Directed Electronics PS-3655E-FM User Manual

One-way fm automatic / manual transmission remote starter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
O N E - W A Y F M A U T O M A T I C / M A N U A L
T R A N S M I S S I O N R E M O T E S T A R T E R
PS-3655E-FM
User Guide
It is the responsibility of the vehicle operator to ensure their vehicle
is parked in a safe and responsible manner.
1. a) Manual transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in the NEUTRAL
position and the parking brake is engaged in order to avoid accidents
upon remote starting.
b) Automatic transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in "Park" in order to
avoid accidents upon remote starting.
(Note: Make sure that the automatic vehicle cannot start in "Drive".)
2. It is the user's responsibility to ensure that the remote starter is
disabled or put into valet mode before servicing.
Designed & engineered in Canada
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired operation of
the device.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen
that the equivalent isotropically radiated power (EIRP) is not more than that required for successful
communication.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate the
equipment
Doc#: 100826
Rev:1.0
© 2010
WARNING
- PS-3655E-FM -
- FcN -
Canada

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS-3655E-FM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Directed Electronics PS-3655E-FM

Summary of Contents for Directed Electronics PS-3655E-FM

  • Page 1 NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user's authority to operate the equipment Doc#: 100826 Rev:1.0 © 2010 - PS-3655E-FM - - FcN - Canada...
  • Page 2 What is EncryptR™ Technology? EncryptR™ employs proprietary encryption software that sends unique codes from the remote starter to the ADS-TB or ADS-AL-CA bypass module that cannot be replicated or reversed with hi-tech equipment. The EncryptR™ communication exchanged between the remote starter and the ADS bypass module is best described as a “secret handshake”...

  • Page 3: Table Of Contents

    Table of Contents Introduction ..........................4 Using the Remote Control ....................... 4 Vehicle Presets ..........................5 Heater ............................5 Windshield Wipers & Radio & Headlights ..................5 Arming the Starter Kill ........................5 Remote-Starting Your Vehicle ......................6 Setting Your Vehicle Into Ready Mode ..................6 Remote-starting ..........................

  • Page 4: Introduction

    Introduction This is a state-of-the-art remote car starter system. The system is packed with advanced features such as priority access to the driver’s door (commodity features), the Safe Start children safety feature and SmartStart™. SmartStart™ is a groundbreaking technology that enables your remote starter features to be accessed by your smartphone.

  • Page 5: Vehicle Presets

    Vehicle Presets Heater When leaving the vehicle it is recommended to preset the accessory controls in preparation for the next remote start. Settings for the blower motor (fan), front and rear, should not be left on HIGH. It is recommended to leave the settings on LOW or MEDIUM instead. Windshield Wipers &...

  • Page 6: Remote-Starting Your Vehicle

    To disarm the Starter Kill, press the button on the transmitter. The parking lights will flash twice. The LED on the antenna will remain OFF. If remote door locks are installed, this will also unlock the doors. Remote Starting Your Vehicle Setting Your Vehicle Into Ready Mode If your vehicle has a manual transmission you must read the following indications.

  • Page 7: Driving Off

    If your vehicle has an automatic transmission and it does not start at the first attempt, the system will shut down, wait a few seconds and try to start the engine again. There will be 3 start attempts before the system gives up. Driving Off With the vehicle running remotely, press the button to disarm and unlock the doors.

  • Page 8: Valet Mode

    Note1: The engine will continue running until the user re-enters the vehicle or until the expiration of the engine run time. Note2: If the pre-programmed run-time expires or if the user shuts down the engine by remote control, the vehicle will enter Ready Mode. Caution!!! Do not leave children or pets unattended in a vehicle standing in Idle Mode.

  • Page 9: Panic Mode

    Panic Mode Note: Panic mode can only be activated if the horn has been adequately configured by the installer. In an emergency situation, you can activate panic mode by pressing and holding the AUX button for more than 3 seconds, until the horn starts honking. If the vehicle is under a remote start, the engine will shutdown automatically before setting off the horn.

  • Page 10: Disable/Enable Led Flashing

    The parking lights will flash slowly 3 times then remain lit. To stop the vehicle at any moment, simply press the button. This procedure can only be carried out once per remote start. Example: If your Module is programmed for a runtime of 3 minutes and your vehicle has been running for 2 minutes already, pressing the button will reset the counter to zero and the Engine will run for another cycle (in this case, 3 minutes).

  • Page 11: Safe Start

    Safe Start This feature will eliminate accidental remote starts, e.g. when children are playing with the transmitter. Safe start enabled: If this feature is enabled, the user must press the button twice within 3 seconds to remote-start the vehicle. Swap start: If this feature is enabled; Rapidly press AUX twice.

  • Page 12: Aux 1

    Press the button. Within 3 seconds, press the buttons simultaneously for 3 sec. The P-lights will flash once To take the system out of home valet mode: Turn the ignition key to the IGNITION ON (RUN) position. The system will warn you if someone attempts to start your vehicle while it stands in home valet mode.

  • Page 13: Oem-Style Alarm

    OEM Style Alarm The OEM-style alarm (if configured by your installer) monitors the doors, hood and ignition switch of your vehicle. It will sound the horn if a door or the hood is opened, or if the key is turned in the ignition.

  • Page 14: Diagnostics - Parking Light Flash Table

    Diagnostics – Parking Light Flash Table Parking lights flashes Description Doors locked. Trunk released. Start signal received from the remote. Runtime has expired Doors unlocked 2 fast Valet mode is deactivated 2 slow Shutdown by remote Shutdown by brake 4 fast A remote start was attempted while the brake pedal is engaged.
