RHINO GXa Instruction Manual

INSTRUCTION MANUAL FOR THE NEW:
Remote Control Compact Car Alarm
Proudly Designed
with 2 Stage Impact Sensor, plus
in Australia
Central Locking &
Immobilisation Outputs.
N517

TO ARM/DISARM ALARM

The alarm is activated by pressing the button on the remote control transmitter once. The
blinkers will flash once, and the siren will beep once. The dash LED-light will stay on for 20
seconds then flash, THE ALARM IS NOW ON.
To deactivate the alarm, press the button again. The blinkers will flash twice and the siren will
beep twice. THE ALARM IS NOW OFF.
If the siren is sounding, and you wish to disarm, one press of the button will cancel the siren and
disarm the alarm. The blinkers will flash twice and the siren will beep twice. THE ALARM IS NOW OFF.
Note: If power is removed from the alarm system, i.e. when replacing your car battery, the alarm will automatically
return to the mode it was in prior to disconnecting power.

ALARM TRIGGER

When triggered, the siren will sound for 30 seconds and then will automatically rearm. If the alarm has been triggered
in your absence, the siren will beep 4 times upon disarm rather than give the normal 2 beeps to indicate alarm
activation has occurred.

EMERGENCY PANIC BUTTON

The panic feature is activated by pressing & holding the button on the remote control transmitter for 3 seconds. The
system will arm or disarm first depending on what state it was in. The siren will then sound & the blinkers will flash for
30 seconds. To cancel "panic", follow disarm procedure as desribed above.
NOTE: Panic does not work when the ignition is on by requirement of Australian Law (EPA-Environmental Protection Authority).
PRE-ALERT IMPACT WARNING WITH ETS™
This special feature provides a two stage impact sensing system. It gives the security conscious owner a sensitive car
body impact sensor that will give a potential thief prior warning that the vehicle is protected by this most formidable
alarm system. On detection of a low level impact i.e. from a tyre kick, the siren will simply beep for a few seconds to
warn away the would-be thief. If the vehicle is attacked any further, the system will move into full siren mode. The
unique ETS™ Environment Tuned Sensor is able to distinguish between environmental shocks caused by aircraft,
trucks, or extreme weather conditions, and the impact caused by any thief attempting to break in or other heavy
impacts. Furthermore the system features the unique Rhino "Auto Adjust" process, where during the 20 sec. arming
delay, the alarm samples the background noise where the vehicle is parked, and will if necessary automatically reduce
the sensitivity of the impact sensor to an appropriate level. This process allows a trouble free sensitivity that ordinary
alarms simply can not provide. The sensitivity level reference point can be adjusted to suit your particular needs.
Please refer to the programming section contained later in this manual.
1
