Ltl Acorn AG-680M Series User Manual

Mms/gprs most cost-effective scouting trail camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

MMS/GPRS Most Cost-effective
Scouting Trail Camera
1.
Introduction ........................................................................................................................ - 1 -
1.1 Fully Functionality Introduction .................................................................................... - 1 -
1.2 Application ..................................................................................................................... - 1 -
1.3 Power Supply ................................................................................................................. - 1 -
1.4 Attention ......................................................................................................................... - 2 -
1.5 Key Features .................................................................................................................. - 2 -
2.
Whole View and Details of Camera .................................................................................. - 3 -
2.1 Figure 1: Front View of Camera; ................................................................................... - 3 -
2.2 Figure 3.2: Bottom View of Camera; ............................................................................. - 4 -
2.3 Figure 3.3: Side and Back View of Camera. .................................................................. - 5 -
2.4 Figure 3.4: Internal View of Camera .............................................................................. - 6 -
2.5 Function Keys & Other Details ...................................................................................... - 6 -
3.
Quick Start .......................................................................................................................... - 7 -
3.1 How to start the camera? ................................................................................................ - 7 -
3.2 How to set the functions? ............................................................................................... - 7 -
4.
Operation List .................................................................................................................... - 8 -
4.1 Video/Photo Playback .................................................................................................... - 8 -
4.2 Delete: ............................................................................................................................ - 8 -
4.3 Format of SD Card ......................................................................................................... - 8 -
4.4 Operation Menu ............................................................................................................. - 8 -
5.
Specification ...................................................................................................................... - 10 -
6.
Phone SMS Message Remote Command Orders .......................................................... - 12 -
7.
SD Cards Selection and Battery Life Test Report ......................................................... - 13 -
7.1 SD Card Selection ........................................................................................................ - 13 -
7.2 Battery Life Test Report for Reference ........................................................................ - 14 -
8.
Trouble Shooting .............................................................................................................. - 14 -
8.1 Photos Do Not Capture Subject of Interest .................................................................. - 14 -
8.2 Camera stops taking images or won't take images ...................................................... - 14 -
9.
Warranty ........................................................................................................................... - 15 -
Acorn Guard
AG-680M Series
USER'S MANUAL
Contents
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AG-680M Series and is the answer not in the manual?

Questions and answers

Related Manuals for Ltl Acorn AG-680M Series

Summary of Contents for Ltl Acorn AG-680M Series

  • Page 1: Table Of Contents

    Acorn Guard ® MMS/GPRS Most Cost-effective Scouting Trail Camera AG-680M Series USER’S MANUAL Contents Introduction ........................- 1 - 1.1 Fully Functionality Introduction ..................- 1 - 1.2 Application ........................- 1 - 1.3 Power Supply ......................... - 1 - 1.4 Attention .........................

  • Page 2: Introduction

    1. Introduction Thank you for choosing one of AcornGuard easy operation highly qualified products. You now may enjoy the excellences reflected on this series product. This 12MP HD digital camera was totally R&D by our diligent and smart engineers based on feedbacks and requirements from customers globally.

  • Page 3: Attention

    To bring users better using experience, our engineers designed this camera to be able to work with most standard 6~12V lithium battery build-in solar panels. C. Power Adaptor—Security Surveillance Purpose This camera can also be powered by an external 6~12V DC adapter. Recommend to remove the alkaline batteries when power adapter is used, to avoid surcharging.

  • Page 4: Whole View And Details Of Camera

    q. Audio Recording brings you heart pumping like ever before; r. Two different TV OUT settings help you review photos/videos even from Television. Below are for GPRS Model only s. With SMS/MMS/GPRS/SMTP/HTTP function, camera can transmit photos to 1-4 settled mobile phones and 1-4 email accounts according to set intervals constantly at lower battery consumption.
  • Page 5 2.2 Figure 3.2: Bottom View of Camera; Push slightly to open this cover TV Out DC in USB Port SD Card Slot Battery Slot - 4 -...
  • Page 6 2.3 Figure 3.3: Side and Back View of Camera. GPRS module Slot Battery Slot Push here to open battery slot and GPRS module slot cover - 5 -...

  • Page 7: Function Keys & Other Details

    2.4 Figure 3.4: Internal View of Camera Introduction of each button a) Press Buttons 01: Menu; 02/ 03/ 04/ 05: navigation arrow buttons; 06: OK b) Switch Buttons 07: Power Switch; 08: Camera/Video Switch; 09: IR LEDs Group Switch; 10: GPRS Switch 2.5 Function Keys &...

  • Page 8: Quick Start

    Navigation buttons a) Power Switch by “On”, press “OK” once to wake up camera LCD screen to enter TEST Mode; b) Test mode, Press “Menu” once to enter camera setting menu; Press “OK” to shoot photo(s) or video clips. c) To navigate the interface by pressing “←”, “↑”, “→”, or “↓”, press “OK” for selection.

  • Page 9: Operation List

    4. Operation List 4.1 Video/Photo Playback In Test Mode without pressing button “Menu”: press arrow button “↑” to enter Playback; press “←” and “→” for selection, “OK” to play photo/video. Press button “↑” again to return. Press “Menu” button to initiate Deletion of files or Format of SD card.
  • Page 10 environment temperature is hard to tell by camera, suggest set High. Select “ON”, to set the beginning time and end time 10. Timer (hour/minute); camera will only work during the time user set. Select “ON”, to set the interval; PIR sensor of camera will be turned off;...

  • Page 11: Specification

    Note: APN will be entered automatically if you select your operator in “Country Set” 2) Enter your mailbox IP; i.e.: Hotmail IP: smtp.hotmail.com; Gmail IP: smtp.gmail.com; 3) Enter your mailbox port; Port of most mailbox is 25; plz enter your mailbox corresponding port. 4) Enter your mailbox password access.
  • Page 12 Effective Pixels 2560x1920 Day/Night Mode IR arrange IR Setting Top: 19 LED, Foot: 21LED Memory SD Card (8MB – 32 GB) Operating keys Lens F=3.0; FOV=52°; Auto IR-Cut-Remove (at night) LCD Screen 2” TFT, RGB, 262k PIR Sensitivity 3 sensitive levels: High / Normal / Low PIR distance 12m –...

  • Page 13: Phone Sms Message Remote Command Orders

    6. Phone SMS Message Remote Command Orders All SMS message order codes start with “*”, end with “#”. Camera GPRS module will confirm back to preset phone(s)/ email(s)/ FTP account with a successful configured notification message upon every single remote SMS command order message.

  • Page 14: Sd Cards Selection And Battery Life Test Report

    Represent time with 2 digits, i.e.: Camera only shoot photos/videos 2h 24m 21s: 022421 10*022421# every 2hours 24minutes 21seconds upon motion. Timer: 11*# Represent time with 2 digits, hyphen to connect beginning time and end time; Camera works only between 2:01:30 i.e.: 11*020130-160510# a.m.

  • Page 15: Battery Life Test Report For Reference

    Pls check to see which size card can fit your needs best. Size 2 GB 4 GB 8 GB 16 GB 32 GB Capacity Photo (pictures) 1373 2823 5517 11141 244962 8 MP 1813 3544 7157 14241 12 MP 1575 3181 6326 Video (hours)

  • Page 16: Gprs Version Camera Stops Sending Photos To Email Or Mobiles

    taking images. Or user can turn on Cycle Recording to avoid such problem. 2. Check batteries to make sure that alkaline or lithium AA batteries left power is enough for camera to work. 3. Make sure that the camera power switch is in the “On” position and not in the “Off”...
