This publication, including photographs, illustrations and software, is
under the protection of international copyright laws, with all rights
reserved. Neither this guide, nor any of the material contained herein, may
be reproduced without the express written consent of the manufacturer.
The information in this document is subject to change without notice. The
manufacturer makes no representations or warranties with respect to the
contents hereof and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose. Further, the
manufacturer reserves the right to revise this publication and to make
changes from time to time in the content hereof without obligation of the
manufacturer to notify any person of such revision or changes.
Trademarks
IBM, VGA, and PS/2 are registered trademarks of International Business
Machines.
AMD, Athlon 64 Sempron are registered trademarks of Advanced Micro
Devices Inc.
Microsoft, MS-DOS and Windows 98/ME/NT/2000/XP are registered
trademarks of Microsoft Corporation.
AMI is a registered trademark of American Megatrends Inc.
Other names used in this publication may be trademarks and are acknowl-
edged.
Static Electricity Precautions
1. Don't take this motherboard and components out of their original
static-proof package until you are ready to install them.
2. While installing, please wear a grounded wrist strap if possible. If
you don't have a wrist strap, discharge static electricity by
touching the bare metal of the system chassis.
3. Carefully hold this motherboard by its edges. Do not touch those
components unless it is absolutely necessary. Put this
motherboard on the top of static-protection package with
component side facing up while installing.
Pre-Installation Inspection
1. Inspect this motherboard whether there are any damages to
components and connectors on the board.
2. If you suspect this motherboard has been damaged, do not connect
power to the system. Contact your motherboard vendor about
those damages.
Motherboard User's Guide
Copyright © 2007
All Rights Reserved
KN6100M Series, V3.0
i
May 2007
Advertisement
Table of Contents
Related Manuals for Mercury KN6100M
Summary of Contents for Mercury KN6100M
-
Page 1: Static Electricity Precautions
2. If you suspect this motherboard has been damaged, do not connect power to the system. Contact your motherboard vendor about those damages. Copyright © 2007 All Rights Reserved KN6100M Series, V3.0 May 2007... -
Page 2: Table Of Contents
Motherboard User’s Guide Table of Contents Trademark....................i Chapter 1: Introduction................1 Key Features....................1 Package Contents..................4 Chapter 2: Motherboard Installation............5 Motherboard Components.................6 I/O Ports....................7 Installing the Processor................7 Installing Memory Modules...............8 Jumper Settings..................10 Install the Motherboard................11 Connecting Optional Devices..............12 Install Other Devices................14 Expansion Slots ..................16 Chapter 3: BIOS Setup Utility...............20 Introduction....................20 Running the Setup Utility.................20... - Page 3 Motherboard User’s Guide Notice: 1. Owing to Microsoft’s certifying schedule is various to every supplier, we might have some drivers not certified yet by Microsoft. Therefore, it might happen under Windows XP that a dialogue box (shown as below) pops out warning you this software has not passed Windows Logo testing to verify its compatibility with Windows XP.
-
Page 4: Chapter 1 Introduction
Motherboard User’s Guide Chapter 1 Introduction This motherboard has a Socket AM2 supporting the newest and advanced AMD Athlon 64 FX/Athlon 64 X2 Dual-Core/Athlon 64/Sempron CPUs with HyperTransport Technology processors, Front-Side Bus (FSB) speeds up to 1000 MHz. This motherboard is based on MCP61 Value/MCP61 Standard media and communications processor that supports the Serial ATA interface for high- performance and mainstream desktop PCs, and the built-in USB 2.0 provid- ing higher bandwidth. - Page 5 Motherboard User’s Guide Two separate PCI Express controllers with 2 total lanes configured • as two x1 PCI Express lanes (MCP61 Value)/Three separate PCI Express controllers with ten total lanes configured as one x8 and two x1 PCI Express lanes (MCP61 Standard) Support 2 SATA2 3.0 Gb/s devices •...
- Page 6 Chapter 1: Introduction Fast Ethernet LAN (optional) Built-in 10Base-T/100Base-Tx IEEE 802.3u fast Ethernet • transceiver Low-power mode • MII and 7-wire serial interface • USB 2.0 Compliant with Universal Serial Bus Specification Revision 2.0 • Compliant with Universal Host Controller Interface Specification •...
-
Page 7: Package Contents
Motherboard User’s Guide Package Contents Your motherboard package ships with the following items: The motherboard The User’s Guide One diskette drive ribbon cable (optional) One IDE drive ribbon cable The Software support CD Optional Accessories You can purchase the following optional accessories for this motherboard. The Extended USB module The Serial ATA cable The Serial ATA power cable... -
Page 8: Chapter 2 Motherboard Installation
Chapter 2: Motherboard Installation Chapter 2 Motherboard Installation To install this motherboard in a system, please follow these instructions in this chapter: Identify the motherboard components Install a CPU Install one or more system memory modules Make sure all jumpers and switches are set correctly Install this motherboard in a system chassis (case) Connect any extension brackets or cables to headers/connectors on the motherboard... -
Page 9: Motherboard Components
Motherboard User’s Guide Motherboard Components ITEM LABEL COMPONENTS CPU_FAN CPU cooling fan connector Socket AM2 for AMD Athlon 64 FX/Athlon 64 X2 CPU Socket Dual-Core/Athlon 64 /Sempron processor DDRΙΙ1~2 240-pin DDR2 SDRAM slots Floppy Disk Drive connector PWR1 Standard 24-Pin AT X Power connector IDE1 Primary IDE connector SYS_FAN... -
Page 10: I/O Ports
Chapter 2: Motherboard Installation I/O Ports The illustration below shows a side view of the built-in I/O ports on the motherboard. PS/2 Mouse Use the upper PS/2 port to connect a PS/2 pointing device. Use the low er PS/2 port to connect a PS/2 PS/2 Keyboard keyboard. -
Page 11: Installing Memory Modules
Motherboard User’s Guide CPU Installation Procedure Follow these instructions to install the CPU: Unhook the locking lever of the CPU socket. Pull the locking lever away from the socket and raising it to the upright position. Match the pin1 corner marked as the beveled edge on the CPU with the pin1 corner on the socket. - Page 12 Chapter 2: Motherboard Installation Over its predecessor, DDR2-SDRAM offers greater bandwidth and density in a smaller package along with a reduction in power consumption. In addi- tion, DDR2-SDRAM offers new features and functions that enable a higher clock rate and data rate operations of 800/667/533/400 MHz. DDR2 trans- fers 64 bits of data twice every clock cycle.
-
Page 13: Jumper Settings
Motherboard User’s Guide Note for dual-channel DDR: 1. You CAN NOT use only one DIMM2 for it might cause the system shutdown. 2. You need to use DIMM1 and DIMM2 with the same size of memory modules. Jumper Settings Connecting two pins with a jumper cap is SHORT; removing a jumper cap from these pins, OPEN. -
Page 14: Install The Motherboard
Chapter 2: Motherboard Installation Install The Motherboard Install the motherboard in a system chassis (case). The board is an micro- ATX size motherboard. You can install this motherboard in an ATX case. Make sure your case has an I/O cover plate matching the ports on this motherboard. -
Page 15: Connecting Optional Devices
Motherboard User’s Guide Connecting Optional Devices Refer to the following for information on connecting the motherboard’s optional devices: SPK1: Speaker Header Connect the cable from the PC speaker to the SPK1 header on the motherboard. Sig n al SPKR F_AUDIO: Front Panel Audio Header This header allows the user to install auxiliary front-oriented microphone and line-out ports for easier access. - Page 16 Chapter 2: Motherboard Installation F_USB1/2: Front Panel USB Headers The motherboard has USB ports installed on the rear edge I/O port array. Additionally, some computer cases have USB ports at the front of the case. If you have this kind of case, use auxiliary USB headers F_USB1/2 to connect the front-mounted ports to the motherboard.
-
Page 17: Install Other Devices
Motherboard User’s Guide Install Other Devices Install and connect any other devices in the system following the steps below. Floppy Disk Drive The motherboard ships with a floppy disk drive cable that can support one or two drives. Drives can be 3.5" or 5.25" wide, with capacities of 360K, 720K, 1.2MB, 1.44MB, or 2.88MB. - Page 18 Chapter 2: Motherboard Installation Serial ATA Devices The Serial ATA (Advanced Technology Attachment) is the standard interface for the IDE hard drives, which is designed to overcome the design limitations while enabling the storage interface to scale with the growing media rate demands of PC platforms.
-
Page 19: Expansion Slots
Motherboard User’s Guide Expansion Slots This motherboard has one PCI Ex16, one PCI Ex1 slots, two 32-bit PCI slots and one optional CNR slot. - Page 20 Chapter 2: Motherboard Installation Follow the steps below to install an Ultra PCI Express/ PCI Express x1/ Azalia CNR/PCI expansion card. 1. Locate the Ultra PCI Express, PCI Express x1,Azalia CNR and PCI slots on the mainboard. 2. Remove the blanking plate of the slot from the system chassis. 3.
- Page 21 Motherboard User’s Guide Table A: Supported PCI-E 8X VGA Cards List VGA Chip Model Name ASUS EAX300LE A334C/TD ASUS EAX1600XT SILENT/TVD/256M/A ASUS EAX1300PRO/TD/256M/A ASUS EAX850XTP/2DHTV/256M/A ASUS EAX1800XT2DHTV/512M/A ATI RADEON X850 CrossFire Edition 256M Colorful ATI X300/TV Out 128M Colorful X800XL/CH 128MB DDR Colorful X1300-GD3 /128M/128bit/DDR3 Colorful X1300-GD2 UP 256M/128bit/DDR2 Colorful X1600PRO-GD3/128M/128bit/DDR3...
- Page 22 Chapter 2: Motherboard Installation VGA Chip Model Name ASL Power Stick 6600LE 256M 128Bit GD2 ASUS EN5750/A ASUS EN7800GTX/2DHTV/OSP/A ASUS EN5750/TD/P/128M ASUS EN6600LE/SILENCER/TD/256M/A ASUS EN6800XT/HTD/256M/V1.00 BD3466 V1.2 GeForce 6600/256M BD3493 6200TC 128M Colorful 6600GT/128M Colorful 7800GT/CH 512MB DDRIII ECS N6200LE-128TT DDR1 128M ECS N6200LE-128TY/128M/64bit/DDR2 ECS N6600LE-128DV DDR1 128M ECS N6600LE-256DY DDR2 256M...
-
Page 23: Chapter 3 Bios Setup Utility
Motherboard User’s Guide Chapter 3 BIOS Setup Utility Introduction The BIOS Setup Utility records settings and information of your computer, such as date and time, the type of hardware installed, and various configuration settings. Your computer applies the information to initialize all the components when booting up and basic functions of coordination between system components. -
Page 24: Standard Cmos Setup Page
Chapter 3: BIOS Setup Utility Some options on the main menu page lead to tables of items with installed values that you can use cursor arrow keys to highlight one item, and press PgUp and PgDn keys to cycle through alternative values of that item. The other options on the main menu page lead to dialog boxes requiring your answer OK or Cancel by selecting the [OK] or [Cancel] key. -
Page 25: Advanced Bios Features Page
Motherboard User’s Guide Video This item defines the video mode of the system. The motherboard has a built-in VGA graphics system; you must leave this item at the default value. Halt On Setting This item defines the operation of the system POST (Power On Self Test) routine. - Page 26 Chapter 3: BIOS Setup Utility CPU Feature (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phonex-AwardBIOS CMOS Setup Utility CPU Feature Help Item NPT Fid Control [Auto] NPT Vid Control [Auto] Use < > or < >...
- Page 27 Motherboard User’s Guide Hard Disk Boot Priority (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phonex-AwardBIOS CMOS Setup Utility Hard Disk Boot Priority Help Item 1. Ch2 M : WDCWD1600JS-22MHB0 Use < > or < > to select a de- 2.
- Page 28 Chapter 3: BIOS Setup Utility CD-ROM Boot Priority (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phonex-AwardBIOS CMOS Setup Utility Network Boot Priority Help Item 1. Network 0: NVIDIA Boot Agent 227.0524 Use < > or < > to select a device, then press <+>...
- Page 29 Motherboard User’s Guide Boot Up NumLock Status (On) This item defines if the keyboard Num Lock key is active when your system is started. Gate A20 Option (Fast) This item defines how the system handles legacy software that was written for an earlier generation of processors.
-
Page 30: Advanced Chipset Features Page
Chapter 3: BIOS Setup Utility Advanced Chipset Features Page These items define critical timing parameters of the motherboard. You should leave the items on this page at their default values unless you are very familiar with the technical specifications of your system hardware. If you change the values incorrectly, you may introduce fatal errors or recurring instability into your system. - Page 31 Motherboard User’s Guide Phonex-AwardBIOS CMOS Setup Utility DRAM Configuration Onboard GPU [Enable If No Ext GPU] Help Item Frame Buffer Size [64M] GPU Bank Flip [Disabled] [Disabled] CPU Frequency [200.0] Menu Level K8<->NB HT Speed [Auto] K8<->NB HT Width [Auto] DRAM Configuration [Press Enter] PCIE Spread Spectrum...
- Page 32 Chapter 3: BIOS Setup Utility Bottom of [31:24] IO space This item is used to select the memory that will be remapped higher than 00E0. Bottom of UMA DRAM [31:24] This item is used to set the bottom of UMA DRAM [31:24]. We strongly recommend that you leave this item at its default setting.
-
Page 33: Integrated Peripherals Page
Motherboard User’s Guide Integrated Peripherals Page These options display items that define the operation of peripheral components on the system’s input/output ports. Phonex-AwardBIOS CMOS Setup Utility Integrated Peripherals Help Item IDE Function Setup [Press Enter] RAID Config [Press Enter] Menu Level Onboard Device Setup [Press Enter] Super IO Device... - Page 34 Chapter 3: BIOS Setup Utility IDE DMA transfer access This item allows you to enable the transfer access of the IDE DMA then burst onto the PCI bus and nonburstable transactions do not. Serial-ATA Controller This item allows you to enable or disable the onboard SATA controller. IDE Prefetch Mode The onboard IDE drive interface supports IDE prefetching, for faster drive access.
- Page 35 Motherboard User’s Guide Onboard Device Setup (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phonex-AwardBIOS CMOS Setup Utility Onboard Device Setup Onchip USB [V1.1 + V2.0] Help Item USB Memory Type [SHADOW] USB Keyboard Support [Enabled] USB Mouse Support [Enabled]...
- Page 36 Chapter 3: BIOS Setup Utility SuperIO Device (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phonex-AwardBIOS CMOS Setup Utility SuperIO Device Help Item Onboard FDC Controller [Enabled] Onboard Serial Port 1 [3F8/IRQ4] Onboard Serial Port 2 [2F8/IRQ3] Menu Level UART Mode Select...
-
Page 37: Power Management Setup Page
Motherboard User’s Guide Power Management Setup Page Power Management Setup Page Power Management Setup Page Power Management Setup Page Power Management Setup Page This option lets you control system power management. The system has various power-saving modes including powering down the hard disk, turning off the video, suspending to RAM, and software power down that allows the system to be automatically resumed by certain events. - Page 38 Chapter 3: BIOS Setup Utility ware power down. If the item is set to Delay 4 Sec. then you have to hold the power button down for four seconds to cause a software power down. HPET Support This item enables or disables HPET support. Resume by PCI-E PME This system can be turned off with a software command.
-
Page 39: Pnp/Pci Configurations Page
Motherboard User’s Guide PnP/PCI Configurations Page These options configure how PnP (Plug and Play) and PCI expansion cards operate in your system. Both the the ISA and PCI buses on the motherboard use system IRQs (Interrup ReQuests) and DMAs (Direct Memory Access). You must set up the IRQ and DMA assignments correctly through the PnP/ PCI Configurations Setup utility for the motherboard to work properly. -
Page 40: Pc Health Status Page
Chapter 3: BIOS Setup Utility PC Health Status Page On motherboards that support hardware monitoring, this item lets you monitor the parameters for critical voltages, temperatures and fan speeds Phonex-AwardBIOS CMOS Setup Utility PC Health Status Smart Fan Function [Press Enter] Help Item Shutdown Temperature [Disabled]... - Page 41 Motherboard User’s Guide Shutdown Temperature Enables you to set the maximum temperature the system can reach before powering down. Warning Temperature Enables you to set the warning temperature before powering down. System Component Characteristics These fields provide you with information about the systems current operating status.
-
Page 42: Load Fail-Safe Defaults
Chapter 3: BIOS Setup Utility Load Fail-Safe Defaults This option opens a dialog box that lets you install fail-safe defaults for all appropriate items in the Setup Utility: Press <Y> and then <Enter> to install the defaults. Press <N> and then <Enter>... -
Page 43: Save & Exit Setup
Motherboard User’s Guide Save & Exit Setup Highlight this item and press <Enter> to save the changes that you have made in the Setup Utility and exit the Setup Utility. When the Save and Exit dialog box appears, press <Y> to save and exit, or press <N> to return to the main menu. -
Page 44: Chapter 4 Software & Applications
Chapter 4: Software & Applications Chapter 4 Software & Applications Introduction This chapter describes the contents of the support CD-ROM that comes with the motherboard package. The support CD-ROM contains all useful software, necessary drivers and utility programs to properly run our products. More program information is available in a README file, located in the same directory as the software. - Page 45 Motherboard User’s Guide The Browse CD button is a standard Windows command that you can check the contents of the disc with the Windows 98 file browsing interface. The Exit button closes the Auto Setup window. To run the program again, reinsert the CD-ROM disc in the drive;...
-
Page 46: Bundled Software Installation
Chapter 4: Software & Applications Note: To install the CNR card driver, please select the “Modem” item manually after the Auto Setup. Click on “Next >” and the CNR card driver will be installed automatically. The support software will automatically install. Once any of the installation procedures start, software is automatically installed in sequence. - Page 47 Motherboard User’s Guide...
