Mercury KVM400M-L User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
This publication, including all photographs, illustrations and
software, is protected under international copyright laws, with all
rights reserved. Neither this manual, nor any of the material
contained herein, may be reproduced without written consent of the
author.
The information in this document is subject to change without
notice. The manufacturer makes no representations or warranties
with respect to the contents hereof and specifically disclaims any
implied warranties of merchantability or fitness for any particular
purpose. Further, the manufacturer reserves the right to revise this
publication and to make changes from time to time in the content
hereof without obligation of the manufacturer to notify any person
of such revision or changes.
Trademarks
IBM, VGA, and PS/2 are registered trademarks of International
Business Machines.
Intel, Pentium/II/III, Pentium 4, Celeron and MMX are registered
trademarks of Intel Corporation.
Microsoft, MS-DOS and Windows 98/ME/NT/2000/XP are
registered trademarks of Microsoft Corporation.
PC-cillin is a registered trademark of Trend Micro Inc.
AMI is a registered trademark of American Megatrends Inc.
SiS is a trademark of Silicon Integrated System Corporation.
Other brands or product names in this manual are trademarks or the
properties of their respective owners and are acknowledged.
Copyright © 2004
All Rights Reserved
KVM400M-L Series, V1.3A
KM400/January 2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KVM400M-L and is the answer not in the manual?

Questions and answers

Related Manuals for Mercury KVM400M-L

Summary of Contents for Mercury KVM400M-L

  • Page 1 SiS is a trademark of Silicon Integrated System Corporation. Other brands or product names in this manual are trademarks or the properties of their respective owners and are acknowledged. Copyright © 2004 All Rights Reserved KVM400M-L Series, V1.3A KM400/January 2004...

  • Page 2: Table Of Contents

    Table of Contents Trademarks..................I Chapter 1: Introduction..............1 Key Features ................2 Package Contents..............5 Static Electricity Precautions...........6 Pre-Installation Inspection ............6 Chapter 2: Mainboard Installation..........7 Mainboard Components ............8 I/O Ports...................9 Installing the Porcessor............10 Installing Memory Modules ..........11 Jumper Settings..............12 Install the Mainboard.............13 Connecting Optional Devices ..........14 Install Other Devices .............16 Expansion Slots ..............19...
  • Page 3 Notice: 1. Owing to Microsoft’s certifying schedule is various to every supplier, we might have some drivers not certified yet by Microsoft. Therefore, it might happen under Windows XP that a dialogue box (shown as below) pop out warning you this software has not passed Windows Logo testing to verify its compatibility with Windows XP.

  • Page 5: Chapter 1: Introduction

    Chapter 1 Introduction This mainboard has a Socket-462 processor socket for the AMD K7 type of processors. You can install any of these processors on this mainboard. This mainboard supports front-side bus speed of 200/166 MHz. This mainboard integrates the VIA KM400A/400 Northbridge along with VT8237/8235CE Southbridge chipsets that supports built-in AC97 Codec, 2 DDR400/333 modules up to 2GB system memory.

  • Page 6: Key Features

    Key Features This mainboard has the following key features: Socket-462 Processor Support ♦ Supports AMD Athlon XP/Athlon/Duron processors ♦ Supports 200 MHz Front-Side Bus (with NB KM400A) or 166 MHz Front-Side Bus (with NB KM400) Chipset There are VIA KM400A/400 Northbridge and VT8237/8235CE Southbridge in this chipset in accordance with an innovative and scalable architecture with proven reliability and performance.
  • Page 7 Power Supply and Power Management ♦ ATX power supply connector ♦ Meets ACPI 1.0b and APM 1.2 requirements, keyboard power on/off ♦ Supports RTC Alarm, Wake On Modem, AC97 Wake-Up and USB Wake-Up AC97 Audio Codec ♦ Compliant with AC’97 2.1 specification ♦...
  • Page 8 ♦ MII Interface to Ethernet Controller/Configuration & Status ♦ Auto Negotiation: 10/100, Full/Half Duplex ♦ Meet All Applicable IEEE802.3, 10Base-T and 100Base- TX Standards USB 2.0 ♦ Compliant with Universal Serial Bus Specification Revision 2.0 ♦ Compliant with Intel’s Enhanced Host Controller Interface Specification Revision 0.95 ♦...

  • Page 9: Package Contents

    Package Contents Your mainboard package contains the following items: The mainboard The User’s Manual One diskette drive ribbon cable (optional) One IDE drive ribbon cable Software support CD Optional Accessories You can purchase the following optional accessories for this mainboard. Extended USB module CNR v.90 56K Fax/Modem card Card Reader (You can buy your own Card Reader from the...

  • Page 10: Static Electricity Precautions

    Static Electricity Precautions Static electricity could damage components on this mainboard. Take the following precautions while unpacking this mainboard and installing it in a system. 1. Don’t take this mainboard and components out of their original static-proof package until you are ready to install them. 2.

  • Page 11: Chapter 2: Mainboard Installation

    Chapter 2 Mainboard Installation To install this mainboard in a system, please follow the instructions in this chapter: Identify the mainboard components Install a CPU Install one or more system memory modules Verify that all jumpers or switches are set correctly Install the mainboard in a system chassis (case) Connect any extension brackets or cables to connectors on the mainboard...

  • Page 12: Mainboard Components

    Mainboard Components Identify major components on the mainboard via this diagram underneath. Note 1: Any jumpers on your mainboard not appearing in the illustration above are for testing only. Note 2: There will be two extra USB connectors (USB2 & USB3) and two Serial ATA connectors (J4 &...

  • Page 13: I/O Ports

    I/O Ports The illustration below shows a side view of the built-in I/O ports on the mainboard. (optional) (shared with J6) PS/2 Mouse Use the upper PS/2 port to connect a PS/2 pointing device. PS/2 Keyboard Use the lower PS/2 port to connect a PS/2 keyboard.

  • Page 14: Installing The Processor

    Installing the Processor This mainboard has a Socket 462 processor socket. When choosing a processor, consider the performance requirements of the system. Performance is based on the processor design, the clock speed and system bus frequency of the processor, and the quantity of internal cache memory and external cache memory.

  • Page 15: Installing Memory Modules

    Installing Memory Modules This mainboard accommodates two 184-pin 2.5V unbuffered Double Data Rate SDRAM (DDR SDRAM) Dual Inline Memory Module (DIMM) sockets, and supports up to 2.0 GB of DDR400 SDRAM with KM400A NB or DDR333 SDRAM with KM400 DDR SDRAM is a type of SDRAM that supports data transfers on both edges of each clock cycle (the rising and falling edges), effectively doubling the memory chip’s data throughput.

  • Page 16: Jumper Settings

    cutout on the DIMM module with the notch on the DIMM socket. 3. Install the DIMM module into the socket and press it firmly down until it is seated correctly. The socket latches are levered upwards and latch on to the edges of the DIMM.

  • Page 17: Install The Mainboard

    Jumper JP3: CPU Clock Selector This jumper selects the processor clock frequency. CPU Clock Pins 1-2 Pins 3-4 133 MHz 166 MHz 100 MHz 200 MHz Install the Mainboard Install the mainboard in a system chassis (case). The board is a FLEX ATX size mainboard.

  • Page 18: Connecting Optional Devices

    Signal Signal HD_LED_P FP PWR/SLP HD_LED_N FP PWR/SLP RESET_SW_N POWER_SW_P RESET_SW_P POWER_SW_N RSVD_DNU Connecting Optional Devices Refer to the following for information on connecting the mainboard’s optional devices: AUDIO1 SIR1 USB3 USB2 SPK1 SPK1: Speaker Connector Connect the cable from the PC speaker to the SPK1 connector on the mainboard.
  • Page 19 USB2 & USB3: Front panel USB Connector The mainboard has USB ports installed on the rear edge I/O port array. Additionally, some computer cases have USB ports at the front of the case. If you have this kind of case, use auxiliary USB connector USB2/USB3 to connect the front-mounted ports to the mainboard.

  • Page 20: Install Other Devices

    Please check the pin assignment of the cable and the USB header on the mainboard. Make sure the pin assignment will match before plugging in. Any incorrect usage may cause unexpected damage to the system. The vendor won’t be responsible for any incidental or consequential damage arising from the usage or misusage of the purchased product.
  • Page 21 Floppy Disk Drive The mainboard ships with a floppy disk drive cable that can support one or two drives. Drives can be 3.5” or 5.25” wide, with capacities of 360K, 720K, 1.2MB, 1.44MB, or 2.88MB. Install your drives and connect power from the system power supply.
  • Page 22 The SATA connector supports new Serial ATA devices for the highest data transfer rates (1.5 Gbps burst), simpler disk drive cabling and easier PC assembly. It eliminates limitations of the current Parallel ATA interface, but maintains register compatibility and software compatibility with Parallel ATA. Internal Sound Connections If you have installed a CD-ROM drive or DVD-ROM drive, you can connect the drive audio cable to the onboard sound system.

  • Page 23: Expansion Slots

    Expansion Slots This mainboard has one AGP, one CNR and two 32-bit PCI slots. AGP1 CNR1 PCI2 PC1 PCI1 Follow the steps below to install an AGP/CNR/PCI expansion card. 1. Locate the AGP, PCI or CNR slot on the mainboard. 2.

  • Page 24: Chapter 3: Bios Setup Utility

    Chapter 3 BIOS Setup Utility Introduction The BIOS Setup Utility records settings and information about your computer such as the date and time, the kind of hardware installed, and various configuration settings. Your computer uses this information to initialize all the components when booting up and functions as the basis for coordination between system components.

  • Page 25: Running The Setup Utility

    Running the Setup Utility Each time your computer starts, before the operating system loads, a message appears on the screen that prompts you to “Hit <DEL> if you want to run SETUP”. When you see this message, press the Delete key and the Main menu page of the Setup Utility appears on your monitor.

  • Page 26: Standard Cmos Setup Page

    Standard CMOS Setup Page This page sets up basic information such as the date, the time, the IDE devices, and the diskette drives. If you press the F3 key, the system will automatically detect and configure the hard disks on the IDE channels.

  • Page 27: Advanced Setup Page

    Advanced Setup Page This page sets up more advanced information about your system. Take care of this page with more caution. Any changes can affect the operation of your computer. AMIBIOS SETUP – ADVANCED SETUP (C) 2000 American Megatrends, Inc. All Rights Reserved Quick Boot Enabled Boot Device...
  • Page 28 BootUp Num-Lock This item determines if the Num Lock key is active or inactive at system start- up time. Floppy Drive Swap If you have two diskette drives installed and you enable this item, drive A becomes drive B and drive B becomes drive A.

  • Page 29: Power Management Setup Page

    SDRAM CAS# This item determines the operation of Latency SDRAM memory CAS (column address strobe). It is recommended that you leave this item at the default value. The 2T setting requires faster memory that specifically supports this mode. SDRAM Bank Enable this item to increase SDRAM Interleave memory speed.
  • Page 30 ACPI Aware O/S Enable this item if you are using an O/S that supports ACPI function such as Windows 98/ME /2000. Power Use this item to select a power management Management scheme. Both APM and ACPI are supported. Suspend Time Out This sets the timeout for Suspend mode in minutes.

  • Page 31: Pci/Plug And Play Setup Page

    PCI / Plug and Play Setup Page This page sets some of the parameters for devices installed on the PCI bus and devices that use the system plug and play capability. AMIBIOS SETUP – PCI / PLUG AND PLAY SETUP (C) 2000 American Megatrends, Inc.

  • Page 32: Load Optimal Settings

    Load Optimal Settings If you select this item and press Enter a dialog box appears. If you press Y, and then Enter, the Setup Utility loads a set of fail-safe default values. These default values are not very demanding and they should allow your system to function with most kinds of hardware and memory chips.
  • Page 33 OnBoard Serial Use these items to enable or disable the PortA onboard COM1 serial port, and to assign a port address. OnBoard IR Port Use this item to enable or disable the onboard infrared port, and to assign a port address. Onboard Parallel Use this item to enable or disable the onboard Port...

  • Page 34: Cpu Pnp Setup Page

    CPU PnP Setup Page This page lets you manually configure the mainboard for the CPU. The system will automatically detect the kind of CPU that you have installed and make the appropriate adjustments to the items on this page. AMIBIOS SETUP – CPU PnP SETUP ©2000 American Megatrends, Inc.

  • Page 35: Hardware Monitor Page

    Hardware Monitor Page This page sets some of the parameters for the hardware monitoring function of this mainboard. AMIBIOS SETUP – HARDWARE MONITOR (C) 2000 American Megatrends, Inc. All Rights Reserved *** System Hardware *** Vcore 1.616V Vdimm 2.496V Vivdd 2.496V Vcc5V 4.972V...

  • Page 36: Exit

    Change or Remove the Password Highlight this item, press Enter and type in the current password. At the next dialog box, type in the new password, or just press Enter to disable password protection. Exit Highlight this item and press Enter to save the changes that you have made in the Setup Utility configuration and exit the program.

  • Page 37: Chapter 4: Software & Applications

    Chapter 4 Software & Applications Introduction This chapter describes the contents of the support CD-ROM that comes with the mainboard package. The support CD-ROM contains all useful software, necessary drivers and utility programs to properly run our products. More program information is available in a README file, located in the same directory as the software.

  • Page 38: Installing Support Software

    Installing Support Software 1.Insert the support CD-ROM disc in the CD-ROM drive. 2.When you insert the CD-ROM disc in the system CD-ROM drive, the CD automatically displays an Auto Setup screen. 3.The screen displays three buttons of Setup, Browse CD and Exit on the right side, and three others Setup, Application and ReadMe at the bottom.
  • Page 39 Auto-Installing under Windows 98/ME/2000/XP If you are under Windows 98/ME/2000/XP, please click the Setup button to run the software auto-installing program while the Auto Setup screen pops out after inserting the support CD-ROM: 1. The installation program loads and displays the following screen.

  • Page 40: Bundled Software Installation

    Installing under Windows NT or Manual Installation If you are under Windows NT, the auto-installing program doesn’t work out; or you have to do the manual installation, please follow this procedure while the Auto Setup screen pops out after inserting the support CD-ROM: 1.
