Town & Country Fireplaces TC42 Installation And Operating Instructions Manual

Series d modular direct vent fireplace
Hide thumbs Also See for TC42:
Table of Contents

Advertisement

Quick Links

See also: Operating Instructions , Instruction Manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a re or
explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY
Installation and service must be performed
by a quali ed installer, service agency or the
gas supplier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the re department.
Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any
other appliance.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certi ed kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
030615-48
SERIAL #
TC42
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL TC42
SERIES D
MODULAR DIRECT VENT
FIREPLACE
TC42_D
5056.426D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC42 and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC42

Summary of Contents for Town & Country Fireplaces TC42

  • Page 1 This appliance is not convertible for use with other gases, unless a certi ed kit is used. This appliance is suitable for installation in a bedroom or bed sitting room. MODEL TC42 SERIES D MODULAR DIRECT VENT FIREPLACE 030615-48 TC42_D 5056.426D...

  • Page 2: Table Of Contents

    Locating The Fireplace ........... 7 Vent Offset Chart ..........30 Framing and Finishing ..........8 Firebox Panels Installation ........31 TC42 Steel Stud Framing Kit ........ 10 Finishing Touch Trim Kit Instructions ..... 32 Adjustable Lintel ........... 12 Lighting Instructions ..........33 Hearth Extension ..........

  • Page 3: Caution

    Caution FOR YOUR SAFETY - Do not install or operate your Town & Country replace without rst reading and understanding this manual. Any installation or operational deviation from the following instructions voids the Town & Country Fireplaces Warranty and may prove hazardous.

  • Page 4: Important Note For The Commonwealth Of Massachusetts

    Important Note for the Commonwealth of Massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above nished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satis ed.

  • Page 5: Fireplace Dimensions

    Fireplace Dimensions Fig. #1 29 9/16" 53 15/16" 42 3/16" 38 1/2" 16 3/4" 51 1/16" 44 7/16" 29 3/16" 53 1/16" 48" Minimum Clearances to Combustible Material Fig. #2 NON-COMBUSTIBLE ZONE. COMBUSTIBLE FRAMING AND STEEL FRAMING DO NOT INSTALL ANY COMBUSTIBLE MATERIAL, ELECTRICAL WIRING OR GAS FINISH WALL ABOVE STANDOFFS STANDOFFS...

  • Page 6: Installation Requirements

    Fig. #4 Installation Requirements The Town & Country Fireplace installation and venting must conform to the current CAN/CGA-B149 installation code (in Canada) or the current National Fuel Gas Code, ANSI Z223.1 (in the USA), and approved per local codes. Only quali ed (licensed or trained) personnel should install this product.

  • Page 7: Top Standoffs

    Top Standoffs The top standoffs are shipped loose inside Fig. #8 TOP STANDOFFS the replace and must be installed on top of the replace as shown in Fig #8. Do this once the replace is on site and in position. Locating The Fireplace In planning the installation for the replace, it is necessary to determine where the unit is to be installed, location of vent system and where gas supply piping may be plumbed.

  • Page 8: Framing And Finishing

    Framing and Finishing Note: The replace should be in place thickness of nishing surface. walls be insulated to same degree as other and venting installed before framing in exterior walls. Do not place replace directly or building an enclosure around the unit. The sides, back and top of the replace can against the insulation.
  • Page 9 Fig. #11 Fig. #11a IF FINISHING THE WALL ABOVE THE UNIT NON-COMBUSTIBLE BOARD DETAIL WITH PAINT, THE FRAMING KIT SHIPPED WITH THE UNIT SHOULD BE DISCARDED. U S E F U L L S H E E T S O F CA L C I U M SILICATE BOARD OR EQUIVALENT AND FULL LENGTH METAL STUDS TO NON-COMBUSTIBLE...

  • Page 10: Tc42 Steel Stud Framing Kit

    TC42 Steel Stud Framing Kit TC42.BFRKITB Fig. #14 Each Kit Contains: Item Description Qty. Item Description Qty. SCREW, TEKS #8 x 1/2 STUD, HEADER HORIZONTAL (Not shown) 58 1/4” L SIDE STUD, VERTICAL INNER STUD PLATE, HORIZONTAL 53 3/4” L...
  • Page 11 1. Top Frame Assembly 4. Secure to Existing Framing 5. Install Non-combustible Board • • • Lay out the horizontal header Secure the frame assembly to exist- Use drywall screws to install the stud (5) on a large flat surface. ing framing through the horizontal concrete board (Fig #16).

  • Page 12: Adjustable Lintel

    Adjustable Lintel The adjustable lintel assembly has Fig. #17 two orientations for desired nishing. A anged edge and a hemmed edge. The lintel comes factory installed with the ange edge out. If the desired edge is different from the factory setting, use the following steps to change the Lintel edge.

  • Page 13: Hearth Extension

    This replace Fig. #19 recessed up to a maximum depth 4½” from screen, this Non combustible building recess must be constructed from material may not extend Area inside Lintel must non- combustible material. The space past this point remain free of obstructions between the outside lintels and the rebox must be completely free of any debris and the window with trim...

  • Page 14: Electrical

    Electrical The gas control system is located on the right hand side of the rebox behind FIREBOX ACCESS PANEL an access panel and the decorative rebox panel (if installed). The replace is operated via a wall control and a hand held remote control unit. Fig.

  • Page 15: Wall Switch And Remote Control

    Wall Switch and Remote Control Fig. #25 Fig. #26 Fig. #24 TO FIREPLACE Insert a straightened paper clip into Press the ON/OFF button of the Linking the remote control unit to the the “PROGRAM” slot on the wall remote unit. Once the wall unit beeps wall switch.

  • Page 16: Home Automation

    Home Automation The home automation feature supplied with this replace is capable Fig. #28 of controlling the ame and light on/off function with the use of a dry contact relay common to home automation systems. Furthermore, the ame and light level may be modulated from high to low using the 0 - 10 volt analog output available on most home automation systems.

  • Page 17: Gas Supply

    Gas Supply Caution: The gas line should be installed by a quali ed service person in accordance with all building codes. This section is intended as a guide for quali ed technicians installing this appliance. Consult local and / or national building codes before proceeding. •...

  • Page 18: Venting

    Venting Before installing venting for this unit, the installer should read these instructions to insure that the proper vent con guration has been selected. Use only Town and Country Termination kits #: TCVT.WTA - Wall Termination Kit TCVT.RTA - Roof Termination Kit Vent system components approved for use with the Town and Country Fireplace are shown in Fig.

  • Page 19: 5056.426D

    Fig. #31 Fig. #32 TRIM TO LENGTH WALL THIMBLE AND VENT MUST NOT PROTRUDE BEYOND SIDING Wall thimble: Where a vent pipe passes through a combustible wall, a wall thimble/shield must be used to retain insulation and maintain proper clearances. The wall thimble may be cut to length for various wall thicknesses up to 12"...

  • Page 20: 5056.426D

    Vent pipe: Install vent pipe through the wall thimble and attach to ue outlet collar on top of the replace. Secure all joints with screws and seal with approved "High Temp." self-adhesive aluminum tape provided. Adjust the replace position so that the vent pipe does not protrude beyond the outer wall.

  • Page 21: Wall Termination Venting Chart

    Wall Termination Venting Chart Fig. #35 Pipe length Minimum rise Pipe length Maximum run Max. 74 1/4” 1-24” 18" 1-12" 78 1/2” 1-12” 1-18" 75 3/4" 1-48" 1-12" 84 1/2” 1-24" 1-12” 11' 2" 2-48" 1-24" 3-48" 1-24" 90 1/2” 1-24”...

  • Page 22: Roof Termination Venting Chart

    Roof Termination Venting Chart Fig. #36 Pipe length Minimum rise Pipe length Maximum run Maximum 74 1/4” 1-24” 29" 1-12" 78 1/2” 1-12” 1-18" 77 1/4" 1-48" 1-12" 84 1/2” 1-24" 1-12” 11' 1 1/2" 2-48" 1-24" 3-48" 1-24" 90 1/2” 1-24"...
  • Page 23 Ceiling Opening: Fig. #37 Determine the exact position of the replace so that the vent pipe is centered (if possible) between two building framing members. Lay out the vent system path, minimizing the number of elbows and length of vent. Consult your local building codes prior to 14 1/2"...
  • Page 24 (Fig #39). Seal screw heads and joint with caulking to prevent any moisture entering the venting system. Fig. #39 VERTICAL TERMINATION CAP (TCVT.9365) VENT PIPE MASTIC STORM COLLAR (TC42.90665) FLASHING NOTE: ADJUSTABLE FOR VARIOUS ROOF PITCHES, FROM FLAT ROOF TO 12/12 PITCH ROOF. 5056.426D TC42_D 030615-48...

  • Page 25: Vent Terminal Clearance

    Vent Terminal Clearance Minimum clearances to the vent terminal must be maintained as shown Fig. #40 VENT TERMINAL MINIMUM CLEARANCES in gure #40 & 41. Measure clearances to the nearest edge of termina- TO ADJACENT STRUCTURES tion hood. NOTE: Vent terminal must not be recessed NOTE: LOCAL CODES OR REGULATIONS MAY REQUIRE...

  • Page 26: Vent Pipe Sealant

    Vent Pipe Sealant Fig. #42 APPROVED “HIGH TEMP.” SELF-ADHESIVE TAPE VENT PIPE All outer joints of the vent pipe must be sealed with the approved "High Temperature" self- adhesive aluminium tape provided. Wrap the tape completely around the joint and press rmly in place.

  • Page 27: Vent Restrictor Adjustment

    Vent Restrictor Adjustment The vent restrictor is located on the underside of the rebox top. The unit leaves the fac- Fig. #43 tory with the vent restrictor open. The restrictor is built into the appliance for secondary air WALL AND ROOF ow adjustment.

  • Page 28: Wall Termination Kit

    TCVT.THIMA WALL SHIELD / CEILING FIRESTOP 9 5/8" TCVT.THIMA - OPTIONAL Roof Termination Kit TCVT.RTA Fig. #46 16 1/2" VERTICAL TERMINATION CAP TCVT.9365 9" STORM COLLAR TC42.90665 WALL SHIELD / CEILING FIRESTOP ROOF SUPPORT TCVT.THIMA BRACKET TCVT.93915 5056.426D TC42_D 030615-48...

  • Page 29: Vent Pipe Dimensions

    Vent Pipe Dimensions Fig. #47 11" 12" PIPE ..10 1/4" 18" PIPE ..16 1/4" 24" PIPE ..22 1/4" 48" PIPE ..46 1/4" 10 15/16" 9 1/2" TCVT.811X12ADJ 11 1/8" TCVT.811X _ _ 13 13/16" 12 9/16" 8 5/16"...

  • Page 30: Vent Offset Chart

    Vent Offset Chart Fig. #48 12" PIPE 18 5/8" 18" 18" PIPE 22 7/8" 22 3/8" 10 7/8" 24" PIPE 27 1/8" 26 1/2" 48" PIPE 44 1/16" 43 1/2" 1 1/4” 11 3/8" ADDING AN ADJUSTABLE SECTION TO PIPE WILL INCREASE OFFSET BY 2 1/8"...

  • Page 31: Firebox Panels Installation

    Firebox Panels Installation TC42 PANELS PARK AVE. HERRINGBONE 2 ............TCPN.42PAC2 MOUNT VERNON RED BRICK ..........TCPN.42VRC2 MANHATTAN BEIGE STACKED BRICK ..........TCPN.42MNC2 BLACK PORCELAIN ..................TCPN.549.C COFFEE BEAN BROWN PORCELAIN ..........TCPN.549CB.C TITANIUM ....................TCPN.549TI COPPER ......................TCPN.549CU MILAN 2 ....................TCPN.42MILC2 (See Porcelain panel instruction manual for speci c instructions for these panels) Before proceeding see burner instructions.

  • Page 32: Finishing Touch Trim Kit Instructions

    3. Install the Right Side Panel by inserting Fig. #50 the bottom of the panel in rst and then angling it up into position. It may be necessary to push the rebox shield up to allow panel to move freely into place. 4.

  • Page 33: Lighting Instructions

    Lighting Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: - Immediately call your gas supplier from a neighbour's phone. Follow If you do not follow these instructions exactly, a the gas supplier's instructions. fire or explosion may result causing property damage, - If you cannot reach your gas supplier, call the fire department.

  • Page 34: First Fire

    First Fire When lit for the rst time, the replace will emit a slight odor for a couple of hours. This is due to the curing of paints, seal- ants and lubricants used in the manufacturing process. This condition is temporary. Open doors and windows to ventilate area.
  • Page 35 Key Lock Transmission Low battery alarm Thermostat OFF/ Room ON/SMART Temperature CPI mode Set Point: Aux ON Temperature/Level/State Flame ON Split Flow Dimmer ON Comfort fan Fig. #53 Remote Control Transmitter LCD display. Note: Some functions may not be available Attention! •...
  • Page 36 Fireplace Description The Pro ame2 Remote Control Fireplace consists of three elements: Pro ame2 Remote Control Transmitter. Pro ame Integrated Fireplace Control (IFC Module) board and a wiring harness to connect the IFC to the gas valve and stepper motor (Fig. 23, page 14). Wall mounted Remote Control Receiver (Figs.
  • Page 37 Program button Fig. #54 wall switch electronics Fig. #57 Remote Control Transmitter battery bay Fig. #56 Town & Country wall Fig. #55 wall switch batteries side switch face plate. Using the Remote Control Transmitter Temperature indication Display With the remote control transmitter in the “OFF” position, press the thermostat and mode keys at the same time.
  • Page 38 Remote Flame Control The Pro ame2 has six (6) ame levels. With the replace turned on, and the ame level at maximum height, press the down arrow key once (Fig. 60 Flame level 1) to reduce the ame height by one step until the ame is turned off.
  • Page 39 Remote dimmer control (Light) The auxiliary function controls the AUX power outlet by the dimmable light control. To activate this function use the Mode Key ( g. 52) to index to the light bulb icon ( g. 66). The inten- sity of the output can be adjusted through six (6) levels.

  • Page 40: Maintenance

    APPENDIX Maintenance CAUTION: Turn off gas and electrical power supply (if applicable) and allow ample time for unit to cool before servicing appliance. It is recommended that the replace and its venting should be inspected at least once a year by a quali ed service person. Glass Panel: Warning: Do not operate replace with glass panel removed, cracked or broken.

  • Page 41: Tc42.D Replacement Parts

    ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. PANEL SETS TC42 BODY ASSM............ TC42.D PARK AVE. BEIGE HERRINGBONE ....TCPN.42PAC2 MT.VERNON RED HERRINGBONE ....TCPN.42VRC2 GLASS ASSM.......... GLAS.2086ASSY MANHATTAN BEIGE STACKED BRICK ..TCPN.42MNC2 BLACK PORCELAIN ........TCPN.549.C FRAMING KIT ...........TC42.9093-A C B BROWN PORCELAIN ......TCPN.549CB.C TITANIUM ............TCPN.549TI...

  • Page 42: Replacement Parts - Control System

    Replacement Parts – Control System (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM ..DESCRIPTION ..........PART NO. ITEM ..DESCRIPTION ..........PART NO. #1 ..CONTROL ASSEMBLY KIT ....TCCV.95755-B #4 ..TEST FITTING ......... 5019.104 #2 ..BULKHEAD ASSEMBLY KIT ....TCRP.8133 #5..

  • Page 43: Wiring Diagram

    Wiring Diagram Fig. #73 5056.426D TC42_D 030615-48...

  • Page 44: Rating Label

    DU GAZ NATUREL DU GAZ LP MODEL/ Minimum supply pressure / Pression minimum d’alimentation: 5.0 in/wc / 5.0 po/c.e. 12.5 in/wc / 12.5 po/c.e. TC42 MODELE: (1.25 kPa) (3.11 kPa) (For the purpose of input adjustment / dans le but de régler l’alimenation) Maximum supply pressure / Pression maximum d’alimentation:...
  • Page 45 5056.426D TC42_D 030615-48...
  • Page 46 5056.426D TC42_D 030615-48...
  • Page 47 TC42_D 030615-48 5056.426D...
  • Page 48 © 2015 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer Web site: www.townandcountry replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
