Icom IC-7400 Service Manual page 54

[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6510001920 1490R
J5 6510000370 MR-DS
J6 6510000370 MR-DS
J7 6510000370 MR-DS
P1 5610000360 LLR-06V (Incl. W2, W4, W5, EP1, EP2)
P2 6510018990 PHR-4
P3 6510018980 PHR-2
P51 6510003240 TMP-P01X-A1
P52 6510003240 TMP-P01X-A1
SP1 2510000761 SM-C77KY0208
MF1 2710000630 FBA08T12HC
WS1 8600036212 SX2072 P01CH-2
WS2 8600036222 SX2072 P02*J01CH-2
(Incl. J1, P2, W6–9, EP5, MP70)
WS3 8600036232 SX2072 P03CH-2
WS4 8970023980 SX2494 1.5Dcoax cable (1)/CH
W1 9020720210 11/02/050/B03/X99
W2 9020720210 11/02/050/B03/X99
W3 9020720200 11/00/050/B03/X99
W4 9020720200 11/00/050/B03/X99
W5 9009630450 13/05/050/B03/B03
W6 9020720090 15/01/220/A08/B11
W7 9020720100 15/02/220/A08/B11
W8 9020720110 15/03/220/A08/B11
W9 9020720120 15/04/220/A08/B11
W10 9020720170 51/99/090/B11Y/W19A
W11 9012410001 WIRE 00 A
W12 8900007160 OPC-700
W13 8900007170 OPC-701
W14 8900009271 OPC-912A
W15 8900009271 OPC-912A
W16 8900015500 OPC-1113A
W17 8900015510 OPC-1114A
W18 8900015160 OPC-916A
W23 8900015160 OPC-916A
W50 9024940010 62/99/420/C31/C31
W51 9086700300 WIRE 8
EP1 6510015940 2-S3.3
EP2 6510015940 2-S3.3
EP3 6910000340 P101 KD*
EP4 6910000310 B312D*
EP5 6910000640 FSOH090RN
EP6 6910020820 SR TUBE 2.9X4 CP L=60MM
MP1 8010017225 2072 CHASSIS-5
MP2 8110006361 2072 T-COVER-1 (incl. MP12)
MP3 8110006351 2072 L-COVER-1
MP4 8110006371 2072 SHIELD COVER-1
MP5 8930045172 2072 A-PLATE-2
MP6 8930041351 1876 MAIN STAND-1
MP7 8930041341 1876 SUB STAND-1
MP8 8930029731 1413 FAN HOLDER-1
MP9 8930037001 1691 EARTH PLATE-1
MP10 8930018520 TR(A) CLIP
MP12 8930036070 1528 SP NET
MP13 8810005771 SCREW BiH M3X8 ZK3
MP14 8810005771 SCREW BiH M3X8 ZK3
MP15 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP16 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP17 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP18 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP19 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP20 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP21 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP22 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP23 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP24 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP25 8810005771 SCREW BiH M3X8 ZK3
MP26 8810003171 SETSCREW (A) 3X8 ZC3
MP27 8810000421 SCREW PH M4X18 ZC3
MP28 8810009311 SCREW B0 3X6 NI-ZC3 (BT)
MP29 8930042690 RUBBER REG (L)
MP30 8930017190 EARTH SPRING (F)
MP31 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP32 8820000530 FLANGE BOLT M4X8 NI
MP33 8930077650 3073 SIDE HANDLE
MP34 8810003371 SETSCREW (C) 3X8 ZC3
MP35 8810003171 SETSCREW (A) 3X8 ZC3
MP36 8810010870 SCREW M4X12 ZK3
MP37 8930046120 RUBBER REG (M)
MP38 8930046120 RUBBER REG (M)
MP39 8850000430 S-WASHER M4 NI
MP40 8850000140 FLAT WASHER M4 BS NI
MP41 8810003161 SETSCREW (A) 3X6 ZC3
MP42 8810003161 SETSCREW (A) 3X6 ZC3
MP43 8810003161 SETSCREW (A) 3X6 ZC3
MP50 8930043800 DOUBLESIDED TAPE (S)
MP51 8930046642 2072 RF PLATE-2
MP53 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP55 8930015640 (SX-713)
MP56 8930047291 2072 A-FILTER PLATE-1
MP58 8810003161 SETSCREW (A) 3X6 ZC3
MP59 8930046720 2072 BUSH
DESCRIPTION QTY.
[CHASSIS PARTS]
REF ORDER
NO. NO.
1
MP60 8930007840 THERMAL SHEET (K)
1 MP63 8930047220 SPONGE (FT)
1
MP64 8850001710 SEALING WASHER (R)
1
MP65 8930047100 2072 SP SPONGE
MP66 8930047090 SPONGE (FP)
1 MP67 8930047070 SPONGE (FQ)
1
MP68 8930047050 THERMAL SHEET (BU)
1
MP70 8950000180 CABLE TIE -80
1
MP71 8930025070 SPONGE (CW)
1 MP72 8930004070 EARTH SPRING (C) (SX-166)
MP73 8930038820 ALMINIUM SHEET (V)
1
MP75 8930055981 SHIELD SPONGE (F)-1
MP76 8930055981 SHIELD SPONGE (F)-1
1 MP77 8930054521 SHIELD SPONGE (E)-1
MP78 8930058140 SPONGE (GX)
1
MP81 8930043800 DOUBLESIDED TAPE (S)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
3
2
1
12
6
8
8
10
7
4
4
11
2
6
1
2
9
4
4
2
1
2
1
1
2
1
2
2
2
1
1
2
4
4
1
1
4
1
1
1
1
7 - 2
DESCRIPTION QTY.
2
1
4
1
1
1
1
1
1
1
1
1
1
1
1
1
