Multiple object measurement

Up to 3 separate distances can
be obtained with a single meas-
urement, for example when:
• the laser beam passes through
objects in front of the main
target (bushes, shrubs, etc.)
• there are reflective objects
behind the main target
(mountains, etc.)
VECTOR ™- USMC VECTOR 21-V.0.3
This feature is always
i
activated. The order of the
displayed ranges is: closest,
strongest between first and last,
and furthest detected echo.
Sight on the most visible portion
of the object. Operate the
VECTOR as described under
"distance measurement".
www.
Shop for Vectronix products online at:
12
SCOUTBASECAMP
.com 1.877.766.5412
The distance display blinks for a
few seconds after a multiple
distance measurement. Click the
distance key repeatedly to
obtain all the measured
distances in succession.
Distance measurements
