INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING: If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY
Installation and service must be performed by
a quali ed installer, service agency or the gas
supplier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier call the
fire department.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by local
codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a
certified kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Visit www.townandcountryfireplaces.net for the most recent version of this manual
111215-44
SERIAL #
TC54
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL:
TC54
SERIES D
MODULAR DIRECT VENT
FIREPLACE
TC54_D
5056.42562
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces TC54D
Summary of Contents for Town & Country Fireplaces TC54D
- Page 1 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. FOR YOUR SAFETY Installation and service must be performed by a quali ed installer, service agency or the gas SERIAL #...
-
Page 2: Table Of Contents
NEVER ALLOW CHILDREN TO TOUCH GLASS. A barrier designed to reduce the risk of burns from the hot viewing glass is provided with the appliance and shall be installed for the protection of children and other at-risk individuals. TC54D _111215-44 5056.42562... -
Page 3: Caution
This appliance must not be connected to a chimney ue serving a separate solid fuel burning appliance. TC54D _111215-44 5056.42562... -
Page 4: Important Note For The Commonwealth Of Massachusetts
A copy of all installation instructions for all Product Approved side wall horizontally vented gas fuelled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. TC54D _111215-44 5056.42562... -
Page 5: Fireplace Dimensions
‘Hearth Extension’ (Top, sides and bottom) ....1 3/4" in..(45 mm) section for details. A 18" DEEP, 2" THICK, NON-COMBUSTIBLE HEARTH MUST BE PLACED IN FRONT OF THE FULL WIDTH OF THE GLASS Figure 3: Mantel clearances. TC54D _111215-44 5056.42562... -
Page 6: Installation Requirements
To ensure glass is properly latched, grasp the top left and right sides of the glass frame, under moderate pressure it should pull forward and return to original position evenly on both sides. SAFETY BARRIER SCREEN HANDLE Figure 6: Handle. Figure 5: Accessing handle. Figure 4: Safety barrier screen. TC54D _111215-44 5056.42562... -
Page 7: Top Standoffs
The minimum clearances from the fireplace to combustible surfaces must be adhered to and are shown in Figure 2 & Figure 3. EXAMPLES OF COMMON LOCATIONS SEE (FIGURE 14) FOR DIMENSIONS Figure 8: Common installation examples. TC54D _111215-44 5056.42562... -
Page 8: Framing And Finishing
MATERIAL, ELECTRICAL WIRING, IT IS HIGHLY RECOMENDED INSULATION, PLASTIC VAPOR THAT A FULL HEADER BE BARRIER OR GAS PLUMBING INSTALLED ABOVE THE WITHIN THE STEEL STUD FRAMING METAL FRAMING KIT 63 7/8" Figure 9: TC54-D with frame. TC54D _111215-44 5056.42562... - Page 9 NOTE: This fi replace ships with the light wiring secured in retaining clips. Remove light wiring from the retaining clip before installing and walling up the fi replace. wiring from the retaining clip before installing and walling up the fi replace. Wire retaining clip Figure 10: Light wiring retaining clip. TC54D _111215-44 5056.42562...
- Page 10 26 5/8" 37 11/16" 63 1/2" 14 5/8" RANGE RANGE 32 13/16" 34 13/16" 81 1/8" 63 1/2" 34 9/16" 36 5/16" 114 11/16" FRAMING RANGE LINTEL 1/32" 1/2" 3 1/2" Figure 14: TC54 Minimum Combustible Framing. TC54D _111215-44 5056.42562...
-
Page 11: Steel Stud Framing Kit
SCREW, TEKS #8 x 1/2 STUD, HEADER HORIZONTAL (Not shown) 58 1/4" L STUD, INNER SIDES STUD PLATE, HORIZONTAL 63 3/4”L STUD, OUTER SIDES BASE PLATE 5 15/16” L 63 3/4”L CENTER STUD, VERTICAL FRAMING PLATE SHORT 19 7/16”L TC54D _111215-44 5056.42562... -
Page 12: Frame Assembly
Align the assembled frame to the unit framing brackets (Figure 16). Align the framing plates (8) to the fastening points through the access holes in the outer side studs (3). Figure 17: Aligning the frame so that the at surface is facing outward. TC54D _111215-44 5056.42562... -
Page 13: Adjustable Lintel
FLANGED EDGE HEMMED EDGE SAFETY BARRIER GLASS DOOR approximately 1”. SCREEN TRIM Tighten the securing bolts (Figure 19). Figure 18: Lintel and trim. Re-attach the window trim. Reinstall safety barrier screen. 3/8 SECURING BOLT Figure 19: Securing bolt. TC54D _111215-44 5056.42562... -
Page 14: Hearth Extension
Width of glass 1” max above bottom of replace Bottom of replace Figure 21: TC54D Hearth extension. Caution: A minimum 2” thick non-combustible hearth extension extending 18” in front of this replace must be tted if a combustible sub oor extends in front of the replace. To ensure that the hearth does not interfere with the safety screen, the replace must be raised to ensure that the hearth extension is no more than 1”... -
Page 15: Electrical
(Figure 25) to the “ON” position. The SWITCH igniter will start to spark. After a short delay, the pilot will light followed by the main burner. GAS CONNECTOR WALL SWITCH MODULE INTERFACE BOARD JUNCTION BOX CONNECTOR TC54D _111215-44 5056.42562... -
Page 16: Wall Switch And Remote Control
“NV”. If using a power vent, “PV” should be selected. Follow the instructions provided with the power vent kit for proper installation. Figure 28: Vent mode selection switch. TC54D _111215-44 5056.42562... -
Page 17: Home Automation
Figure 30: Home automation wiring diagram. NOTE: • Digital I/O must be connected to a dry contact relay. • Analog ame and light input through 0 - 10 volt DC signal scaled as follows: Low = 1 volt High = 10 volts TC54D _111215-44 5056.42562... -
Page 18: Gas Supply
FRONT MANIFOLD PRESSURE Min. Pressure 5.0" WC 12.5" WC (For purpose of input adjustment) Max. Pressure 13.9" WC 13.9" WC Manifold Pressure Maximum 3.5" WC 10" WC Figure 31: Gas test ports. Minimum 1.6" WC 6.4" WC TC54D _111215-44 5056.42562... -
Page 19: Horizontal Termination Venting (Power Vented)
Up to 3 feet below unit Figure 34: TC54D Optional venting. Maximum vent length is 66 ft plus six 90 degree elbow or combination of other elbows equaling 90 degrees. Minimum vent length is 10 ft plus one 90 degree elbow. The vent can be installed with any combination of rise and run between the above gures including 3ft below the unit. -
Page 20: Vertical Termination Venting
Roof Termination Kit ............ TCVT.RTA Wall Shield / Ceiling Firestop ........TCVT.THIMA Roof Flashing, Adjustable .........TCVT.811FLADJ Roof Flashing, Flat ..........TCVT.811FLFLT Roof Flashing, Steep .........TCVT.811FLSTP or any that ts 11" pipe NOTE: A vertically vented TC54 cannot be power-vented TC54D _111215-44 5056.42562... -
Page 21: Roof Termination Venting Chart
Only 45º elbows can be used in this vent system. Maximum number of elbows is 2. 4' MAX. Minimum 5’ of vertical vent required before 1st elbow. Figure 35: TC54D Vertical venting chart. TC54D _111215-44 5056.42562... -
Page 22: Ceiling Opening
Attach the brackets to the roof joists with nails or building screws. Tighten the band around the vent pipe and ROOF SUPPORT BRACKET secure in place with screws. (TCVT.93915) Figure 37: Roof support bracket. TC54D _111215-44 5056.42562... -
Page 23: Vent Pipe Sealant
"High Temperature" self-adhesive aluminium tape provided. Wrap the tape completely around the joint and press rmly in place. Figure 39: Sealing TC54D vent joints. Insulated Collar Shield INSULATION (Included Pt# TC36.9709) COVER (2 PCS.) -
Page 24: Roof Vent Terminal
Minimum clearances to the vent terminal must be maintained as shown in Figure 42 & Figure 42. Measure clearances to the nearest edge of termination hood. NOTE: Vent terminal must not be recessed NOTE: LOCAL CODES OR REGULATIONS MAY REQUIRE DIFFERENT CLEARANCES. TC54D _111215-44 5056.42562... -
Page 25: Roof Pitch Table
** only permitted if veranda, porch, deck, or balcony is fully open on a minimum of 2 sides beneath the oor* * as speci ed in CGA B149 Installation Codes, Note: local Codes or Regulation may require different clearances * for U.S.A. Installations follow the current National Fuel Gas Code, ANSI Z223.1 TC54D _111215-44 5056.42562... -
Page 26: Vent Restrictor Adjustment
Figure 43: Restrictor rise and run • Flame has excessive movement. chart. To adjust the restrictor: • Loosen the screw holding the restrictor. • Move the restrictor to its intended opening. • Re-tighten the screw. OPENING VENT RESTRICTOR Figure 44: Vent restrictor. TC54D _111215-44 5056.42562... -
Page 27: Roof Termination Kit
Roof Termination Kit VERTICAL TERMINATION CAP TCVT.9365 STORM COLLAR TC42.90665 CEILING FIRESTOP TCVT.THIMA ROOF SUPPORT BRACKET TCVT.93915 Figure 45: Roof termination kit. TC54D _111215-44 5056.42562... -
Page 28: Vent Pipe Dimensions
31 3/4" 16 1/16” 48" PIPE 38 3/4" 44 7/8" 1 1/4” ADDING AN ADJUSTABLE SECTION 6 1/8” TO PIPE WILL INCREASE OFFSET BY 2 1/8" TO 6 3/4" 1 1/4” Figure 47: TC54 Vent offset chart. TC54D _111215-44 5056.42562... -
Page 29: Firebox Panels Installation
Although the brackets are adjusted at the factory for the best t, some adjustment may be necessary. Adjust the angle of the bracket by hand to ensure a snug t. Figure 50: Retainer panel screws location. SCREWS TC54D _111215-44 5056.42562... -
Page 30: Finishing Touch Trim Kit Instructions
TOP OR BOTTOM RAIL 4. Attach the top and bottom rails and adjust so mitres are even at the corners. SIDE RAILS 5. Place the magnetic Town & Country logo in the bottom right corner. Figure 52: Trim kit components. TC54D _111215-44 5056.42562... -
Page 31: Lighting Instructions
Serveiller les enfants. Garder les vêtements, le meubles, l'essence ou autres liquides produisant des vapeurs infl ammables loin de l'appareil. S'assurer que le brûleur et le compartiment des commandes sont propres. Voir les instructions d'installation et d'utilisation qui accompagnent l'appareil. 090713 5051.185 GBWY TC54D _111215-44 5056.42562... -
Page 32: First Fire
30 seconds to ignite each time the “ON” button has been selected. Remote Control Operation Blue back lit LCD display ON/OFF Key THERMOSTAT Key UP/DOWN Arrow Key MODE Key Figure 53: Pro ame 2 handset. TC54D _111215-44 5056.42562... - Page 33 In case of remote control malfunction, turn off the fi replace using the “on/off” main switch located on the wall. For installation/maintenance, turn off the fi replace at the on/off switch located on the wall and at the fi replace power supply circuit breaker. TC54D _111215-44 5056.42562...
-
Page 34: Fireplace Description
5. On the remote control transmitter, push the power on key once. The remote control transmitter will beep 4 times to indicate that the remote control transmitter and the IFC module are now synchronized. The remote control transmitter is now ready to use. TC54D _111215-44 5056.42562... -
Page 35: Using The Remote Control Transmitter
If the batteries of the remote control transmitter are low or depleted, the replace can be turned off manually using ON/OFF switch located on Town & Country wall switch. This will bypass the remote control transmitter. Figure 60: Pro ame 2 Celcius screen. TC54D _111215-44 5056.42562... -
Page 36: Remote Flame Control
The thermostat key (Figure 53) on the remote handset needs to be held down. Keep it pressed down and remove one of the three batteries from the remote handset. Simply re-install the battery that was removed and the feature is activated. Use the same procedure to disable the thermostat function. TC54D _111215-44 5056.42562... -
Page 37: Remote Dimmer Control (Light)
This is an alert for a low battery condition for the IFC board. When the batteries are replaced, a single “beep” will be emitted from the IFC module when a key is pressed, see "Initializing the Fireplace for the rst time" on page 34. TC54D _111215-44 5056.42562... -
Page 38: Maintenance
Viewing glass may be cleaned as necessary with replace glass cleaner. b) Exterior nish may be cleaned with mild soap and water. CAUTION: Do not use abrasive cleaners on glass or any other part of the replace. Do not clean glass when hot. Figure 69: Pilot assembly. TC54D _111215-44 5056.42562... -
Page 39: Replacement Parts
4d ....... PANEL, LEFT BASE 5d ..PANEL, LEFT /RIGHT BASE 1d ..SPRING LATCH ASSEMBLY(2) 1e .. CONTROL ASSEMBLY HOLDER 4e .....PANEL, RIGHT BASE 4f ....PANEL, LOWER BACK 1f ....LED LIGHT ASSEMBLY BRICK PANEL RETAINER (not shown) TC54D _111215-44 5056.42562... -
Page 40: Replacement Parts - Control System
2d ........... 1/2" BULKHEAD FITTING 1e .............IGNITION MODULE 2e ........... 1/4" BULKHEAD FITTING 1f ............WIRING HARNESS 2f ..........ELEC BULKHEAD FITTING REMOTE TRANSMITTER 1g ............TRANSFORMER (not shown) 1h ........PRESSURE TEST ASSEMBLY 1i........... REGULATOR BOARD 1j............ PRESSURE SWITCH TC54D _111215-44 5056.42562... -
Page 41: Wiring Diagram
Wiring Diagram TC54D _111215-44 5056.42562... -
Page 42: Rating Label
SEP OCT NOV DEC 2017 des dommages matériels ou des blessures. Voir la notice de l’utilisateur qui accompgne l’appareil. Pour de l’aide ou des renseignements supplémentaires, consultez un installateur, un technicien agréé ou le fournisseur de gaz. 250814 5050.720352D 1-TC54D TC54D _111215-44 5056.42562... - Page 43 TC54D _111215-44 5056.42562...
- Page 44 © 2015 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer Web site: www.townandcountry replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
