Icom IC-7400 Service Manual page 58

[PA UNIT]
REF ORDER
NO. NO.
MP3 8930047110 RUBBER SHEET (AP)
MP4 8930047120 RUBBER SHEET (AQ)
MP7 8930001180 EARTH PLATE (FX-22)
MP8 8860001450 2178 RUG
MP201 8860001450 2178 RUG
[TUNER UNIT]
REF ORDER
NO. NO.
RL1* 6330001610 NY-12W-K-IE
RL2* 6330001610 NY-12W-K-IE
RL3* 6330001610 NY-12W-K-IE
RL4* 6330001610 NY-12W-K-IE
RL5* 6330001520 VE-12HM-K
RL6* 6330001520 VE-12HM-K
RL7* 6330001520 VE-12HM-K
RL8* 6330001520 VE-12HM-K
RL9* 6330001520 VE-12HM-K
RL10* 6330001610 NY-12W-K-IE
RL11* 6330001610 NY-12W-K-IE
RL12* 6330001610 NY-12W-K-IE
RL13* 6330001610 NY-12W-K-IE
RL14* 6330001610 NY-12W-K-IE
RL15* 6330001610 NY-12W-K-IE
J3 6510007900 TBP-P01X-A1
J4* 6510007900 TBP-P01X-A1
J5* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN)
P3 6510003240 TMP-P01X-A1
P4 6510003240 TMP-P01X-A1
MF1 2710000800 MP24ZA
MF2 2710000800 MP24ZA
WS1 8970022710 SX1876 1.5D (2)/TU (Incl. J3, P3)
W1 9018760110 62/99/190/C24/C31
W2 9086700300 WIRE 8
W3 9018760110 62/99/190/C24/C31
W4 9086700300 WIRE 8
W5 8900015420 OPC-1630
W6 8900015420 OPC-1630
MP1 8930041091 1876 A-ANGLE-1
MP2 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP3 8810009061 SCREW M3X6 ZK3
MP4 8930041111 1876 B-ANGLE-1
MP5 8810009061 SCREW M3X6 ZK3
MP6 8820000881 1528 SCREW-1
MP7 8930030112 1414 PLATE-2
MP8 8950003200 UJ6-5 (UNIVERSAL COUPLINGS)
MP9 8930051580 2178 TUNER PLATE
DESCRIPTION QTY.
DESCRIPTION QTY.
[CTRL UNIT]
REF ORDER
NO. NO.
1 RL1* 6330001460 FTR-F1 CA012V
1 RL2* 6330001460 FTR-F1 CA012V
1 RL3* 6330001460 FTR-F1 CA012V
2 RL4* 6330000470 AE5343 (NR-HD 12V)
2
J1* 6510007020 TMP-J01X-V6
J2 6510007900 TBP-P01X-A1
J3* 6510007020 TMP-J01X-V6
J4* 6510007020 TMP-J01X-V6
J7* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN)
J8* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN)
J10* 6510003411 B05B-EH-S (LF) (SN)
J11* 6510003411 B05B-EH-S (LF) (SN)
1
J13 6510009870 PD054-02M
1
J14* 6510018961 B2B-PH-SM4-TB (LF) (SN)
1
1
P2 6510003240 TMP-P01X-A1
1
P3 6510018980 PHR-2
1
1
WS1 8600036850 SX2494 P03*J13CT (Incl. J13, P3, W13, 14)
1
WS2 8970023961 SX2494 1.5DA (1)/CT
1
(Incl. J2, P2, W51, 52, EP2, MP2)
1
1
W3 7120000490 ERD25T0
1
W11 7120000490 ERD25T0
1
W12 7120000490 ERD25T0
1
W13 9020720140 51/99/530/B11A/D33A
1
W14 9011130780 WIRE 00 A A
W51 9009130167 62/99/420/C24/C31
1
W52 9086700300 WIRE 8
1
1
EP2 6910000630 FSOH070RN
1
MP1 8510014440 2494 SHIELD CASE
1
MP2 8950000180 CABLE TIE -80
MP4 8510005521 VCOSHIELD PLATE (A)-1 (SX-644)
1
1
[ACCESSORY]
1
REF ORDER
1
NO. NO.
1
1
P1 5610000410 AP-319
1
1
MC1 (Optional) HM-36-1
1
F1 5210000090 FGB 30A
1
F2 5210000061 FGB 5A PBF
1
4
W1 8900006490 OPC-025D
1
2
4
2
2
1 W1
F1
F2
7 - 6
DESCRIPTION
DESCRIPTION
MC1
P1
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
QTY.
1
1
2
1
1
