INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
MT VERNON PELLET INSERT
ADVANCED ENERGY (AE)
Model(s):
MTVERNINSAE-MBK
MTVERNINSAE-PMH
MTVERNINSAE-CSB
CAUTION
Tested and approved for wood pellets, shelled field
corn, wheat and black oil sunflower seeds. Burning of
any other type of fuel voids your warranty.
CAUTION
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and na-
tional codes and regulations.
• Consult local building, fire officials or authorities having juris-
diction about restrictions, installation inspection, and permits.
1
Owner's Manual
Operation & Care
Tested and
O-T L
Portland
Listed by
Oregon USA
C
US
OMNI-Test Laboratories, Inc.
7036-187
WARNING
If the information in these instruc-
tions is not followed exactly, a
fire may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfire - If heater or chimney con-
nector glows, you are overfiring. Overfiring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specified. Failure to
comply may cause house fire.
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fireplace.
•
Alert children and adults to hazards of high temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other flammable
materials away.
NOTE
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrafire.com
Pour obtenir une traduction française de ce manuel, s'il vous
plaît contacter votre revendeur ou visitez www.quadrafire.com
January 29, 2014
Advertisement
Table of Contents
Related Manuals for Quadra-Fire MTVERNINSAE-MBK
Summary of Contents for Quadra-Fire MTVERNINSAE-MBK
- Page 1 If the information in these instruc- MT VERNON PELLET INSERT tions is not followed exactly, a fire may result causing property ADVANCED ENERGY (AE) damage, personal injury, or death. Model(s): • Do not store or use gasoline or other flam- MTVERNINSAE-MBK mable vapors and liquids in the vicinity of MTVERNINSAE-PMH this or any other appliance. • Do not overfire - If heater or chimney con- MTVERNINSAE-CSB nector glows, you are overfiring. Overfiring will void your warranty.
-
Page 2: Congratulations
A. Congratulations tion of our stoves, inserts and fireplaces. And yet we are Hearth & Home Technologies welcomes you to our tradition old-fashioned when it comes to craftsmanship. Each unit of excellence! In choosing a Quadra-Fire appliance, you is meticulously fabricated and gold and nickel surfaces are have our assurance of commitment to quality, durability, and hand-finished for lasting beauty and enjoyment. Our pledge performance. -
Page 3: Table Of Contents
MT. VERNON AE INSERT Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided may result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury. • NOTICE: Indicates practices which may cause damage to the appliance or to property. -
Page 4: Warranty Policy
MT. VERNON AE INSERT Castile Pellet Insert C. Warranty Policy Hearth & Home Technologies Inc. LIMITED LIFETIME WARRANTY Hearth & Home Technologies Inc., on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance... - Page 5 MT. VERNON AE INSERT Castile Pellet Insert WARRANTY CONDITIONS: �� ���������������������������������������������������������������������������������������������������������������������� ���������������������������������������������������������������� �� ������������������������������������������������������������������������������������������������� �� ���������������������������������������������������������������������������������������������������������������������������� ��������������������������������������������������������������������������������������������������������������������� ����������������������������������������������������������������������������������� �� ������������������������������������������������������������������������������������������������������������������� ������������������������������������������� WARRANTY EXCLUSIONS: ������������������������������������������� �� ��������������������������������������������������������������������������������������������������������������������� ������������������������������������������������������������������������������������������ �� �������������������������������������������������������������������������������������������������������������������� ����������������������������������������������������������������������������������������������������������������� �� ���������������������������������������������������������������������������������������������������������������� �������������������������������������������������������������������������������������������������������������������������- ��������������� �� �������������������������������������������������������������������������������������������������������������- ��������������������������������������������������������������� �� ����������������������������������������������������������������������������������������������������������������������� �������������������������������������������������������������������������������������������������������������������������� ��������������������������������������������������������������������������������������������������������������������- ���������������������������������������������������������������������������������������������������������������...
-
Page 6: Listing And Code Approvals
Improper installation, adjustment, alteration, service or Shipping Weight: 425 lbs maintenance can cause injury or property damage. For assistance or additional information, consult a qualified *BTU will vary, depending on the type of fuel you use in your installer, service agency or your dealer. appliance. Consult your Quadra-Fire dealer for best results. NOTE: Hearth & Home Technologies, manufacturer of this appliance, reserves the right to alter its products, their specifications and/or price without notice. C. Glass Specifications This stove is equipped with 5mm ceramic glass. Replace Quadra-Fire is a registered trademark of Hearth & Home glass only with 5mm ceramic glass. -
Page 7: Operating Instructions
MT. VERNON AE INSERT User Guide Operating Instructions Fuel Material WARNING • Made from sawdust or wood by-products • Shelled field corn & other biomass fuels Fire Risk. • Depending on the source material it may have a high or • Do not operate appliance before reading and low ash content. understanding operating instructions. Higher Ash Content Material • Failure to operate appliance properly may cause a house fire. • Hardwoods with a high mineral content • Fuel that contains bark A. Fire Safety • Standard grade pellets, high ash pellets, corn and other To provide reasonable fire safety, the following should be biomass fuels given serious consideration: Lower Ash Content Material... -
Page 8: General Operating Information
MT. VERNON AE INSERT E. General Operating Information Size • Pellets are either 1/4 inch or 5/16 inch (6-8mm) in diameter Read and understand the Thermostat Wall Control • Length should be no more that 1-1/2 inches (38mm) manual for detailed operating instructions. The wall con- • Pellet lengths can vary from lot to lot from the same trol is an integral part of how to operate this appliance. -
Page 9: Before Your First Fire
MT. VERNON AE INSERT F. Before Your First Fire 2. Comfort Level Selection • First, make sure your appliance has been properly installed Once your fuel is selected, select the temperature at the desired and that all safety requirements have been met. setting on the SET COMFORT LEVEL screen. Figure 9.2. • Pay particular attention to the fire protection, venting and thermostat wall control installation instructions. • Double check that the ash pan, hopper and firebox are empty and then close the firebox door. NOTICE: The tip of thermocouple must be in contact with the Figure 9.2 inside end of the thermocouple cover or missed ignitions can occur. -
Page 10: Battery Back-Up System (Optional)
MT. VERNON AE INSERT J. Battery Back-up System (Optional) Wall Control Display The wall control will display the battery icon when operating in the battery back-up mode. Figure 10.2 CAUTION! • Hook up to battery terminals BEFORE you plug battery “Maint Burn” will display when into appliance. the thermostat has reached the • Damage to internal electronic components may occur. set room temperature and will run on low until it reaches its auto-clean cycle time. -
Page 11: Ignition Cycles
MT. VERNON AE INSERT L. Ignition Cycles 2. Soft Start Cycle (SS-Low / SS-Med) The appliance engine is controlled by the digital thermostat Once the fire is lit: wall control. The digital display on the wall control will tell • The appliance moves into the low soft-start cycle as it you what your appliance is doing in the upper left corner continues to build the fire (System Status). Figure 11.1. -
Page 12: Insert Removal
MT. VERNON AE INSERT 5. Auto-Clean Cycle The firepot auto-clean system will cycle: WARNING • When the appliance is first plugged in Fire Risk • When the house reaches temperature and the appliance Do NOT operate appliance: shuts down • With appliance door open. • With firepot floor open. • At prescribed intervals, depending on the type of fuel se- Do NOT store fuel: lected • Closer than required clearances to com- bustibles to appliance. • When starting up after an electrical interruption • Within space required for loading or ash If your appliance is running and the auto-clean cycle is initi- removal. -
Page 13: Frequently Asked Questions
MT. VERNON AE INSERT N. Frequently Asked Questions ISSUES SOLUTIONS 1. Metallic noise 1. Noise is caused by metal expanding and contracting as it heats up and cools down, similar to the sound pro- duced by a furnace or heating duct. This noise does not affect the operation or longevity of your appliance. 2. Ash build-up on glass 2. This is normal. Clean the glass. Glass has turned dirty 3. Excessive build up of ash. The lower burn settings will produce more ash, the higher burn settings produce... -
Page 14: Wall Control Operating Instructions
AUTO: (x) or MAN: (x) (x) = heat output level The Quadra-Fire Wall Control is not just a traditional ther- mostat, but an integral part of the pellet appliance system. Indicates both the operating cycle (automatic or manual) While it has many of the features one would expect from and the current heat output level. -
Page 15: General Information About Using The Wall Control
MT. VERNON AE INSERT “Set at:” indication will change to “Hold at:” and displays the 1. Set Comfort Level (Temperature) operating temperature setting. The most basic operation of the wall control is to turn the 4. Notification Icons appliance on or off depending on the requirement for heat. From the main screen, the SET COMFORT LEVEL screen The system notification area uses icons to indicate if an ac- can be activated by pressing the UP or DOWN button on the tion needs to be taken. In battery mode it indicates the ap- right side of the display area. - Page 16 MT. VERNON AE INSERT To select a fuel type, use the UP/DOWN buttons to scroll to AUTO/MANUAL SETTINGS the desired fuel type and then press the button under “Se- Automatic lect”. The arrow will change to indicate the currently select- Manual ed fuel. NOTE: If you are burning a high ash fuel set the fuel selec- tion to “Utility Pellets”. Figure 16.1 When purchasing corn or wheat to burn in your appliance, read the ingredient label very carefully. Do NOT purchase b. Manual fuel that contains any additives such as oils (i.e. soybean In MANUAL cycle, the heat output remains the same oil) and meals as it will result in poor appliance performance.
- Page 17 MT. VERNON AE INSERT When the screen is first entered the “Wake Hour” is high- lighted. Use the UP/DOWN buttons to adjust the hour to the desired hour and press the button under “Set/Next”. Wednesday The highlight will move to the minutes display. Adjust the minutes and press “Set/Next.” The highlight is now on the temperature value. Set the desired temperature for the Wake period and press “Set/Next.” Figure 17.6 The highlight is now on the hour display for the Day peri- b.
- Page 18 MT. VERNON AE INSERT b. Flame Height Adjust f. Elevation FLAME HEIGHT ADJUST is used to adjust flame height (fuel ELEVATION allows you to adjust the appliance to your feed rate) for specific installation and fuel type. The dealer specific elevation. Press the UP/DOWN buttons to select will usually adjust this if necessary on installation and can your elevation. The message in the center will change advise on specific settings for a particular application.
-
Page 19: Quick Start Guide
MT. VERNON AE INSERT F. Quick Start Guide Any button pressed will turn on the backlight. Wall control will automati- NOTICE: cally revert back to the starting screen if there is no activity for 15 seconds; except for the “CONFIRM FUEL CHANGE” screen. CHOOSING FUEL TYPE CHOOSING TEMP UNIT: °F or °C Buttons READY 12:30 PM Set at: 68 READY 12:30 PM Down Set at: 68 MENU HEAT OUTPUT MENU 1. At the starting screen, press “MENU” HEAT OUTPUT Wall Control for Reference button once or twice until “MENU”... - Page 20 MT. VERNON AE INSERT SETTING HEAT OUTPUT HOPPER OUT OF FUEL SETTING COMFORT LEVEL ERROR LIST READY 12:30 PM READY 12:30 PM Min Firepot Temp Set at: 68 Set at: 68 MENU HEAT OUTPUT MENU HEAT OUTPUT At the starting screen, press “HEAT 1. Press and hold “UP” or “DOWN” but- SERVICE RETRY...
-
Page 21: Service Information
MT. VERNON AE INSERT Refer to page ___ for instructions on how to attach the cable G. Service Information to appliance. The following are screens you will see when The SERVICE INFORMATION screen displays contact in- using a back-up battery. formation for Hearth & Home Technologies Customer Ser- Operating on Battery Back-Up vice Line. The local dealer may have changed this upon or •... -
Page 22: Maintenance And Service
MT. VERNON AE INSERT Maintenance and Service When properly maintained, your fireplace will give you Before Servicing Your Appliance many years of trouble-free service. Contact your dealer to CAUTION! SHOCK AND SMOKE HAZARD! answer question regarding proper operation, troubleshoot- ing and service for your appliance. Visit www.quadrafire. • Proper Shutdown Procedure must be followed. com to find a dealer. We recommend annual service by a • Smoke spillage into room can occur if appliance is not qualified service technician. cool before unplugging appliance. • Risk of shock if appliance is not turned off before servic- A. Proper Shutdown Procedure ing appliance. 1. Set wall control to OFF on AUTOMATIC / MANUAL SET- TING screen. Figure 22.1. 2. -
Page 23: General Maintenance And Cleaning
MT. VERNON AE INSERT 2. Ash Removal from Firebox C. General Maintenance and Cleaning • Frequency: Weekly or more frequently depending on ash build-up 1. Auto-Clean System Inspection & Cleaning • By: Homeowner • Frequency: Monthly or every ton (aprx. 50 bags) or Be sure the wall control screen says OFF and the more frequently depending on the type of fuel appliance is allowed to cool. - Page 24 MT. VERNON AE INSERT 5. Cleaning Firepot with Firepot Clean-Out Tool Tools Needed: A Shop Vac and generic micro cleaning kit; flat head and Phillips screwdriver; 11/32 Nut-driver or • Frequency: wrench. Softwood Pellets: Weekly or every 5 bags Hardwood Pellets: Weekly or every 3 bags Alternate Fuel: Daily or every 1 bag • By: Homeowner a. Be sure the wall control screen says OFF and the appliance is allowed to cool.
- Page 25 MT. VERNON AE INSERT c. Assemble the crevice tool from the micro cleaning kit to f. Removing the Combustion (Exhaust) Blower attach to a Shop Vac. Figure 25.1. 1. The combustion blower is mounted in the bottom right rear of the appliance. Figure 25.3. 2. Remove side panel and then using an 11/32 nut driver to loosen all six nuts, but do not remove. Rotate the blower and remove from the housing. Figure 25.4. 3. Set the blower on the top of the housing. You do not need to disconnect the wires.
- Page 26 MT. VERNON AE INSERT 7. Cleaning the Hopper 9. Door Latch Inspection • Frequency: Monthly or after burning 1 ton of fuel, • Frequency: Prior to heating season (aprx 50 bags) or when changing fuel types • By: Homeowner • By: Homeowner The door latch is non-adjustable but the gasketing between the glass and firebox should be inspected periodically to make a. Be sure the wall control screen says OFF and the appliance sure there is a good seal. If the gasket is frayed or damaged, is allowed to cool. replace with a new one. b. After burning approximately 1 ton of fuel you will need to clean the hopper to prevent sawdust and/or fines build-up.
-
Page 27: High Ash Fuel Content Maintenance
MT. VERNON AE INSERT D. High Ash Fuel Content Maintenance • Frequency: When the ash build-up exceeds the half way point in the firepot • By: Homeowner If the ash build-up exceeds the half way point in the firepot before it automatically cleans, then the firepot is not being cleaned often enough. Another symptom is if clinkers are adhering to the sides of the firepot. Double check the wall control to ensure the proper setting has been selected for the fuel you are burning. If that is correct, change the setting to “Utility Pellet”. NOTE: You will need to empty the ash pan more fre- quently if using the “Utility Pellet”... -
Page 28: Troubleshooting Guide
MT. VERNON AE INSERT Troubleshooting Guide With proper installation, operation, and maintenance your appliance will provide years of trouble-free service. If you do experience a prob- lem, this troubleshooting guide will assist a qualified service person in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualified service technician. Error Message Possible Cause Corrective Action Bad wall control or control board Replace wall control or control board 3 wires have loose connections or installed Check connections wrong BAD TC DROP TUBE Drop tube thermocouple is broken or leads are Check connections reversed (TC = Thermocouple) Replace thermocouple BAD TC FIREPOT Firepot thermocouple is broken or leads are Check connections reversed Replace thermocouple (TC = Thermocouple) SNAP DISC TRIPPED Overheat sensor (snap disc) has tripped Turn power off to appliance and manually... -
Page 29: Service Parts Replacement
MT. VERNON AE INSERT Service Parts Replacement A. Baffle Removal B. Glass Replacement The appliance must be in complete shutdown, com- a. Swing open the face and remove the door from the pletely cool and the exhaust blower off. appliance by lifting the door off of the hinge pins and lay on a flat surface face down. b. Open door. b. Using a Phillips head screw driver, remove 4 screws, 2 c. The baffle is located at the top inside of firebox. on the top and 2 on the bottom. Remove metal bracket d. -
Page 30: Convection Blower Replacement
MT. VERNON AE INSERT C. Convection Blower Replacement Follow the proper shut down procedures as outlined on page 35, Section 10.A. Removal of Cast Sides You will need to remove the cast sides in order to remove Notch and replace the convection blower. 1. There is a latch on the back side of the cast side in the Latch middle of the top opening of the cast side as indicated in Figure 30.1. -
Page 31: Reference Materials
MT. VERNON AE INSERT Reference Materials A. Component Functions When describing the location of a component, it is always AS YOU FACE THE FRONT OF 1. Auto-Clean Motor THE APPLIANCE. The auto-clean motor is located under and behind the 9. Firepot firepot on the left side, inside the convection air chamber. It automatically opens and closes the firepot floor so ashes can The firepot is made of high quality ductile iron. The floor of... - Page 32 MT. VERNON AE INSERT 17. Power Supply 21. Vacuum Switch The power supply is located at the rear of the appliance. It The vacuum switch is located on the right side of the appliance converts 120 volt AC current to 15 volt DC current to power under the feed motor behind right side panel and connects to the appliance.
-
Page 33: Component Locations
MT. VERNON AE INSERT B. Component Locations Low Fuel Indicator Drop Tube Door Switch Control Convection Board Blower Exhaust Blower Auger Optical Switch behind Feed Motor Feed Motor Vacuum Power Supply Switch Figure 33.2 - Power Supply, Control Board, Convection Blower Re-set Button... -
Page 34: Exploded Drawings
C. Exploded Drawings MT VERNON INSERT-AE Service Parts Beginning Manufacturing Date: Sept. 2006 Advanced Energy Pellet Insert Ending Manufacturing Date: Active MTVERNINSAE-CSB, MTVERNINSAE-MBK, MTVERNINSAE-PMH MTVERNINSAE-CWL (Sept 2006 thru June 2011) Part number list on following pages. 03/13 7036-187 January 29, 2014... -
Page 35: Service Parts List
MT. VERNON AE INSERT MT VERNON INSERT-AE Service Parts Beginning Manufacturing Date: Sept. 2006 Ending Manufacturing Date: Active D. Service Parts List IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. at Depot ITEM DESCRIPTION COMMENTS PART NUMBER Matte Black 7036-107MBK Sienna Bronze 7036-107CSB Hopper Lid Willow 7036-107CWL Mahogany 7036-107PMH... - Page 36 MT. VERNON AE INSERT MT VERNON INSERT-AE Service Parts Beginning Manufacturing Date: Sept. 2006 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. at Depot ITEM DESCRIPTION COMMENTS PART NUMBER #19 Door Assembly 19.1 19.7 19.6 19.2 19.5 19.3 19.4 Door Assembly 7034-006 19.1 Hinge, Female...
- Page 37 MT. VERNON AE INSERT MT VERNON INSERT-AE Service Parts Beginning Manufacturing Date: Sept. 2006 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. at Depot ITEM DESCRIPTION COMMENTS PART NUMBER Combustion Blower Assembly 7034-033 Gasket, Blower, Combustion (Between …) ...Housing & Stove SRV7000-332 Gasket, Motor, Blower, Combustion (Between …) ...Housing & Motor SRV7000-714 Control Board Assembly SRV7000-456 Fuse 15A Slow Iec Glass Pkg of 10 7000-491/10 Convection Blower...
- Page 38 MT. VERNON AE INSERT MT VERNON INSERT-AE Service Parts Beginning Manufacturing Date: Sept. 2006 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. at Depot ITEM DESCRIPTION COMMENTS PART NUMBER #40 Auto-Clean Motor/Arm Assembly #39 Firepot Riser Assembly 39.1 39.2 39.3 39.4 39.5 40.1...
- Page 39 MT. VERNON AE INSERT MT VERNON INSERT-AE Service Parts Beginning Manufacturing Date: Sept. 2006 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. at Depot ITEM DESCRIPTION COMMENTS PART NUMBER Adaptor, TPVNT-4 Bracket, Control Board 7034-212 Bracket, Door Switch 7034-215 Bracket, Hopper Switch 7036-148 Bracket, Snap Disc 7034-150 Bracket, Vacuum Switch 7034-211 Matte Black 7036-018...
- Page 40 MT. VERNON AE INSERT MT VERNON INSERT-AE Service Parts Beginning Manufacturing Date: Sept. 2006 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. at Depot ITEM DESCRIPTION COMMENTS PART NUMBER Top Mount Left SRV7036-117 Top Mount Right SRV7036-115 Vacuum Hose - Field Cut to Size 3 Ft.
- Page 41 MT. VERNON AE INSERT MT VERNON INSERT-AE Service Parts Beginning Manufacturing Date: Sept. 2006 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. at Depot ITEM DESCRIPTION COMMENTS PART NUMBER Accessories 12 Volt Power Cord 12VCORD-AE Damper, 3 Inch - Tall Vertical Installs Only PEL-DAMP3 Damper, 4 Inch - Tall Vertical Installs Only PEL-DAMP4 Firescreen SCR-7005 Hearth Support ZCSPT-MVI Log Set (2 Pc) Sold as set only...
-
Page 42: Homeowner's Notes
MT. VERNON AE INSERT E. Homeowner’s Notes 7036-187 January 29, 2014... - Page 43 MT. VERNON AE INSERT January 29, 2014 7036-187...
-
Page 44: Contact Information
CONTACT INFORMATION Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafire.com CAUTION DO NOT DISCARD THIS MANUAL Read, understand and Leave this manual with • Important operating and •...
