XGT Panel

User's Manual

XP30-BTE

XP30-BTA

XP30-TTE

XP30-TTA

XP40-TTE

XP40-TTA

XP50-TTE

XP50-TTA

XP70-TTA

XP80-TTA

XP90-TTA

http://eng.lsis.biz

Table of Contents

Need help?

Do you have a question about the XP30-BTE and is the answer not in the manual?

Questions and answers

Summary of Contents for LSIS XP30-BTE

Page 1 Right choice for ultimate yield LSIS strives to maximize customers' profit in gratitude of choosing us for your partner. Human Machine Interface XGT Panel XGT Panel Series User’s Manual XP30-BTE XP30-BTA XP30-TTE XP30-TTA XP40-TTE XP40-TTA XP50-TTE XP50-TTA XP70-TTA XP80-TTA XP90-TTA...
Page 2 Safety Precautions Before using the product… To use the product safely and effectively, please read this instruction manual thoroughly before use. ► Please keep to the safety precaution, for it is to prevent accidents and potential danger from occurring. ► Safety precaution is classified into ‘Warning’ and ‘Caution’ and their meanings are as follows. Warning Violating the instruction may result in serious personal injury or death.
Page 3: Installation Precautions
Safety Precautions Design Precautions Warning Install a safety circuit external to the HMI to protect the whole control system in case of external power supply trouble. Serious trouble may occur to the entire system due to erroneous output/operation of the HMI. Design Precautions Caution In/output signal or communication cable should be at least 100mm apart from...
Page 4 Safety Precautions Wiring Precautions Warning Be sure to turn off the HMI and external power before wiring. Otherwise, it may result in an electric shock or damage to the product. Caution Wire correctly by checking each of the product’s rated voltage and terminal layout. Otherwise, it may result in fire, electric shock or erroneous operation.
Page 5 Safety Precautions Startup and Maintenance Precautions Warning Do not touch the terminals while power is on. Otherwise, it may cause electric shock or erroneous operation. Turn off the PLC and external power when cleaning or tightening the terminal. Otherwise, it may cause electric shock or erroneous operation. Do not charge, disassemble, heat, short circuit, solder, etc.
Page 6 8. Project upload function by external storage equipment added 9. Update function by external storage equipment added 10. XP30-BTE interface added 11. Figure and name of each part for XP30-BTE added 12. Specification of XP30-BTE added 13. Aux diagnosis function added 14.
Page 7: Table Of Contents
Contents Chapter. 1 General Introduction ..................1-1~1-6 1.1 Usage of User Manual ..............................1-1 1.2 Feature ..................................1-2 1.3 Terminology ................................... 1-6 Chapter. 2 System Configuration ..................2-1~2-6 2.1 Name and Function of Each Part ..........................2-1 2.2 System Configuration ..............................2-5 Chapter.
Page 8 Contents 6.1 Connection Information ..............................6-2 6.2 PLC Information ................................6-3 6.3 History of PLC Error ..............................6-4 6.4 History of PLC Mode Conversion ..........................6-5 6.5 History of PLC Power ..............................6-6 6.6 History of PLC System ............................... 6-7 6.7 PLC Communication Configuration Settings ......................
Page 9 Contents Chapter. 12 EMC Standard Certification ..............12-1~12-2 12.1 Requirement for EMC Standard Certification ......................12-1 12.1.1 CE standard certification ..........................12-1 12.1.2 MIC standard certification ..........................12-2 12.2 Requirement for Low Voltage Command Suitability ....................12-2 12.2.1 Standard applied for XGT Panel ........................12-2 12.2.2 Selection of XGT Panel ..........................
Page 10: Chapter. 1 General Introduction
Chapter 1. General Introduction Chapter 1. General Introduction 1.1 Usage of User Manual This manual provides information of each product’s specification, usage and so on. This is necessary to use XGT Panel for medium and large HMI system. The user manual’s configuration is as follows. Sequence Category Contents...
Page 11: Feature
Chapter 1. General Introduction 1.2 Feature XGT Panel has the following features. Diverse external interface (a) It maximizes custom’s use by providing diverse external interface including USB, CF card and Ethernet. Expansion connector CF card Communication Memory Interface Module Logging data Image/font data USB host Etc.
Page 12 Chapter 1. General Introduction (c) XP30-BTE(TTE), economic type, is not supported for Ethernet, expansion connector and CF card. Battery Cover RS232C USB Port RS422/RS485 Terminal Block Type Based on Windows CE (a) Adoption of Microsoft Company’s Windows CE • Windows CE 5.0 (b) Advantage •...
Page 13 Chapter 1. General Introduction • It adopts TFT LCD which supports the 65,536 colors. (XP30-BTE/DC and XP30-BTA/DC adopts STN Mono LCD.) (b) It provides diverse graphic type. • It is available to express precisely and actually. • It provides the simple moving function with GIF support.
Page 14 Chapter 1. General Introduction Advanced function (a) Alarm function • The History alarm can be classified alarm group and alarm list and selected alarm can be expressed by alarm search. • The Flow alarm indicates current or the latest alarm at the bottom of screen. •...
Page 15: Terminology
Chapter 1. General Introduction 1.3 Terminology It describes terms used in this manual. Term Definition Example Ex.) CPU module A standard element that has a specified function which configures the system. Module Power module, Devices such as I/O board, which inserted onto the mother board or base unit. I/O module A single module or group of modules that perform an independent Ex.) Basic unit,...
Page 16: Chapter. 2 System Configuration
Chapter 2. System Configuration Chapter 2. System Configuration Here describes the feature of XGT Panel and system configuration. 2.1 Name and Function of Each Part 1. 1. 1. 1. XP30-BTA, XP30/50/70/80-TTA Number Name Description 1) Analog touch panel: User touch input ①...
Page 17 Chapter 2. System Configuration Number Name Description Indicates operation status of device Normal RUN status (monitoring, downloading the project data) Green ② LED Status Initializing the status when booting (HMI does not operate) Error occurs (communication error, project data error) ③...
Page 18 When you use the XGT Panel, the prevention tape is installed to prevent battery discharge. If you remove this prevention tape, backup is available. In order to remove tape, pull tape downward like the following figure. Prevention tape 2. XP30-BTE, XP30-TTE, XP50-TTE, XP40-TTA(TTE)
Page 19 Chapter 2. System Configuration Number Name Description 1) Analog touch panel: User touch input Front view ① 2) LCD: screen display Indicates operation status of module. Normal RUN status (monitoring, downloading the project data) LED Status Green ② Initializing mode when booting (HMI does not Ready) Error occurs (communication error, project data error)
Page 20: System Configuration
Chapter 2. System Configuration 2.2 System Configuration In order to use XGT Panel, write project data at the XP-Builder and transmit it to the XGT Panel. XGT Panel can be basically connected through RS-232C. Maximum communication speed is 115,200 [bps]. RS-232C communication speed is not fast so it takes long time to transmit project data into XGT Panel.
Page 21 1) We recommend Ethernet more than RS-232C. 2) For the Ethernet cable manufacture, please refer to the communication manual. 3) For the project transmission method, please refer to the XP-Builder manual. 4) Ethernet is not supported on XP30-BTE, XP30-TTE, XP50-TTE and XP40-TTE.
Page 22: Chapter. 3 Standard Specification
(15G) Shock IEC 61131-2 * Duration time: 11 ㎳ endurance * Pulse wave: half sine pulse (3 shocks per axis, on X, Y, Z axis) AC: ±1,500V LSIS Square wave Standard Impulse noise DC: ±1,000V IEC 61131-2 Electrostatic ± 6 kV (Discharge by contact)
Page 23 However, it also contains the status generating temporarily conduction due to condensation. (3) Radiated electromagnetic field noise for XP30-BTE(TTE) is 80 ~ 1000MHz, 10 V/m (All others are same as shown on the table)
Page 24: Function Standards
Chapter 3. Standard Specification Cooling Air-cooling method 3.2 Function Standards XGT Panel’s function standard is as follows. 1. DC type (1) 5.7 Inches Models Item XP30-TTE/DC XP30-BTE/DC XP30-BTA/DC XP30-TTA/DC Display type TFT LCD STN mono LCD TFT Color LCD Screen size ㎝ (5.7”)
Page 25 Chapter 3. Standard Specification Item XP30-TTE/DC XP30-BTE/DC XP30-BTA/DC XP30-TTA/DC Recipe available Data logging available Script executor available Certifications CE, UL, KC Protection standard IP65F Dimension (mm) 181 x 140 x 56.5 181 x 140 x 66.5 Panel cut (mm) 156 x 123.5 156 x 123.5...
Page 26 Chapter 3. Standard Specification Item XP40-TTE/DC XP40-TTA/DC Multi-language Up to 8 language simultaneously Animation GIF format is available. Recipe Available Data logging Available Script executor Available Certifications CE, UL(cUL), KC Protection standard IP65F Dimension (mm) 203.5x153.5x41.5 Panel cut (mm) 192 x 138 Rated voltage DC24V (19.2 ~ 28.8V) Power consumption (W)
Page 27 Because battery is used when power is off, battery is not consumed when power is on. (5) LCD Backlight replacement : XP40-TTA(TTE)/DC, XP50-TTA(TTE)/DC, XP70-TTA/DC, XP80-TTA/DC, LCD backlight is replaceable. However in XP30-BTE/DC, XP30-TTE/DC, XP30-BTA/DC and XP30-TTA/DC, LCD backlight is not replaceable because LCD and backlight is all-in-one type.
Page 28 Chapter 3. Standard Specification 2. AC Type (1) 10.4/12.1/15 Inches Models Item XP70-TTA/AC XP80-TTA/AC XP90-TTA/AC Display type TFT Color LCD Screen size 26cm (10.4”) 31cm (12.1”) 38cm (15”) Display Resolution 640 x 480 pixel 800 x 600 pixel 1024 x 768 pixel Color indication 65,000 Color Left/Right: 65 deg.
Page 29 F G (Chapter 2.1) is for FG terminal of extension card. ⑤ ⑮ (Except XP30-BTE , XP30-TTE and XP50-TTE) (3) Prevention tape of Battery discharge : There is prevention tape is to prevent the battery discharge. In order to use backup, remove the prevention tape.
Page 30: Chapter. 4 System Configuration
Chapter 4. System Configuration Chapter 4. System Configuration It describes the system configuration including XGT Panel’s time setting, Ethernet connection setting, and connection with PC and backlight. If you press [Settings] button in XGT Panel’s basic screen, you can set XGT Panel’s environment as follows. XGT Panel’s basic screen XGT Panel’s System Configuration screen...
Page 31: Touch Calibration
Chapter 4. System Configuration 4.1 Touch Calibration When the location is not recognized in XGT Panel, Touch’s scale can be adjusted in XGT Panel. If you press [Touch Calibration] button in System Configuration, the setting screen shows up. If you press five ‘+’ marks, XGT Panel’s touch location adjustment is completed.
Page 32: Backlight Setting
Chapter 4. System Configuration 4.2 Backlight Setting If you press [Backlight Setting] button in [System Configuration] screen as follows, setting screen shows up. Against no use for long time through XGT Panel, you can set ‘Automatically turn off backlight’ function. Set whether you use backlight automation On/Off function or not and time, then press OK button as follows.
Page 33: Date Time Setting
Chapter 4. System Configuration 4.3 Date Time Setting If you press [DateTime Setting] button in [System Configuration] as follows, you can set XGT Panel’s data and time. Remark You can set data/time at device information of communication dialog at the XP-Builder. For details, please refer to the XP-Builder’s manual.
Page 34: Pc Connection Setting
Chapter 4. System Configuration 4.4 PC Connection Setting If you press [PC Conn Setting] button in [System Configuration] screen as follows, you can set RS-232C and TCP/IP’s port number to communicate with PC. Remark The condition is set as the above. No other setting is required. But in case of changing RS-232C’s communication speed, change as above.
Page 35: Ethernet Setting
: 192.168.0.1 Gateway : 192.168.0.1 Ethernet is not supported on XP30-BTE If you reboot after pressing [Disable] button, the device will not use Ethernet. In this case, booting speed gets faster. If you use Ethernet again, reboot after pressing [Enable].
Page 36: Contrast Setting (Only For Xp30-Bta/Dc)
Chapter 4. System Configuration 4.6 Contrast Setting (only for XP30-BTA(BTE)/DC) If you press [Contrast Setting] button on [System Configuration] screen, you can adjust mono LCD’s Contrast. UP button increase Contrast, DOWN button decrease Contrast. Contrast value is between 0~100. Adjustment is only available for mono type XP30-BTA/BTE Adjustment is available during operation.
Page 37: Environment Setting
Chapter 4. System Configuration 4.7 Environment Setting If you press [Environment Setting] button in [System Configuration] screen as follows, you can set ‘Auto Goto Screen’ and ‘Buzzer On/Off’. When setting [Auto Goto Screen], XGT Panel is rebooted. Or when downloading the edit data is completed, the screen automatically shows up.
Page 38: Chapter. 5 Diagnostics
Chapter 5. Diagnostics Chapter 5. Diagnostics It describes the diagnosis function for XGT Panel’s communication terminal, screen and touch function. If you press [Diagnostics] button on the XGT Panel’s basic screen, the menu for diagnosis shows up. XGT Panel’s environment setting screen XGT Panel’s basic screen 5.1 Screen Diagnosis If you press [Screen] button, screens continuously change into diverse color with buzzer.
Page 39: Touch Diagnosis
Chapter 5. Diagnostics 5.2 Touch Diagnosis If you touch the screen, the touched location is displayed as follows. If pressing the [OK] button, you can quit the screen. If the touched location is not correct, reset the Touch setting. For detailed information, please refer to the Chapter 4. System Configuration.
Page 40: Flash Memory Diagnosis Function
5.5 CF Card Diagnosis If you press [CF Card] button, the result of diagnosis shows up in the result windows. Remark If ‘Read Disk Information Error!’ occurs, please contact with Customer service center. CF Card is not supported on XP30-BTE, XP30-TTE, XP50-TTE, XP40-TTA(TTE)
Page 41: Serial Communication Diagnosis
Chapter 5. Diagnostics 5.6 Serial Communication Diagnosis If you press [Serial] button, you can diagnose Serial ports which is equipped at XGT Panel. (In case of diagnosis purpose, you have to connect the loop-back terminal at each port.) The followed feature is Loop Back terminal. In case of communication diagnosis, connect as followed feature. The tool port terminal should be made as follows.
Page 42 Chapter 5. Diagnostics The RS-232C port terminal should be made as follows R S R S R S R S - - - - 2 3 2 C 2 3 2 C 2 3 2 C 2 3 2 C R S R S R S R S - - - - 4 2 2 / 4 8 5 4 2 2 / 4 8 5 4 2 2 / 4 8 5...
Page 43: Led Diagnosis
If you press [LED] button, you can check whether LED is converted into designated color or not at the bottom of XGT Panel. 5.8 AUX Diagnosis If you press [Aux Interface] button, you can check the functions of card that is currently connected. ※ Not supported on following models: XP30-BTE(TTE), XP50-TTE, XP40-TTA(TTE)
Page 44: Chapter 6 Viewing Information Of Plc Connection Status
Ch.6 Viewing Information of PLC Connection Status Chapter 6 Viewing Information of PLC Connection Status You can see the diverse information including XGT Panel’s and PLC’s CPU information through View PLC Connection Status Information. [Method] (a) Select [PLC Information] in the menu. (b) Select the designated PLC.
Page 45: Connection Information
Ch.6 Viewing Information of PLC Connection Status 6.1 Connection Information You can check the setting items for the connection with PLC such as Vender of PLC, Target device, Connection type, Connection information and Timeout value in the XP-Builder.
Page 46: Plc Information
Ch.6 Viewing Information of PLC Connection Status 6.2 PLC Information You can check CPU type of PLC, operation mode, state, version, and scan time. Remark The following PLC is available for view of PLC information. - MASTER-K CPU, FEnet, Cnet - GLOFA-GM CPU, FEnet, Cnet - XGK/XGB/XGI CPU, FEnet, Cnet...
Page 47: History Of Plc Error
Ch.6 Viewing Information of PLC Connection Status 6.3 History of PLC Error You can check the PLC Error History. Remark The following PLC is available for viewing Error History. - MASTER-K CPU doesn’t have the Error History. - GLOFA-GM CPU - XGK/XGI CPU - XGB CPU doesn’t have the Error History.
Page 48: History Of Plc Mode Conversion
Ch.6 Viewing Information of PLC Connection Status 6.4 History of PLC Mode Conversion You can check the history about our PLC’s RUN/STOP operation mode. Remark The following PLC is available for viewing PLC operation mode conversion history. - MASTER-K CPU doesn’t have the history about operation mode conversion. - GLOFA-GM CPU - XGK/XGI CPU - XGB CPU doesn’t have the history about operation mode conversion.
Page 49: History Of Plc Power
Ch.6 Viewing Information of PLC Connection Status 6.5 History of PLC Power You can check the history about when PLC was turned on and off Remark The following PLC is available for viewing the history of when our PLC was turned off and on. - MASTER-K CPU doesn’t have the history about when our PLC was turned on and off.
Page 50: History Of Plc System
Ch.6 Viewing Information of PLC Connection Status 6.6 History of PLC System You can check history about PLC system. Remark The following PLC is available for viewing history about system. - MASTER-K CPU doesn’t have the history about system. - Only GLOFA-GM CPU (GM4C) has the history about system. Other CPUs don’t have the history about system. - XGK/XGI CPU - XGB CPU doesn’t have the history about system.
Page 51: Plc Communication Configuration Settings
6.7 PLC Communication Configuration Settings You can select [Settings] button to change PLC communication settings Remark For further information about the settings, please refer to the PLC user manual. [Program Monitor] button is activated in case of LSIS PLC Direct Driver...
Page 52: Chapter 7 Storage Function
Chapter 7. Storage Function Chapter 7 Storage Function 7.1 General Introduction Downloading the user project made in XP-Builder from PC, uploading the project stored in the device to PC, updating the device and etc are available through connection with XGT Panel with Serial cable or Ethernet cable generally. However, when those connections are not available, you can use CF card, USB storage equipment 1.
Page 53: Downloading Project Through The Storage Equipment
Chapter.7 Storage Function 7.2 Downloading Project through the Storage Equipment 1. If you touch [Project Download], the following dialog shows. 2. In case of selecting [USB], the directory list under the path, \USB Storage\XP_Project\ shows. In case of selecting [CF], the directory list under the path, \Storage Card\XP_Project\ shows.
Page 54: Updating The Device Through Storage Equipment
Chapter 7. Storage Function 7.4 Updating the Device through Storage Equipment 1. If you touch [Project Upload], the following dialog shows. 2. In case of selecting [USB], the directory list under the path, \USB Storage\XP_Project\ shows. In case of selecting [CF], the directory list under the path, \Storage Card\XP_Project\ shows.
Page 55: Chapter 8 Xgt Panel S/W Update
3 seconds. After downloading XGT Panel software from LSIS website, make a temporary folder and save it. Designate the folder where the software will be saved in the XP-Builder’s [XGT Panel Update] windows and update XGT Panel by [Send] menu.
Page 56: Chapter 9 File Backup Through External Storage Equipment
Chapter 9. File Backup through External Storage Equipment Chapter 9 File Backup through External Storage Equipment Describes on management function about external storage equipment saving backup data of logging, recipe, and screen image (1) XGT Panel can back up the logging, recipe, and screen image data at CF card or USB storage equipment according to setting in XP-Builder.
Page 57 Chapter 9. File Backup through External Storage Equipment (c) Name of year, month directory includes the firstly created day information under its directory Ex) In case directory is created in 2010, October and includes directory since 15 under, directory’s name is : 2010.10.15.FF FF at end means the directory can save more data created in 2010, October (currently, the number of lower directory is 500 or less)
Page 58: Operation Setting When There Is No Space For Backup
Chapter 9. File Backup through External Storage Equipment (3) The lower directory structure is same as that of logging. (4) Name of screen image backup file includes hour, minute, second information. (a) Backup file is created in bitmap format. (b) File name starts with ‘S’ and includes hour, minute, second, index information. (c) In case backup file is created at the same time in terms of second, index information at the end of file name increases.
Page 59: Monitoring Connection Status Of External Storage Equipment
Chapter 9. File Backup through External Storage Equipment 9.3 Monitoring Connection Status of External Storage Equipment XGT Panels monitors connection status about external storage equipment designated when setting backup path in XP-Builder. The following figure is backup path specified in XP-Builder. In order to use this monitoring function, you have to set about system alarm window...
Page 60 Chapter 9. File Backup through External Storage Equipment In case USB storage equipment (or CF storage equipment) is removed during operation after setting the path for saving Logging backup file as USB storage equipment (or CF storage equipment) and downloading the project into device, the designated system alarm (HS951.0) is set.
Page 61: Chapter 10 Installation And Wiring
Chapter 10. Installation and Wiring Chapter 10 Installation and Wiring 10.1 Installation 10.1.1 Installation environment This machine has high reliability regardless environment. But for reliability and stability, be careful the followings (1) Environment condition (a) Install at the panel which can protect this machine from water and dust. XGT Panel is designed by IP65 Standard in front parts and IP20 Standard in rear parts.
Page 62: Notice In Installing The Panel
Here describes how to install XGT Panel in panel and notice. (1) Panel cut • Before installing the XGT Panel in panel, panel should be made with the following dimension. Unit: [mm] Classification X (Wide) Y (Height) Z (Thickness) XP30-BTE ＋ 1 ＋ 1 XP30-TTE 156.0 123.5 XP30-BTA － 0 －...
Page 63 Chapter 10. Installation and Wiring (2) XGT Panel installation Unit: [mm] • Keep the distance of 100 mm between XGT Panel and panel per each direction. Remark (1) To be affected at a minimum by the electromagnetic waves (radial noise) or heat from other controllers, it needs to keep its distance as the above explanation.
Page 64 • When installing the XGT Panel, consider screen and use of touch. • When you don’t see within the following angle, you may not see clearly. When installing, consider angle. Item Angle (left and right) Upper Lower XP30-BTE 45 deg. 40 deg. 20 deg. XP30-TTE 80 deg.
Page 65 Chapter 10. Installation and Wiring (4) Fixation • Fix the XGT by using the bracket as follows. (The bracket is included in the product.) Fix through Panel Bracket Fix through bracket Fix through bracket Fix through bracket Remark Please remove a protective film attached to the screen when launching a product. Modification of the protective film can cause the touch malfunction or error in input.
Page 66: Wiring
Chapter 10. Installation and Wiring 10.2 Wiring It describes the wiring that you should know when installing the XGT Panel. 10.2.1 Power wiring XGT Panel is divided into the DC product and the AC product. Power Name XP30-BTA(BTE)/DC XP30-TTA(TTE)/DC XP40-TTA(TTE)/DC DC 24V XP50-TTA(TTE)/DC XP70-TTA/DC...
Page 67 Chapter 10. Installation and Wiring The power terminal should have the following specification. Ø3.2 Ø3.2 Less than Less than 6.00mm 6.00mm The power cable should have the following specification. Type Cable specification (Unit: ㎟㎟㎟㎟ Power and protection ground 1.5 (AWG16) ~ 2.5 (AWG12) Remark (1) Because of voltage down, we recommend the thick stranded cable (more than 2 ㎟...
Page 68 Chapter 10. Installation and Wiring AC Power Ground 100~220 V A C 1 0 0 ~ 2 4 0 V 전 원 입 력 AC power connection Remark (1) When the regulation of power is bigger than provision, use the constant voltage transformer. (2) In case power has much noise, use the insulation transformer.
Page 69 Chapter 10. Installation and Wiring Against the surge and lighting, use the surge absorber as follows. XGT Panel Surge absorber to prevent the lighting Remark (1) Separate the surge absorber’s ground (E1) from XGT Panel’s ground (E2). (2) Select a surge absorber so as not to exceed the maximum permissible voltage of a surge absorber even if power voltage rises to maximum When noise invades, use the insulation shield Trans or noise filter.
Page 70: Ground Wiring
Chapter 10. Installation and Wiring 10.2.2 Ground wiring (1) Our XGT Panel has enough anti-noise measure, so except that there are many noises specially, the ground is not needed. When doing ground, please refer to the followings. (2) The ground should be the exclusive ground. The ground should be type 3 ground (ground resistor is less than 100Ω).
Page 71: Chapter. 11 Maintenance
Chapter 11. Maintenance Chapter 11 Maintenance To keep the XGT Panel best, examine the XGT Panel. 11.1 Maintenance Because an error may be developed by environment, the periodic maintenance is needed. You should check the following categories once or twice every 6 months. Maintenance category Judgment standard Measure...
Page 72: Periodical Maintenance
Chapter 11. Maintenance 11.3 Periodical Maintenance Check the followings once or twice every six months and take measure. Maintenance category Maintenance method Judgment standard Measure Surrounding 0 ~ 50 °C Modify it to meet the general temperature Measure through standard. Environment Surrounding humidity temperature/Hygrometer...
Page 73 (2) LCD backlight’s exchange is available for only XP50-TTA, XP70-TTA, XP80-TTA, XP90-TTA. In case of XP30-BTE, XP30- BTA, XP30-TTA, you have to exchange the LCD when error occurs or product life is finished because LCD and backlight is one product.
Page 74: Chapter 12 Emc Standard Certification
Chapter 12. EMC Standard Certification Chapter 12 EMC Standard Certification 12.1 Requirement for EMC Standard Certification EMC command is regulated on “It doesn’t produce the Strong electromagnetic waves: Emission” and “It is not affected by electromagnetic wave from external: Immunity”. The following is describing the contents to meet the EMC command when configuring the system by using the XGT Panel.
Page 75: Requirement For Low Voltage Command Suitability
Chapter 12. EMC Standard Certification Directive: Electromagnetic Compatibility Directive 89/336/EEC amended by the Directive 93/68/EEC 12.1.2 KC standard certification The XGT Panel acquire the electromagnetic fitness registration (KC specification) certified by wave laboratory under information- communication part. A grade device This device acquires KC for business.
Page 76: Appendix 1 Troubleshooting
Appendix 1. Troubleshooting Appendix 1 Troubleshooting 1. 1. 1. 1. Type of Problem It classifies problems from XGT Panel including an indicated figure, indication of the object, and problems appeared when downloading. Refer to the following chart. Classification of problem Description Problem when starting Malfunction when starting.
Page 77: Reaction Problem When Touching
Appendix 1. Troubleshooting 3. Reaction Problem when Touching When touching the screen it reacts in a different area or it may not react at all? Phenomenon: When touching the screen it reacts in a different area or it may not react at all. <Reason>...
Page 78 Appendix 1. Troubleshooting 4. Display Problem of Figure and Object The shape of object is not shown or the number or character value which has to be shown is not shown. Phenomenon: The shape of object is not shown or the number or character value which has to be shown is not shown. <Reason>...
Page 79 Appendix 1. Troubleshooting Object type Phenomenon History Alarm Viewer Change doesn’t occur. When communication is abnormal, alarm occurs because it can’t know the status of alarm target device. But previous alarm data shows up as it is. Data list Value is not shown. Lattice of viewing data list of object is shown as it is. Logging Viewer Change doesn’t occur.
Page 80: Communication Problem
Appendix 1. Troubleshooting The object always shows up above the figure. Phenomenon: I downloaded the figure above the object in XP-Builder, but the object always shows up above the figure. <Reason> 1) In XGT Panel, The object always shows up above the figure. <Solution>...
Page 81: Cf/Usb Removal Of Memory Card
Appendix 1. Troubleshooting 6. CF/USB Removal of Memory Card When removing the CF/USB memory card, device is stopped for some times. Phenomenon: This happens when doing data backup including logging, recipe. <Reason> 1) This happens because memory card is removed when doing data backup. <Solution>...
Page 82: Error Message During Execution Of Program
Appendix 1. Troubleshooting 7. Error Message during Execution of Program In case that problems occur during execution of XGT Panel including the start of device, diagnosis of device and environment setting, project download, monitoring of control device, and error messages occur as type of box. At this time the message indicates the code made by 4 digit number.
Page 83 Appendix 1. Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address contact the near Customer Service Center. There is password in the each object. When editing the project downloaded in the present Switch XGT Panel Invalid password. device, input the designated password at the project property information.
Page 84 Appendix 1. Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address This message shows up when making it There's not Password newly because there is no password setting 0x01 XP Builder File. file in the device. When making it newly, it is initialized with no password.
Page 85 Appendix 1. Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address Project is set to store data at USB storage device equipped at device. By the way, now it can’t read information about USB storage Failed to read USB 0x09 XP Builder device.
Page 86 Appendix 1. Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address The project backup file downloaded already Failed to delete previous can be deleted because of error of XGT 0x11 XGT Panel project archive. Please Panel. Reboot XGT Panel. If this problem is reboot XGT Panel.
Page 87 Appendix 1. Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address There is a program to reboot engine program after downloading in the device but when it Failed to save new fails, this message shows up. But because 0x1C XGT Panel project archive.
Page 88 Appendix 1. Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address repeated, contact Customer Service Center. When saving the project, the password Password is not inputted by user is not same as present 0x56 XGT Panel matched.
Page 89 Appendix 1. Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address The project data file can’t be found. Save the Cannot find download project data file at the USB again. When this 0x5D XGT Panel file. symptom is repeated, check the USB.
Page 90 Appendix 1. Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address The project data classified according to the content is moved to the original storage Cannot move new location. But when it fails, the downloading is 0x67 XGT Panel project data files.
Page 91 Appendix 1. Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address The new module is downloaded by the XGT Panel update but the previous module is not deleted. Reboot the device. If the XGT Panel software is not started normally, touch Failed to Delete 0x06 XGT Panel...
Page 92 Appendix 1. Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address The version information list to update is empty. Check the module folder newly designated at XP- There's no file to 0x24 XP-Builder Builder and if there is no error, download XGT download.
Page 93 Appendix 1. Troubleshooting Error code Occurrence Object Error message Reason and measure location Type Address To reboot the engine is not available because of wrong file which is developed by downloading wrong module or There's no downloaded communication error. 0x2B XGT Panel file.
Page 94: Appendix 2. Dimension
Appendix 2. Dimension Appendix 2. Dimension (Unit: mm) (1) XP30-BTE/DC, XP30-TTE/DC (2) XP50-TTE/DC App.2-1...
Page 95 Appendix 2. Dimension (3) XP30-BTA/DC, XP30-TTA/DC (4) XP40-TTE/DC, XP40-TTA/DC App.2-2...
Page 96 Appendix 2. Dimension (5) XP50-TTA/DC (6) XP70-TTA/AC, XP70-TTA/DC App.2-3...
Page 97 Appendix 2. Dimension (7) XP80-TTA/AC, XP80-TTA/DC (8) XP90-TTA/AC App.2-4...
Page 98 Warranty and Environmental Policy Warranty 1. Warranty Period The product you purchased will be guaranteed for 18 months from the date of manufacturing. 2. Scope of Warranty Any trouble or defect occurring for the above-mentioned period will be partially replaced or repaired. However, please note the following cases will be excluded from the scope of warranty.
Page 99 LS values every single customers. Quality and service come first at LSIS. Always at your service, standing for our customers. http://eng.lsis.biz 10310000867 ■ HEAD OFFICE ■ LS Industrial Systems Chengdu Office _ Chengdu, China LS tower, Hogye-dong, Dongan-gu, Anyang-si, Gyeonggi-do 1026-6, Address : 12FL.
