This section provides information on serial prefixes
below 845. Table 8-1 is a tabular presentation of the serial
prefix numbers and the corresponding change numbers. To
adapt this manual to the instrument on hand, determine the
serial prefix of the instrument, then refer to Table 8-1 and make
the appropriate changes to the manual.
TABLE 8-1. SERIAL PREFIX/CHANGE
NUMBER REFERENCES
Serial Prefix
1113A-1049A
1048A-1040A
1039A-1025A
1024A-1017A
1016A-926
925-845
844 and Below
8-4.
CHANGE I
8-5.
COLOR SCHEME. Page 1-3, Figure 1-4, change trim
to Light Gray.
SECTION VIII
BACKDATING
Change
I
I, II
I, II, III
I, II, III, IV
I thru V
I thru VI
I thru VII
Page 2-2, Figure 2-1, change Rack Mount Brackets part no. to
07035-00490.
Page 6-3, Table 6-1, change J-601 part no. to 8120-3148.
Page 6-6, Table 6-2, Spare Parts, change the following items:
Power Cord, 8120-1348; Panel - Side - RH & LH, 07035-
00071; Panel - Front and Rear, 07035-00061; Rear Hood Assy
- Stnd, 07035-62570; Rear Hood Assy - Metric, 07035-62571.
Page 6-11, Figure 6-2, items 47 and 48 part no.'s are:
47 Block, Pen Arm, 07034-60320; 48 Pen Scale Assy - Eng,
07034-60210 and Pen Scale Assy - Met - 07034-60200
Page 6-9, Figure 6-1, make the following changes:
Pen Scale - Eng, 07034-60210; Pen Scale - Met, 07034-
60200; Rear Hood Assy - Eng, 07035-62570; Rear Hood - Met,
07035-62571; Panel Rear, 07035-00061; Panel RH, 07035-
00071; Rear Corner - RH, 07035-40030; Front Corner - RH,
07035-20150; Rear Corner - LH, 07035-40040; Panel - Front,
07035-00061; Front Corner - LH, 07035-40021; and Panel -
LH, 07035-00071.
Page 7-9, Figure 7-2, use the following Component ID
illustration:
