Diagnostics – Parking Light Flash Table
Parking lights flashes
x
Doors locked.
x
Trunk released.
1
x
Start signal received from the remote.
x
Runtime has expired
x
2 slow Shutdown by remote
x
Doors unlocked
2 fast
x
Valet mode is deactivated
x
3 slow Runtime is extended.
x
3 fast
Valet mode activated.
x
Shutdown by brake
4 fast
x
A remote start was attempted while the brake pedal is engaged.
x
Shutdown by hood
10 fast
x
A remote start was attempted while the hood is open.
ON Î twice x
Cold weather mode deactivated
ON Î 3 times
x
Cold weather mode activated.
x
Solid ON
Engine is running under remote start.
x
Flash for 30 sec. Panic mode is triggered.
x
Flash for 60 sec. Alarm is triggered.
ON Î twice Î twice
x
A remote start was attempted while the system is in home valet.
