Installing the Memory Module DDR3 SO-DIMM

Cybernet iOne-G4
1. The memory module has only one notch
and will only fit in the slot one way.
2. Insert the memory module into the DIMM
slot at a 45° angle. Then push it in until the
golden finger on the memory module is
deeply inserted into the DIMM slot.
3. Press the memory module down and the
metal clip at each side of the DIMM slot will
automatically close.
4. Repeat the steps to install another memory
module to meet your needs.
