MicroNet SP508C User Manual

8-port 100 mbps fast ethernet hub

Hide thumbs

page of 9

/ 9
Bookmarks

Quick Links

Download this manual

6383;&26383;'

;03RUW#433#0ESV#)DVW#(WKHUQHW

0LFURQHW

+XE

8VHU*V#*XLGH

Need help?

Do you have a question about the SP508C and is the answer not in the manual?

Questions and answers

Summary of Contents for MicroNet SP508C

Page 1 0LFURQHW 0LFURQHW 0LFURQHW 0LFURQHW 6383;&26383;' 6383;&26383;' 6383;&26383;' 6383;&26383;' ;03RUW#433#0ESV#)DVW#(WKHUQHW ;03RUW#433#0ESV#)DVW#(WKHUQHW ;03RUW#433#0ESV#)DVW#(WKHUQHW ;03RUW#433#0ESV#)DVW#(WKHUQHW 8VHU*V#*XLGH 8VHU*V#*XLGH 8VHU*V#*XLGH 8VHU*V#*XLGH...
Page 2 100 Mbps Fast Ethernet connections. Traffic passing between attached devices is confined within the internal repeater bus. The SP508C/SP508D can be used as stand alone hubs or uplink to two units through daisy-chain port. The SP508C/SP508D hub provide an ideal solution for 100 Mbps Fast Ethernet networks.,...
Page 3 +DUGZDUH#'HVFULSWLRQ The SP508C/SP508D provides a friendly design that simplifies installation and network troubleshooting. The figures below show the front panel of SP508C/SP508D. SP508C: S P 5 08 C E th erfast 100 M bps H ub SP508D: 6383;'#(WKHU)DVW#4330ESV#+XE...
Page 4 /('#,QGLFDWRUV The SP508C/SP508D provides LED indicators for monitoring various network conditions. A glance on the front panel will allow you to instantly monitor the status of each station port plus the overall affecting the hub. Color Indication ON: Unit is receiving power...
Page 5 Verify the following installation requirements: • Power requirements: SP508C: 15VDC 800mA. SP508D: 100-240 VAC ( 10%) at 50 to 60 Hz ( 3Hz). • The hub should be located in a cool dry place, with at least 10 cm.
Page 6 Notes: 1. Make sure each twisted-pair cable does not exceed 100 meters (328 feet). 2. The Category 5 cables are used for all Fast Ethernet connections. 3. The port 8 can serve as daisy-chain port (via the MDI RJ-45 port). Use normal RJ45 cable. Plug one end of the cable into MDI port 8 of the hub and plug the other end of the cable into any port of the other switch.
Page 7 7URXEOHVKRRWLQJ The hub can be easily monitored through panel indicators to assist the network manager in identifying problems. This section describes common problems you may encounter and possible solutions. Symptom:Power indicator does not light up (green) after power on. Cause: Defective power outlet, power cord/power adapter, or internal power supply.
Page 8 1HWZRUN 6SHFLILFDWLRQ Hub-to-workstation 100 meters maximum cable connection length for unshielded twisted- pair (UTP) category 5 cable or STP cable. 2 max for 100BASE-TX. Number of hubs chained 6SHFLILFDWLRQV Transmission Technique Base band Tree Topology CSMA/CD, 100Mbps Access Method Standards Conformance IEEE 802.3u 100BASE-TX, Class II Ethernet Repeater Hub Media Supported...
Page 9 Dimensions (WxDxH) SP508C: 197mm x 120mm x 35mm SP508D: 250mm x 116mm x 36mm Power System SP508C: 15VDC 800mA SP508D: 100-120 VAC, or 220-240 Temperature 0 to 40(Standard Operating) 10% to 90% (Non- Humidity condensing) FCC Class A, CISPR 22...
