Operating Instructions supplied with the fi replace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TC54 COUNTRY HOME BURNER KIT TC54.LP02.C (PROPANE ONLY) PART# TC54.LP02.C 061107-12 TC54.LP02.C 5056.4256.025...
1. Attach the lower burner assembly to the fl oor of the fi rebox with Fig. #1 two screws. (Fig. # 1) 2. Attach the manifold supply tube from the lower burner to the front Fig. #2 bulk head fi tting and tighten. (Fig. # 2) Ensure that there are no leaks. 061107-12 TC54.LP02.C...
Page 3
(Fig. # 5) Fig. #5 6. Attach the manifold supply tube from the upper burner to the Fig. #6 rear bulk head fi tting and tighten. (Fig. # 6) Ensure that there are no leaks. 061107-12 TC54.LP02.C...
Page 4
ORANGE WIRE burner pilot to the rear electrical bulk head. (Fig. # 8) (The spark electrode connection has a red dot above it) A panel set must now be installed. See Installation and Operating Instructions manual for details. 061107-12 TC54.LP02.C...
(Fig. # 11) 3. Attach a pressure gauge onto the fi tting. 4. When testing is complete, shut off the gas, remove the fi tting and replace the plug. Thread sealant will be required to ensure a gas tight connection. 061107-12 TC54.LP02.C...
Note: Ember material placement and amount will affect fl ame appearance. More ember material results in lower fl ame height. Add or remove as needed until desired fl ame affect. Fig. #12 CERAMIC FIBRE FILLER PIECES Ember Material Placement Fig. #13 LOG GRATE GLOWING EMBERS 061107-12 TC54.LP02.C...
They rest in position. Locate as per the diagrams (Fig. # 14-20) Note: Improper placement of logs will cause sooting on internal parts and glass. The logs may need to be repositioned slightly to avoid excessive fl ame impingement. Fig. #14 Fig. #16 Fig. #15 Fig. #17 061107-12 TC54.LP02.C...
4. Rotate the shutter to increase or decrease the amount of primary air. PRIMARY AIR SHUTTERS The fl ame should be just orange and “lazy”. It should NEVER be set to create soot on internal parts and glass. Fig. #21 061107-12 TC54.LP02.C...
LEFT, #3 (shown in fi g.#20) ................5098.74615.3 BOTTOM RIGHT, #4 (shown in fi g.#20) ............5098.74615.4 BOTTOM CENTRE, #5 (shown in fi g.#20) ............5098.74615.5 BOTTOM LEFT, #6 (shown in fi g.#20) ............5098.74615.6 MIDDLE, #7 (shown in fi g.#20) ..............5098.74615.7 Sold only in sets 061107-12 TC54.LP02.C...
