2

Installing the MP-11x

The equipment must only be installed or serviced by qualified service personnel.
To install the MP-11x, take these 3 steps:
Unpack the MP-11x (refer to Section
1.
Check the package contents (refer to Section
2.
Mount the MP-11x (refer to Section
3.
Cable the MP-11x (refer to Section
4.
After connecting the MP-11x to the power source, the Ready and Power LEDs on the front panel
turn to green (after a self-testing period of about 2 minutes). Any malfunction in the startup
procedure changes the Fail LED to red and the Ready LED is turned off (refer to Section
page 26 for details on the MP-11x LEDs).
When you have completed the above relevant sections you are then ready to start configuring the
gateway (Section
2.1

Unpacking

To unpack the MP-11x, take these 6 steps:
Open the carton and remove the packing materials.
1.
Remove the MP-11x gateway from the carton.
2.
Check that there is no equipment damage.
3.
Check, retain and process any documents.
4.
Notify AudioCodes or your local supplier of any damage or discrepancies.
5.
Retain any diskettes or CDs.
6.
2.2

Package Contents

Ensure that in addition to the MP-11x, the package contains:
•
AC power cable.
•
Small plastic bag containing four anti-slide bumpers for desktop installation.
•
A CD with software and documentation may be included.
•
This Fast Track Installation Guide.
MP-11x
Caution Electrical Shock
2.4
2.5
3 on page 13).
2.1 below).
2.2 below).
on page 9).
on page 10).
