Installation Site Preparation
2.3 Installation Site Preparation You can mount POE-FSH2422G-390 24-Port Full Power 802.3af PoE Switch either on desktop or on a 19-inch rack. If you plan to mount the switch on desktop, please choose a steady, level surface in a well-ventilated area that is free from excessive dust. In any case, the installation site chosen for your switch has to comply with the following requirements: AirLive POE-FSH2422G-390 User’s Manual... -
Page 14: Rack Mounting
Leave at least 10cm(4 inch) of space around the switch to allow heating dissipation 2.4 Rack Mounting The POE-FSH2422G-390 PoE Switch can be mounted on a standard size 19-inch rack, which can in turn be placed in a wiring closet with other equipments. -
Page 15: Desktop Installation
2. Installation of the Switch 2.5 Desktop Installation The POE-FSH2422G-390 PoE Switch has four rubber pads attached on each corner of its underside. These pads serve as cushioning against vibration and prevent the switch from sliding off its position. They also allow adequate ventilation space when you place the switch on top of another device. -
Page 16: Cabling Requirements
Auto MDI/MDI-X function The POE-FSH2422G-390 PoE Switch is equipped with Auto-MDI/MDI-X function, which allows you to use straight-thru cable even when connecting to another switch/hub. Simply use the straight-through cable for all types of 10/100BASE-TX connections, either to a PC or to a networking device such as other hub or switch. -
Page 17: Connecting To Power
Cabling type for 10/100BASE-TX and 1000Base-T 2.7 Connecting to Power POE-FSH2422G-390 PoE Switch features a universal auto-select power supply unit, which allows a power connection to a wide range of input voltages from 100 to 240VAC @ 50 ~ 60Hz. - Page 18 2. Installation of the Switch Key in the user ID and the password to pass the authentication; the user ID and the password are “admin” IP Address: 192.168.2.1 ID: admin Password: airlive AirLive POE-FSH2422G-390 User’s Manual...
-
Page 19: Led Indicators
3. LED Indicators LED Indicators Before connecting any network device to POE-FSH2422G-390 802.3af PoE Switch, you should take a few minutes to look over this chapter and get familiar with the front panel LED indicators of your Switch. 3.1 Comprehensive LEDs 3.2 LED Table... -
Page 20: Web Management
4. Web Management Web Management The POE-FSH2422G-390 PoE Switch can be configured by web based interface, including administrator, port management, VLAN setting, per port counter, trunk setting, QoS setting, security filter, configuration/ backup/recovery, miscellaneous, log out, and so on. The device based smart switch supports main stream browsers, such as IE 6.0~7.0, Firefox... - Page 21 “Start -> Settings -> Network -> Local Connection” of the task bar’s Start menu. Step 2 Clock on the “property” icon. Step 3 Double click on the “Internet Protocol (TCP/IP) AirLive POE-FSH2422G-390 User’s Manual...
-
Page 22: Remote Management
Click “Okay” after finish entering the IP. Note: The POE-FSH2422G-390 has DHCP client ability. This allows DHCP server (or router) to assign IP automatically. However, we do not recommend turning on the DHCP client because the DHCP server assign the IP randomly. The DHCP client should be used only when connecting directly to Cable Modem (for remote management) whose service provider uses DHCP for IP assignment. -
Page 23: Connect Through Broadband Router
ISP for further information about your IP address. When the configuration is finished, the Remote PC can access the switch by typing the switch’s IP address on the web browser. Connect through Broadband Router AirLive POE-FSH2422G-390 User’s Manual... -
Page 24: Get Into The Web Management
Open the Internet Explorer Step 2 Enter the switch’s IP address in the Address field and press enter. Step 3 When prompt for User’s name and Password, enter the following information: User’s Name: admin Password: airlive AirLive POE-FSH2422G-390 User’s Manual... -
Page 25: Administrator
Administrator on Home Page, including: Authentication Configuration System IP Configuration System Status Load Default Setting Firmware Update Reboot Device In the following sessions, we will talk in detail about the management functions under the Administrator menu. AirLive POE-FSH2422G-390 User’s Manual... -
Page 26: Authentication Configuration (Administrator Menu)
This page shows authentication configuration information. User can set new Username and Password in this page. 4.6 System IP Configuration (Administrator menu) This page shows system configuration including the current IP address and sub-net mask and gateway. AirLive POE-FSH2422G-390 User’s Manual... -
Page 27: System Status (Administrator Menu)
“-“, “+”, “0 ~9”, excluding special character. MAC Address: Displays the unique hardware address assigned by manufacturer (default). Number of Ports: Displays number of ports in the switch. System Version: Displays the switch’s firmware version. And then click Update button. AirLive POE-FSH2422G-390 User’s Manual... -
Page 28: Load Default Setting (Administrator Menu)
Boot Loader, so the Boot Loader will keep intact. Even though the power is turned off or the cable link fails during the firmware update procedure, the Boot loader will restore the code to firmware update page. AirLive POE-FSH2422G-390 User’s Manual... -
Page 29: Reboot Device (Administrator Menu)
There are many management functions can be set or performed if you click the Port Management on Home Page, including: Port Configuration Port Mirroring Bandwidth Control Broadcast Storm Control In the following sessions, we will talk in detail about the management functions under the Port Management menu. AirLive POE-FSH2422G-390 User’s Manual... -
Page 30: Port Configuration (Port Management Menu)
Speed: When the Auto-Negotiation column is set as Disable, users have to set the connection speed to the ports ticked. Duplex: When the Auto-Negotiation column is set as Disable, users have to set the connection mode in Half/Full to the ports ticked. AirLive POE-FSH2422G-390 User’s Manual... -
Page 31: Port Mirroring (Port Management Menu)
Destination (mirroring) port for monitoring RX only, TX only or both RX and TX traffic which come from the source port. Users can connect the mirroring port to LAN analyzer or Netxray. Monitored Packets: Pull down the selection menu to choose what kind of packet is to be monitored. AirLive POE-FSH2422G-390 User’s Manual... -
Page 32: Bandwidth Control (Port Management Menu)
This page allows the setting of the bandwidth for each port. The TX rate and RX rate can be filled with the number ranging from 1 to 255. This number should be multiplied by the selected bandwidth resolution to get the actual bandwidth. AirLive POE-FSH2422G-390 User’s Manual... -
Page 33: Broadcast Storm Control (Port Management Menu)
Enable Port: Having ticked the boxes, the port will stop transmitting or receiving data when their sending byte counts or receiving byte counts reach the defined threshold. Click Update to have the configuration take effect. AirLive POE-FSH2422G-390 User’s Manual... -
Page 34: Poe (Port Management Menu)
There are many management functions can be set or performed if you click the VLAN Setting on Home Page, including: VLAN Mode VLAN Member Multi to 1 Setting In the following sessions, we will talk in detail about the management functions under the VLAN Setting menu. AirLive POE-FSH2422G-390 User’s Manual... -
Page 35: Vlan Mode (Vlan Setting)
Remove tag means the 802.1Q tag of the outgoing packet of the selected port will not be sent. Use this setting for your Network Connections to PCs. Only packets of the VLAN Group the Port is member of will be sent. AirLive POE-FSH2422G-390 User’s Manual... -
Page 36: Vlan Member (Vlan Setting)
The ports need to be made member of your VLAN groups. This is for Tag Based and Port Based VLAN Mode. The screen here looks different whether you run Tag Based or Port Based Mode. VLAN Member in Port Based Mode AirLive POE-FSH2422G-390 User’s Manual... - Page 37 Port 1 is member of group 100 and 101. A simple PC is connected to Port 1. If that PC is now sending out data, with PVID you define if that data is for group 100 or 101. AirLive POE-FSH2422G-390 User’s Manual...
-
Page 38: Multi To 1 Setting (Vlan Setting)
Receive packet & Drop packet: This category shows the number of received valid packet and the number of dropped packet. Receive packet & CRC packet: This category shows the received correct packet and received CRC error. AirLive POE-FSH2422G-390 User’s Manual... -
Page 39: Trunking
This managed switch supports two trunk group, each trunk consists of 2~4 ports. Trunk hash algorithm can be selected according to 4 different methods. AirLive POE-FSH2422G-390 User’s Manual... -
Page 40: Qos Setting
4.24 Priority Mode (QoS Setting) There are three priority modes available to specify the priority of packets being serviced. Those include First-In-First-Out, All-High-Before-Low, and Weight-Round-Robin. First-In-First-Out: Packets are placed into the queue and serviced in the order they were received. AirLive POE-FSH2422G-390 User’s Manual... -
Page 41: Port, 802.1P, Ip/Ds Based (Qos Setting)
The operating theory for all 4 CoS types can be illustrated by the following figure and table. TCP/UDP CoS is a global setting for all ports and has no connection with the physical port. Other CoS types have a connection with the physical port. AirLive POE-FSH2422G-390 User’s Manual... -
Page 42: Security
Each port can correspond to up to 3 MAC addresses. To activate the port binding function, you should enter the correct MAC address, select the port number, and set the port binding to “enable” and then press “update”. AirLive POE-FSH2422G-390 User’s Manual... -
Page 43: Tcp/Udp Filter (Security)
The ”negative” function makes the switch drop the selected protocol and forward other protocols. The protocol is checked at the selected secure WAN port. And it should be set at the server side. AirLive POE-FSH2422G-390 User’s Manual... -
Page 44: Spanning Tree
Number between 0 - 61440 in increments of 4096. Therefore, there are 16 distinct values. Hello Time: Interval (in seconds) at which the root device transmits a configuration message (BPDU frame). Number between 1-10 (default is 2). AirLive POE-FSH2422G-390 User’s Manual... -
Page 45: Stp Port Settings (Spanning Tree)
BPDU frame. Number between 6-40 (default is 20). Forward Delay: The maximum time (in seconds) the root device will wait before changing states (i.e., discarding to learning to forwarding). Number between 4 – 30 (default is 15) 4.32 STP Port Settings (Spanning Tree) AirLive POE-FSH2422G-390 User’s Manual... - Page 46 Number between 0 - 200000000. 0 means auto generated path cost. State: Show the current port state includes designated port, root port or blocked port. Status: Show the current port status includes forwarding, disable etc… AirLive POE-FSH2422G-390 User’s Manual...
-
Page 47: Loopback Detection Settings (Spanning Tree)
The user can save configuration file to a specified file. If the user wants to recover the original configuration, which is saved at the specified path, just enter the password and then press the “upload” button. Finally the original configuration of the switch will be recovered. AirLive POE-FSH2422G-390 User’s Manual... -
Page 48: Miscellaneous
4. Web Management 4.35 Miscellaneous Miscellaneous setting is used to configure output queue aging time, VLAN stride and IGMP snooping. AirLive POE-FSH2422G-390 User’s Manual... -
Page 49: Snmp
SNMP agents. SNMP agents are programs that reside SNMP capable device's firmware to provide SNMP configuration service. The NMS typically is a PC based software such as HP Openview that can view and manage SNMP network device remotely. AirLive POE-FSH2422G-390 User’s Manual... -
Page 50: Logout
4. Web Management 4.37 Logout The administrator has write access for all parameters governing the onboard agent. User should therefore assign a new administrator password as soon as possible, and store it in a safe place. AirLive POE-FSH2422G-390 User’s Manual... -
Page 51: Appendix A: Product Specifications
Per Port: Link/Act, LED Indicators PoE: Act / Status Per Unit: Power Power Input 100~240V/AC, 50~60Hz 48V/DC per Port Output – 15.4W Max per Port – Power Output 24Watt Max Per Port Power 390Watts (Max) Consumption AirLive POE-FSH2422G-390 User’s Manual... - Page 52 Dimensions 440 × 332 × 44 mm (L x W x H) Weight 4.7 kg Operating 0 to 45℃ Temperature Storage -20 to 90℃ Temperature Humidity 10 to 90% RH (non-condensing) Certifications FCC Class A, CE AirLive POE-FSH2422G-390 User’s Manual...
-
Page 53: Appendix B: Troubleshooting
Please take the following steps to reset the Web Smart Switch back to the original default: Step 1 Turn on the POE-FSH2422G-390 802.3af PoE Switch Step 2 Press and hold the reset button continuously for 5 seconds and release the reset button. - Page 54 Appendix: B: Troubleshooting Key in the user ID and the password to pass the authentication; the user ID and the password are “admin” IP: 192.168.2.1 ID: admin Password: airlive AirLive POE-FSH2422G-390 User’s Manual...
