6 in Top/Rear Vent (152mm) 3 in. (76mm) Back of Hopper 2.75 in. (70mm) Outside Air...
Page 9
3.0 in (76mm) 3.0 in (76mm) 7.5 in (191mm) Use two 45 degree elbows to clear heat shield and hopper.
Page 11
WARNING! Risk of Fire! NOTICE: In Canada when using a factory-built chim- ney it must be safety listed, Type UL103 HT (2100 [1149 C] CLASS “A” or conforming to CAN/ULC- S629M, STANDARD FOR 650 C FACTORY-BUILT CHIMNEYS. 250-2061...
Page 12
Electrical Service Inside Corner FIXED FIXED OPEN CLOSED CLOSED OPEN J or K Termination Cap Air Supply Inlet Restricted Area Gas Meter...
Page 17
NOTE; Use metal plate around exhaust vent pipe and seal all edges with non-flammable insu- lation such as mineral wool or ceramic. Do not use high temperature caulking materials to seal any edge to prevent furture service- ability. Outside Air through Rear Wall (Horizontal)
Page 18
305mm min. above 305mm min. below NOTE; Use metal plate around exhaust vent pipe and seal all edges with non-flammable insula- tion such as mineral wool or Outside Air Termination ceramic. Chimney Top Do not use high temperature caulk- ing materials to seal any edge to (Vertical) prevent furture serviceability.
Page 21
9 attachment holes - 3 on each side and 3 in the front...
“Maint Burn” will display when the thermostat has reached the set room temperature and will run on low until it reaches its auto-clean cycle time. MAINT BURN 12:30 PM Set at: 73 MENU HEAT OUTPUT Battery icon. Battery 13 Volts 12 Volts 11 Volts Below...
Page 29
System Status 12:30 PM READY Set at: 73 MENU HEAT OUTPUT...
Page 31
Buttons 12:30 PM READY READY 12:30 PM Set at: 73 Set at: 68 Room READY 12:30 PM Down Temp MENU HEAT OUTPUT Set at: 68 MENU Function Buttons MENU MENU Set Comfort Level Auto/Manual/Off Fuel Type MENU READY 12:30 PM User Settings Set Comfort Level Set at: 68...
ERROR LIST READY 12:30 PM READY 12:30 PM Min Firepot Temp Set at: 68 Hold at: Set at: 74 MENU MENU HEAT OUTPUT HEAT OUTPUT RETRY SERVICE Medium High ºF 12:30 PM SHUTDOWN Hold at: Set at: 74 SET COMFORT LEVEL ºF MENU HEAT OUTPUT...
Page 38
Loosen all 6 nuts, but do NOT Remove Vacuum out the exhaust area.
Page 44
Heat sinks are taped to cover for shipping. Slowly lift cover and cut the tape holding them in place and then you can remove the cover. Fuse 15A 250V Input Line Input Line Voltage 15V DC out to Voltage AC out to Control Control Board Board Power Supply shown with cover removed...
