INSTRUCTION MANUAL FOR
V2.0
Code Hopping Remote Control Car Alarm, with
Engine Immobilsation, Backup Battery, Two Stage
Designed & Engineered in
Impact Sensor & Fully Programmable Features.
Australia
Build Date:
N517
KEYSWITCH POSITIONS
HIGH SECURITY SWITCH
SYSTEM OFF SYSTEM ON
Located in the rear of the siren is a master switch. This can be
used to turn the system on/off. Bear in mind that if you unplug
the alarm while it is armed, the built in backup battery will
TURN CLOCKWISE
continue to power the system.
TO ARM/DISARM ALARM
The alarm is activated by pressing the LEFT button (Marked with a 1) on the
remote control transmitter. The blinkers will flash once, and the siren will beep once.
The dash LED-light will stay on for 20 seconds then flash, THE ALARM IS NOW ON.
1 2
To deactivate the alarm, press the LEFT button again. The blinkers will flash twice
and the siren will beep twice. THE ALARM IS NOW OFF.
For audible arm / disarm
use the LEFT button.
For silent arm / disarm
press BOTH buttons (1 & 2) together.
BOOT RELEASE FUNCTION
(Available only on cars fitted with an electric boot release motor).
The alarm is fitted with remote boot release opening capability. This feature enables the user to unlock the
boot by pressing the RIGHT button (Marked with a 2) for 3 seconds. The boot will unlock and the alarm will
disarm with audible beeps. NOTE: For safety reasons the remote boot release will not work when the ignition
is turned on.
EMERGENCY PANIC BUTTON
The panic feature is activated by pressing the LEFT button on the remote control transmitter for 3 seconds
This sets off the siren. To cancel "panic", press the LEFT button on the transmitter for 1 second NOTE:
Panic does not work when the ignition is on by requirement of Australian Law (EPA-Environmental
Protection Authority).
BACKUP BATTERY TEST
The alarm is fitted with an intelligent battery backup test feature. When you turn the ignition to on, the alarm
does a diagnostic check on the backup battery. If the charge is below an acceptable level, then the dash LED
will flash for the first 5 seconds when the ignition is turned on.
PAT™ PAST ALARM TRIGGER MEMORY
If the alarm was triggered by an intruder while your alarm was set, it will beep the siren and flash the
blinkers four times on disarm. The system will also store the ten last times the alarm has been activated in
its memory, and can tell you what has triggered the system. Please refer to "Features used by Users and
Installers" contained later in these instructions.
1
