System Upgrade Related
No. Description
Remote network error.
301
Remote upgrade is not authorized.
302
Saving remote package failed.
303
Remote upgrade is cancelled by the user.
304
USB device mounting failed.
400
Reading upgrade package on the USB device
401
failed.
Copying upgrade package on the USB device
402
failed.
USB device is not connected.
403
USB device is being used.
404
Unsupported file system.
405
System is busy clip copying.
500

Specifications

Signal Format
Video Input
Monitor Outputs
Video Resolution
Record Speed
(images per second)
Playback Speed
(images per second)
Alarm Input
Alarm Output
Alarm Reset Input
Internal Buzzer
Network Connectivity
Audio Input
Audio Output
Text Input
VIDEO
NTSC or PAL (Auto Detect)
Composite: 8 or 16 looping inputs, 1 Vp-p, auto-terminating, 75 Ohms
Composite: 1 BNC, 1 Vp-p, 75 Ohms
SPOT: 1 BNC, 1 Vp-p, 75 Ohms
VGA: 1
Composite: 720x480 (NTSC), 720x576 (PAL)
VGA: 800x600, 1024x768, 1280x1024 @ 60Hz
Real-time: 480ips (NTSC), 400ips (PAL) @ CIF (16-ch Model)
Real-time: 240ips (NTSC), 200ips (PAL) @ CIF (8-ch Model)
Full Duplex: 480ips (NTSC), 400ips (PAL) @ CIF (16-ch Model)
Full Duplex: 240ips (NTSC), 200ips (PAL) @ CIF (8-ch Model)
INPUTS/OUTPUTS
8 or 16 terminal, programmable as NC or NO, 2.4V (NC) or 0.3V (NO) threshold,
5VDC
2 relay output, programmable as NC or NO, 2A@125VAC, 1A@30VDC
1 TTL, terminal block
80dB at 10cm
10/100 Mbps Ethernet (RJ-45)
RCA Input: 4 Line In
RCA Output: 1, Line Out
POS Interface, ATM Interface
Clip Copy Related
No. Description
No executable file.
13
Opening executable file failed.
14
Writing executable file failed.
15
Creating image failed.
16
Burning failed.
17
Burning is out of time.
18
Connecting device failed.
19
Device is busy.
20
Unsupported file system.
21
Verify failed.
22
Digital Video Recorder
75
