Page 6-9, Figure 6-1, change PEN SCALE part no.'s to:
BLANK 07035-60185
Page 7-7, Table 7-1, new item 33 to read:
33. Pen won't write
8-14.
CHANGE VI
8-15.
X CAL. Page 6-5, Table 6-1, change R-225 to:
R-225
0698-3250
Page 7-9, Figure 7-3, X AXIS BLOCK, change value of
R225 to 1.71k.
8-16.
CHANGE VII
8-17.
COLOR SCHEME. Page 1-3, Figure 1-4,
change trim to aluminum.
PEN SCALE BLANK 07035-60180; ENGLISH 07035-60181; METRIC 07035-60182
REAR HOOD ASSY ENGLISH 07035-60020; METRIC 07035-60021
ENGLISH 07035-60186
a. Pen tip clogged.
b. Pen reservoir empty.
Resistor, Mtl Flm, 1.71k 1%, 1/8W
METRIC 07035-60250
a. See paragraph 5-18B.
b. Fill with ink (See Figure 3-3.).
Int'l Resist.
Page 6-11, Figure 6-2 (Legend), change item 48 to read:
48
0035-60180
07035-60181
07035-60182
Page 6-9, Figure 6-1, change the following:
CEA T-2.
Pen Scale Assy - Blank
Pen Scale Assy - English
Pen Scale Assy - Metric
8-7(8-8 blank)
