INSTRUCTION MANUAL FOR
Code Hopping Remote Control Car Alarm with Two
Stage Impact Sensor, Battery Backup Siren &
2 Point Engine Immobilisation

TO ARM/DISARM ALARM

The alarm is activated by pressing BUTTON 1 on the remote control transmitter once. The blinkers will flash
once, and the siren will beep once. The dash LED-light will stay on for 15 seconds then flash, THE ALARM IS
NOW ON.
To deactivate the alarm, press the BUTTON 1 again. The blinkers will flash twice and the
siren will beep twice. THE ALARM IS NOW OFF.
If the siren is sounding, and you wish to disarm, the first press will cancel the siren - the
system will then return to an armed state. A second press is required to fully turn the alarm
off (you will hear 2 beeps & the blinkers will flash twice) .
For audible arm / disarm
For silent arm / disarm
ARMING ERROR REPORT & BYPASS
The alarm can identify 6 different trigger inputs as shown in the table below. When arming, if the alarm
senses a trigger from any one of these inputs it will beep out the corresponding code to the that trigger
input 4 seconds after the normal arming beep. That trigger input will be automatically bypassed to prevent
false alarms.
ALARM TRIGGER & MEMORY
When the alarm is triggered the siren will sound for 30 seconds and then will automatically rearm.
If the alarm has been triggered in your absence, the dash LED will be flashing twice as fast as normal when
you return to your vehicle. To find out what has triggered the alarm, disarm the system & then turn the
ignition to on. The red dash LED will flash out a code to identify what inputs have triggered the alarm during
tha last armed period. The most recent trigger will be reported last i.e. if the alarm was triggered by the
impact sensor, & then triggered again by ignition activation, the LED will flash 3 times, pause, and then flash
4 times. Refer to table below.
Trigger
Door Circuit
Bonnet/Boot
Impact Sensor
Ignition Activation
Voltage Drop (Current) Sensing
Optional Sensor Input
BOOT RELEASE - Available on cars fitted with electric boot release motors.
The alarm is fitted with remote boot release capability. This feature enables the user to unlock the boot by
pressing BUTTON 1 for 3 seconds. The boot will unlock and the indicators will flash 10 times.
If the system is armed at the time, it will automatically bypass relevant trigger sectors i.e. impact sensor,
boot trigger, & voltage drop. Once you close the boot, the system will rearm all inputs immediately. Note: If
you do not open the boot during the period when the blinkers are flashing 10 times, the siren will trigger
when you open the boot. For safety reasons, the remote boot release will not work when the ignition is on.
A.C.N 001 621 610
use BUTTON 1.
use BUTTON 2.
4 seconds after arming
Indication Chirp(s)
for Bypass, given
1
2
3
4
5
6
SYDNEY / AUSTRALIA
Build Date:
Alarm Memory Report Via LED
(Flashes) given after disarm when
ignition is turned on
1
2
3
4
5
6
