Used for the purposes for which it is intended, and with careful maintenance as outlined in this User Guide, your Lincat product will give you years of trouble free service. For use in GB & IE...
TECHNICAL DATA Model OG7001 OG7002 Dimensions Overall Height (mm) Width (mm) Depth (mm) Weight (kg) Hob Cooking Surface w x d (mm) 600 x 600 900 x 600 Usable Oven Capacity w x d x h (mm) 500 x 540 x 400...
Ignitor Wand User Instructions SERIAL NUMBER Each appliance manufactured at Lincat has a unique identifying number found in the top NOTE right hand corner of the data plate attached at the rear of the appliance. Please record that number in the space provided should it be required for future reference.
The gas inlet connection is at the rear of the appliance. The pipe work should be of adequate size but not smaller than the gas inlet connection at the rear of the appliance, i.e. Rp ½” BSP (OG7001) & Rp ¾” BSP (OG7002).
Conversion of Gas Type – Injector Changes Model Inlet Pressure Injector Mark Part No. 1.90 JE254 x 4 JE216 x 4 OG7001 20 mbar 2.10 JE206 x 1 JE250 x 1 1.90 JE254 x 6 JE216 x 6 OG7002 20 mbar 2.30...
Page 8
Hob Valve Bypass Injectors Remove the bypass injectors C from each of the hob burner control valves B. Replace the bypass injectors applicable to the required gas type. Screw fully home but do not over tighten. Hob Tap Components Part Description Manifold...
Page 9
Oven Burner injector Remove the oven base tray and shelves. Disconnect the ignition lead and remove thermocouple T by undoing lock nut V. Undo the flexi hose from the coupling O and remove coupling O from burner. ...
USER INSTRUCTION APPLIANCE USE This appliance is only for professional use and should only be used by qualified personnel. Ensure that the person responsible understands how to light, safely operate, clean and shut down the appliance and is made aware of the position and operation of the gas isolating cock in the event of an emergency.
SERVICING SERVICE ACCESS To access and service the gas control valves Remove the control knobs and fascia panel to gain access to the valves. Remove the two screws securing the valve boss and carefully withdraw the spindle from the valve. ...
Page 12
Oven Thermocouple Remove the pan supports, burner caps,rear access panel, hob top and oven liner tray. Remove the thermocouple nut from the thermostat body G. Remove the thermocouple lock nut from the burner and withdraw the thermocouple from the bracket.
SPARE PARTS LIST Part number Part description Used on BU72 Door bushes OG7001, 2 BU86 Oven burner OG7001 BU78 Oven burner OG7002, BU224 Burner base OG7001, 2 BU225 Burner injector holder OG7001, 2 BU226 Burner cap OG7001, 2 CO113 Copper Washer...
FAULT FINDING Piezo oven ignitor not sparking. Check for a short in the high tension lead Replace lead Check electrode for fracture Replace electrode Replace piezo ignitor Burner/s will not light or stay lit Is there gas at the burner? Check injector for blockages Are thermocouple connections loose? Tighten connections...
Gas catering equipment should be routinely serviced to ensure a long trouble free life. It is recommended that this appliance is serviced every 6 months by a competent gas engineer. For help regarding the installation, maintenance and use of your LINCAT equipment, please call:- LINCAT SERVICE HELP DESK ...
