INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other
fl ammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the fi re department.
Installation and service must be performed by
a qualifi ed installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certifi ed kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room
080211-36
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL
TC54.CE2
SERIES C
MODULAR DIRECT VENT
FIREPLACE
TC54.CE2
5056.42562
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces TC54.CE2 Series C
Summary of Contents for Town & Country Fireplaces TC54.CE2 Series C
- Page 1 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. WARNING: If the information in these instructions is not followed exactly, a fi re or explosion may result causing property damage, personal injury or death. FOR YOUR SAFETY Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 2: Table Of Contents
Table of Contents Caution ................... 3 Safety ..................... 3 Massachusetts Rules and Regulations ........... 4 Fireplace Dimensions ..............5 Minimum Clearances to Combustible Material ....... 5 Installation Requirements ............... 6 Manufactured (Mobile) Home ............6 Window Frame Removal ..............6 Top Standoffs .................. -
Page 3: Caution
Caution FOR YOUR SAFETY - Do not install or operate your Town & Country fi replace without fi rst reading and understanding this manual. Any installation or operational deviation from the following instructions voids the Town & Country Fireplaces Warranty and may prove hazardous. -
Page 4: Massachusetts Rules And Regulations
Important Note for the Commonwealth of Massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above fi nished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfi ed. -
Page 5: Fireplace Dimensions
Fireplace Dimensions Fig. #1 16 7/16” 15 3/4” 59 5/16" 59 5/16" 35 5/16" 35 5/16" 63 7/8” 31 1/4" 44 1/8” 48 1/8” 31 1/4" 53 9/16" 53 9/16" 53 9/16” 31 1/4” Minimum Clearances to Combustible Material Fig. #2 NON-COMBUSTIBLE ZONE. -
Page 6: Installation Requirements
Installation Requirements The Town & Country Fireplace installation and venting must conform to the current Natural Gas and Propane installation code CAN/CSA-B149.1 (in Canada) or the current National Fuel Gas Code, NFPA54/ANSI Z223.1 (in the USA), and approved per local codes. -
Page 7: Top Standoffs
Top Standoffs The top standoffs are shipped loose inside Fig. #6 TOP STANDOFFS the fi replace and must be installed on top of the fi replace as shown in Fig #6. Do this once the fi replace is on site and in position. Locating The Fireplace In planning the installation for the fi replace, it is necessary to determine where the unit is to be installed, location of vent system and where gas supply piping may be plumbed. -
Page 8: Framing And Finishing
Framing and Finishing Note: The fi replace should be in place position. Secure the steel frame to the framing Chase Insulation: When installing this and venting installed before framing in or brackets on each side of the unit. Ensure that fi replace against a non-insulated exterior wall building an enclosure around the unit. - Page 9 Fig. #9 Fig. #9A NON-COMBUSTIBLE BOARD DETAIL IF THE BACKER BOARD IS NOT TO BE FINISHED WITH OTHER NON-COMBUS- TIBLE MATERIAL SUCH AS TILES, IT IS RECOMMENDED THAT TOP SECTIONS NON-COMBUSTIBLE BOARD OF BOARD SUPPLIED WITH FRAMING 18 3/4" 18 3/4 KIT BE REPLACED WITH A FULL SHEET OF NON-COMBUSTIBLE BOARD.
-
Page 10: Steel Stud Framing Kit
Steel Stud Framing Kit TC54.FRKT Each Kit Contains: Item Part # Description Qty. 5048.401 SCREW, TEKS #8 x 1/2 8193 STUD, SIDES, 63 3/4”L 8192 STUD, OUTER SIDES, 63 3/4”L 8195 STUD, CENTER, 19 7/16”L 8194 STUD, HEADER, 63 1/2”L 8194.2 STUD, PLATE, 57 1/16”L... - Page 11 2. Attach Side Studs (Legs) Fig. #13 • Attach the outer side studs (3) to the top of the header stud (5). (Fig #13) • Fasten the outer side studs (3) at the bottom using the base plates (10). NAIL TABS 3.
-
Page 12: Hearth Extension
Hearth Extension Fig. #16 WINDOW FRAME (See Caution) HEARTH EXTENSION WINDOW TRACK SUB-FLOOR * Caution: A minimum 2" thick non-combustible hearth extension extending 18" in front of this fi replace must be fi tted if a combustible sub fl oor extends in front of the fi replace. To ensure that the hearth does not interfere with the window frame the fi replace must be raised to ensure that the hearth extension is no more than 1"... -
Page 13: Maestro Control
Maestro Control – Plumbing and Electrical ACCESS PANEL The gas control system is located on the right hand side of the fi rebox behind an access Fig. #17 panel and the decorative fi rebox panel (if installed). The fi replace is operated via a wall control and a hand held remote control unit. -
Page 14: Standing Pilot Function
8. Route the control cable as required to the wall control electrical box. Fig. #21 9. Attach the control cable to the wall control. (Fig #21) 10. Insert the 4 supplied “AA” batteries into the battery pack and connect to wall control. (Fig #22) 11. -
Page 15: Gas Supply
Gas Supply Caution: The gas line should be installed by a qualifi ed service person in accordance with all building codes. This section is intended as a guide for qualifi ed technicians installing this appliance. Consult local and / or national building codes before proceeding. This fi replace has two gas controls and gas lines must be run to both by the installer in order for the fi replace to operate correctly. -
Page 16: Horizontal Termination Venting
Horizontal Termination Venting (Power Vented) This unit can be vented horizontally (wall termination) ONLY with an approved NOTE: High Capacity Power Vent Kit (TCVT.PVAX2) using TC 8x11 Vent Pipe. It is recommended that Please use the instructions provided with the optional High Capacity Power the High Capacity Power Vent Kit when planning any installation where a horizontal termination is Vent Terminal be painted... -
Page 17: Roof Termination Venting Chart
Roof Termination Venting Chart Fig. #27 Various combinations of vent runs may be used. Refer to Fig #27 for details. For optimum MAX. performance and fl ame appearance, keep the vent length to a minimum. Connections between each vent system component must be tightly joined, secured with sheet metal screws and sealed. - Page 18 Ceiling Opening: Fig. #28 Determine the exact position of the fi replace so that the vent pipe is centred (if possible) between two building framing members. Lay out the vent system path, minimizing the number of elbows and length of vent. Consult your local building codes prior to proceed- 14 1/2”...
-
Page 19: Roof Vent Terminal
Roof Vent Terminal: 1. Place the roof fl ashing over the vent pipe, secure and seal it to the roof using the methods and materials appropriate for the type of roof on the building. Shingle roof example shown (Fig #30) 2. -
Page 20: Vent Terminal Clearance
Vent Terminal Clearance Minimum clearances to the vent terminal must be maintained as shown VENT TERMINAL MINIMUM CLEARANCES Fig. #31 in fi gure #40 & 41. Measure clearances to the nearest edge of termina- TO ADJACENT STRUCTURES tion hood. NOTE: Vent terminal must not be recessed NOTE: LOCAL CODES OR REGULATIONS MAY REQUIRE DIFFERENT CLEARANCES. -
Page 21: Vent Restrictor Adjustment
Vent Restrictor Adjustment The vent restrictor is located on the underside of the fi rebox top. The unit leaves the factory Fig. #33 with the vent restrictor wide open. The restrictor is built into the appliance for secondary air WALL AND ROOF fl ow adjustment. -
Page 22: Firebox Panels Installation
Firebox Panels Installation BEIGE HERRINGBONE ................TCPN.771 TUSCAN ....................... TCPN.772 HERITAGE RED ................... TCPN.773 BLACK PORCELAIN ................TCPN.774.C COFFEE BEAN BROWN PORCELAIN ..........TCPN.774CB.C (See Porcelain panel instruction manual for specifi c instructions for these panels) A Firebox Panel Set must be installed for safe operation. Do not use the fi replace without panels. -
Page 23: Finishing Touch Trim Kit Instructions
Finishing Touch Trim Kit Instructions Place two smaller magnets on back of each side rail. Place two larger magnets on back of the top and bottom rails. Attach the side rails. Even the ends up with the door frame. Attach the top and bottom rails and adjust so mitres are even at the corners. Place TC magnetic logo in bottom right corner. -
Page 24: Lighting Instructions
Lighting Instructions FOR YOUR SAFETY READ BEFORE LIGHTING - Do not touch any electric switch; do not use any phone in your WARNING: If you do not follow these instructions building. - Immediately call your gas supplier from a neighbour's phone. exactly, a fire or explosion may result causing Follow the gas supplier's instructions. -
Page 25: Maestro Control System
Maestro Control System Remote Control Initial Setup This fi replace is supplied with a wall control Fig. #37 Fig. #38 and hand held remote control. Please note only genuine Town & Country Fireplace wall controls and hand held remote controls can be used on this fi replace. -
Page 26: Manual Mode
Childproof Lock Fig. #40 An additional feature of this remote control is the childproof lock. To activate this system press and hold the timer and thermostat buttons for approx. 5 seconds until the “lock” symbol appears on the remote display (Fig #40). The remote control hand set buttons are now locked and the lock symbol will reappear every time a button is pressed on the remote control until the timer and thermostat buttons are pressed and held again. - Page 27 Program Mode Fig. #42 Fig. #44 (To preset up to two on and off periods per day) The program mode has two settings for weekdays and two for weekends. The hand held remote comes with the following pre programmed settings: Weekday Program (Monday through Friday) Program one (P1) turns ON at 7:00am and...
- Page 28 Thermostatic Mode Fig. #46 Fig. #48 THERMOSTATIC MODE THERMOSTATIC BUTTON (Only for use where permitted) BUTTON (Operates the fi replace within a set tem- perature range) The fi replace is shipped with thermostatic mode function deactivated. If this function is permitted for use in your area it can be activated by depressing the recessed button on the underside of the hand held remote.
-
Page 29: Appendix
APPENDIX Maintenance CAUTION: Turn off gas and electrical power supply (if applicable) and allow ample time for unit to cool before servicing appliance. It is recommended that the fi replace and its venting should be inspected at least once a year by a qualifi ed service person. Glass Panel: Warning: Do not operate fi replace with glass panel removed, cracked or broken. -
Page 30: Replacement Parts
Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. TC54 BODY ASSM .........TC54.CE PANEL SETS HERRINGBONE ........TCPN.771 TUSCAN ..........TCPN.772 GLASS ASSM........GLAS.2054ASSY HERITAGE RED ........TCPN.773 BLACK PORCELAIN ......TCPN.774.C FRAMIMG KIT ........TC54. FRKIT C B BROWN PORCELAIN ....TCPN.774CB.C MAESTRO CONTROL ASSEMBLY - See Page 31 KIT CONTENTS: #3..FRAMIMG KIT... -
Page 31: Replacement Parts - Maestro Control System
Replacement Parts – Maestro Control System (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM ..DESCRIPTION ..........PART NO. ITEM ..DESCRIPTION ..........PART NO. #1..CONTROL ASSEMBLY KIT ....TCRP.9271A #5..COMMUNICATION CABLE KIT ..TCRP.5005.062 #2..BULKHEAD ASSEMBLY KIT ....TCCV.8133 #6.. -
Page 32: Wiring Diagram
Wiring Diagram Fig. #53 TC54.CE2 080211-36... -
Page 33: Roof Termination Kit
Roof Termination Kit TCVT.RTA Fig. #54 VERTICAL TERMINATION CAP TCVT.9365 STORM COLLAR TC42.90665 CEILING FIRESTOP TCVT.THIMA ROOF SUPPORT BRACKET TCVT.93915 TC54.CE2 080211-36... -
Page 34: Vent Pipe Dimensions
Vent Pipe Dimensions Fig.#55 11" 12" PIPE ....10 1/4" 18" PIPE ....16 1/4" 24" PIPE ....22 1/4" 10 15/16" 48" PIPE ....46 1/4" 9 1/2" TCV T.8 11X12AD J 11 1/8 " TCV T.8 11X _ _ 12 9/16"... -
Page 35: Safety Label Location
Safety Label Location NOTE: The Safety Label is located on a plate found in a slot between the left hand side lintel and the left hand side window frame. This plate is attached to the lintel with a cable. VENTED GAS FIREPLACE - NOT FOR USE WITH SOLID FUEL FOYER AU GAZ À... - Page 36 Technical support: 1-250-748-1184 Web site: www.townandcountryfi replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
