Icom IC-7400 Service Manual page 52

[FILTER UNIT]
REF ORDER
NO. NO.
L1 6140003440 COI LR-386 (FK-100E-5003H)
L2 6140003440 COI LR-386 (FK-100E-5003H)
C1 4030004740 S.CER C2012 JB 1H 472K-T
C2 4030008960 S.CER C2012 JB 1C 104K-T
C5 4030004740 S.CER C2012 JB 1H 472K-T
C6 4030004740 S.CER C2012 JB 1H 472K-T
C7 4030008960 S.CER C2012 JB 1C 104K-T
C8 4030008960 S.CER C2012 JB 1C 104K-T
C9 4030008960 S.CER C2012 JB 1C 104K-T
C10 4030004740 S.CER C2012 JB 1H 472K-T
C12 4030008960 S.CER C2012 JB 1C 104K-T
C13 4030004740 S.CER C2012 JB 1H 472K-T
C15 4030008960 S.CER C2012 JB 1C 104K-T
C16 4030004740 S.CER C2012 JB 1H 472K-T
C18 4030008960 S.CER C2012 JB 1C 104K-T
C19 4030004740 S.CER C2012 JB 1H 472K-T
EP2 6910011330 TER OT-009 M3
EP3 6910011330 TER OT-009 M3
EP4 6910011330 TER OT-009 M3
EP5 6910011330 TER OT-009 M3
DESCRIPTION
[DRV UNIT]
REF ORDER
NO. NO.
Q1 1560001030 S.FET
Q2 1560001030 S.FET
R1 7030000020 S.RES MCR10EZHJ 1 (010)
R2 7030000020 S.RES MCR10EZHJ 1 (010)
R3 7030000020 S.RES MCR10EZHJ 1 (010)
R4 7030000020 S.RES MCR10EZHJ 1 (010)
R5 7030000260 S.RES MCR10EZHJ 100 (101)
R6 7030000260 S.RES MCR10EZHJ 100 (101)
R7 7030010970 S.RES ERJ1TYJ 151U
R8 7030010970 S.RES ERJ1TYJ 151U
C1 4030008960 S.CER C2012 JB 1C 104K-T
C2 4030008960 S.CER C2012 JB 1C 104K-T
C3 4030011180 S.CER GRM31M2C2H220JV01L(GRM42-6 CH)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 24
DESCRIPTION
2SK2975 (MTS103)
2SK2975 (MTS103)
S.=Surface mount
