- Page 1 ARISTEL NETWORKS PTY LTD. MANUAL GSM DOOR PHONE SS91A-M GSM DOOR PHONE (ACCESS CONTROL SYSTEM) For your protection, read these instructions completely And keep them for future reference. SS91A-M GSM Door Phone Revision 2.20, April 2011...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTION ..............3 SS91A-M GSM DOOR PHONE INTRODUCTION ............. 4 SS91A-M GSM DOOR PHONE WITH ACCESSORIES ..........4 INSTALLATION ....................... 5 SS91A-M GSM Door Phone Unit ................5 Wiring Diagram ......................5 LED Indication ......................6 Wiring Instruction ...................... -
Page 3: Important Safety Instruction
Thank you for purchasing SS91A-M GSM Door Phone. Please read this manual carefully before using. Be sure to keep this manual for future reference in case of any problem or question should arise. IMPORTANT SAFTY INSTRUCTIONS When using this SS91A-M GSM Door Phone, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury. -
Page 4: Ss91A-M Gsm Door Phone Introduction
SS91A-M GSM DOOR PHONE INTRODUCTION The GSM Door Phone SS91 is an intercom system, installed at the entrance of a building. It is an ideal product replacing the traditional door phone. It allows you to speak with visitors standing at the entrance of your company or house entrance from a remote location. -
Page 5: Installation
INSTALLATION 1. SS91A-M GSM Door Phone Unit Speaker Call Button Microphone Wiring Diagram (PCB) SS91A-M GSM Door Phone Revision 2.20, April 2011... -
Page 6: Led Indication
Antenna can be fixed vertically upwards on the opposite side of the wall. The antenna could be folded in the shape of “L” during installation. SS91A-M GSM DOOR PHONE OPERATION Visitor: When the visitor pushes the call button to activate the door phone ring tone will be heard from the door phone. - Page 7 Dialing into the intercom from another telephone There are three possible outcomes to dial into the GSM intercom after entering manager mode. Listener monitoring mode Access control mode Programming mode SS91A-M GSM Door Phone Revision 2.20, April 2011...
-
Page 8: User (Manager Mode)
If the number is programmed to open the door but you still would like to use the same number to dial in for programming but not for door open, then you can disable Caller ID display on the SS91A-M GSM Door Phone Revision 2.20, April 2011... - Page 9 SS91A-M GSM Door Phone Revision 2.20, April 2011...
-
Page 10: Programming By Text Message
Signal strength lower than level 3 may cause operational problems such as loss of speech quality (and possibly missing DTMF tones) and network loss. Send *20# Reply Signal Level = 4 ( Signal is very strong ) SS91A-M GSM Door Phone Revision 2.20, April 2011... -
Page 11: Function Code Table
Can only be carried out by *20# strength text message Relay Output key 61 + X# X=0~9 / * /# Auxiliary Output key X=0~9 / * /# 62 + X# Reset 999# reset default None SS91A-M GSM Door Phone Revision 2.20, April 2011... -
Page 12: Specifications
Dimensions: Casing 174 x 113 x 65 mm Face plate: 170 x 100mm Frequency band: GSM 900/1800 MHz dual band / GSM 850/900/1800/1900 MHz quad band Power input: 12V DC, 1A Length of antenna cable 3 meters SS91A-M GSM Door Phone Revision 2.20, April 2011... - Page 13 Aristel NetWorks Pty Ltd. SS91A-M GSM Door Phone Revision 2.20, April 2011...
