BEFORE INSTALLATION

1. System Configuration Verification:

Confirm that the voltage(s) and service configuration shown on TransTrack product label are consistent with the voltage and
service configuration of the facility. A model number is on the bottom side of TransTrack. Each model number
corresponds to the configurations printed in the table below:
Example of a suppressor model number: TK-TT200-3Y208-F
MODEL NUMBER
TK-TTxxx-1P240
TK-TTxxx-1S240
TK-TTxxx-3Y208
TK-TTxxx-3Y380
TK-TTxxx-3Y415
TK-TTxxx-3Y480
TK-TTxxx-3D240
TK-TTxxx-240NN
TK-TTxxx-380NN
TK-TTxxx-480NN
-F suffix denotes enhanced transient filter (ETF) option.
The ETF option is not recommended for applications employing a Ground Fault Current Interrupting (GFCI) breaker.
WARNING: Check to ensure that a proper bond is installed between neutral and ground at the transformer
upstream from all 3-phase WYE, 3-phase high-leg DELTA, split-phase or single-phase TransTrack device (see
!
NEC article 250). If the transformer is not accessible, check the main service disconnect/panel for the N-G
bond. Lack of a proper bond will damage TransTrack and void the warranty.
4
NOMINAL L-N
VOLTAGE VOLTAGE RANGE
240 204-264
120/240 102-132
120/208 102-132
220/380 187-264
240/415 204-264
277/480 236-305
102-132
(A & C PHASES)
120/240
177-229
(B PHASE)
240 N/A
380 N/A
480 N/A
L-L
VOLTAGE RANGE
N/A
204-264
177-229
323-460
353-457
408-528
Three-Phase high-leg DELTA
204-264
Three-Phase DELTA
204-264
Three-Phase DELTA
323-460
Three-Phase DELTA
408-528
™
TRANSTRACK INSTALLATION, OPERATION AND MAINTENANCE MANUAL
CONFIGURATION
Single-Phase,
2-wire+ground
Split-Phase,
3-wire+ground
Three-Phase WYE
4-wire+ground
Three-Phase WYE
4-wire+ground
Three-Phase WYE
4-wire+ground
Three-Phase WYE
4-wire+ground
4-wire+ground
3-wire+ground
3-wire+ground
3-wire+ground
