Vectronix USMC VECTOR 21 Operating & Operator Maintenance Instructions page 2

VECTOR™
Congratulations on purchasing
your VECTOR.
VECTOR = 4 instruments in 1:
• Binoculars
Superb optics in a robust,
watertight, rubber-armoured
casing.
• Digital Compass
Displays magnetic azimuth or
grid azimuth in degrees or
mils.
• Laser Rangefinder
Measures from 5 m to over
10 km (depending on visibility
and nature of target objects).
• Inclinometer
Displays vertical angles
between -45° and +45°.
VECTOR ™- USMC VECTOR 21-V.0.3
As its name implies, the
VECTOR measures the polar
vector from your position to the
target object.
For safe use of the VECTOR, please note the detailed safety
directions included in this manual.
© 2004 Vectronix AG, ® All rights reserved.
www.
Shop for Vectronix products online at:
2
SCOUTBASECAMP
.com 1.877.766.5412
r Range (slope distance)
a Azimuth (bearing, horizontal
direction, angle between
north and object)
v Vertical angle (inclination,
elevation)
VECTOR™
