CHASSIS SYSTEM

The chassis system on the Magnum series is built on a heavy duty 7 gauge powder-coated
full frame. The frame gives the machine great strength and durability. Everything is fas-
tened to the frame using stainless steel hardware allowing for easy servicing should a
repair be needed. .

CHASSIS REPLACEMENT

In the unlikely even that the chassis must be replaced due to collision or damage it can
easily be done. We recommend transferring the components piece by piece from the old
chassis to the new chassis and installing the tank last on the new chassis.

TIRES

There are 5 different tire options for the Magnum series of scrubbers. We offer pneumatic
tires as a standard tire, grey tires for non marking applications. Both the black and grey
tires are available foam filled but come with a 90 day warranty. There is also a HD tire op-
tion which is a solid tire

CASTERS

There are 2 different types of casters available on the Magnum series. There are the red
polyurethane casters which provide very good resistance to oil and grease and roll very
well making the machine easier to steer. There are also grey rubber tires which are a softer
tire making the machine roll a bit smoother but they do not hold up well in solvents or
harsh environments.
