Samsung SMARTCAM SNH-E6440BN User Manual page 31

Item
Audio Detection Support
Audio I/O Support (external microphone and speaker)
Audio Compression Format G.711
Audio Communication Bidirectional (external microphone and speaker), Half Duplex
External microphone 3.5mm Passive microphone(mono)
External microphone sensitivity - 35dB ~ - 40dB
External microphone cable length 8m
Shielded microphone cable (The microphone noise depends on
External microphone cable type
the cable length and shield characteristic.)
Memory Slot microSD (FAT32), Up to 32GB
Event recording, Manual recording, Continuous recording, Remote
Recording & Playback
playback
Ethernet RJ-45 (10/100BASE-T)
Wireless Wi-Fi 802.11 b/g/n (2.4G Single-band)
WiFi Direct Support (Push button)
Security SSL (AES 256bit)
Max. User Access 5 users at Unicast Mode
Operating Temperature / Humidity Camera : -10°C ~ 50°C, Body : 0°C ~ 40°C / Less than 90% RH
Ingress Protection IP66 (Camera part), Indoor (Body)
Description
Input Voltage / Current
Power Consumption
Indication
Color
Dimension (WxHxD)
Weight
Item
9V DC / 1A
Max. 9W
1 LED (Power, Status, Link)
White
Camera (incl. bracket): Φ54 x H102mm,
Body (excl. cradle): W83.2 × H111 × D27.3mm
568g
Description
