Basic Information
Forwarding Throughput
Packet Types
Packet Length
Flow Control
Mechanical
Dimension
Housing
Mounting
Weight
Environmental
Operating Temperature
Storage Temperature
Relative Humidity
Certificate
FCC
CE/EMC
CE/LVD

1.3 Optical Specifications

The media converter series provides the following fiber options:
Full wire speed at 100M full duplex
10Mbps - 14,880 pps at 64-byte packets
100Mbps - 148,800pps at 64-byte packets
Transparent and no modification for
- IEEE 802.3 standard packets
- IEEE 802.1Q VLAN tagged packets
Up to 1522 bytes at store-and-forward mode
No limit at smart-forward mode 100to100
Back-pressure for half-duplex mode
802.3x pause-frame base for full duplex mode
H 23mm x W 72.5mm x D 108mm
Enclosed metal with no fan
Desktop, Wall mount, Center chassis
210g
o
o
-5
C ~ 50
C
o
o
-20
C ~ 60
C (for NC-300D-EC model)
o
o
-20
C ~ 85
C
5% ~ 90%
Part 15 Class B
EMI EN50081-1 Class B, EMS EN55024
EN 60950
-8-
