Configuration

5x
Various instrument functions are
switched on and off via the
configuration menu.
Click the distance key five times
in rapid succession. "COn FIG"
appears followed by the current
range setting.
VECTOR ™- USMC VECTOR 21-V.0.3
Click the azimuth key until the
desired function status appears.
The various functions are
i
described in detail on the
following pages.
www.
Shop for Vectronix products online at:
28
SCOUTBASECAMP
.com 1.877.766.5412

Making adjustments

5x
Click the distance key five times
in rapid succession to save your
settings.
If the distance key is not correctly
clicked five times, the previous
settings remain unchanged and
"Old Conf" is displayed.
