Page 2: Declaration Of Conformity
IPC-R2is / IPC-E2is User Manual Declaration of Conformity This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Weee Statement
WEEE Statement (Waste Electrical and Electronic Equipment) The WEEE directive places an obligation on EU-based manufacturers, distributors, retailers and importers to take-back electronics products at the end of their useful life. A sister Directive, ROHS (Restriction of Hazardous Substances) compliments the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. -
Page 4: Safety Instructions
Safety Instructions Always read the safety instructions carefully. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. Confirm the voltage of the power source and adjust accordingly to 110/220V before connecting the equipment to the power inlet. Place the power cord in such a way that it cannot be stepped on. -
Page 5: Table Of Contents
Trademarks ........................1 WEEE Statement ......................2 Safety Instructions ......................3 Introduction ........................5 IPC R2is & IPC E2is Specifications ................6 IPC-R2is & IPC-E2is Overview ..................8 IPC-R2is Dimension ....................8 IPC-E2is Dimension ..................... 8 IPC-R2is Front I/O View ....................9 IPC-E2is Front I/O View .................... -
Page 6: Introduction
If you have any questions about your new IPC-R2is / IPC-E2is, please do not hesitate to contact us using any of the support numbers provided at the end of this User Manual. -
Page 7: Ipc R2Is & Ipc E2Is Specifications
IPC R2is & IPC E2is Specifications Supports Intel Whiskey Lake 8 Generation Processor, FCBGA1528 2 x DDR4 SO-DIMM sockets, up to 32GB combined Memory Supports memory data transfer rates of 2133MHz/2400 MHz for DDR4, un-buffered non-ECC DDR4 SO-DIMMs Serial ATA controller facilitates high-speed transfers up to 6Gbps Storage Maximum 2 x 2.5”... - Page 8 FCC part 15B class B EN55032 / EN55024 class B Certifications ICES-003 DOC ID: 16001100 Page | 7...
-
Page 9: Ipc-R2Is & Ipc-E2Is Overview
IPC-R2is & IPC-E2is Overview IPC-R2is Dimension IPC-E2is Dimension DOC ID: 16001100 Page | 8... -
Page 10: Ipc-R2Is Front I/O View
IPC-R2is Front I/O View IPC-E2is Front I/O View IPC-R2is / IPC-E2is Back I/O View DOC ID: 16001100 Page | 9... - Page 11 Power button The Power Button is a momentary switch with LED indicator. LED Color Power Status System Status Solid Blue Working state Blinking Suspend to RAM Press the power button to turn on the system. To force a shutdown, press and hold the power button for 4-seconds.
- Page 12 Speed (FS), and Low Speed (LS). USB2.0 There are 2x USB2.0 connections available, which supports up to 480Mbps data rate. These USB ports are also compliant with High Speed (HS), Full Speed (FS), and Low Speed (LS). Ethernet Port LAN1: Intel I219LM 10/100/Gigabit LAN, supports Wake on LAN, PXE boot and vPro technology.
- Page 13 Serial Ports Serial port 1 can be configured for RS-232, RS-422, or RS-485 with auto flow control communication. The default definition of COM1 is RS-232, which can be configured in the BIOS. The pin assignments are listed below: Serial Pin No. RS-232 RS-422 RS-422...
- Page 14 Serial ports 2-4 are all RS-232 and the pin assignments are listed below: Serial Port Pin No. RS-232 COM2~4 SSD/HDD Trays There are 2x front-accessible 2.5” SSD/HDD locking trays. DOC ID: 16001100 Page | 13...
- Page 15 Power Terminal Block The system supports 9V to 36V DC power input by terminal block. Pin No. Definition Chassis Ground Power On/Off Switch This terminal block supports a 2-pin power on/off switch. Pin No. Definition Power Power LED Chassis Ground DOC ID: 16001100 Page | 14...
- Page 16 PoE (Power over Ethernet) Ports (Optional) There are 2x optional Ethernet ports on the IPC-R2is / IPC-E2is that supports IEEE 802.3at (PoE+) Power over Ethernet connection, delivering up to 25.5W / 52V per port and 1000BASE-T GbE data signals over standard Ethernet Cat 5/6 cable. Each PoE connection is powered by Intel®...
-
Page 17: Power Management
Power Management Taking advantage of the power management options available on Windows OS can save you significant amounts of electricity and also provide environmental benefits. For better energy efficiency, turn off your display or set your PC to sleep mode after prolonged periods of user inactivity. - Page 18 Power Management through ENERGY STAR qualified monitors (Not supplied with the IPC-R2is / IPC-E2is) The power management feature allows the IPC-R2is / IPC-E2is to initiate a low-power or “Sleep” mode after a period of user inactivity. When used with an external ENERGY STAR qualified mnitor, this functionality also supports similar power management features for the display.
-
Page 19: Waking The System Up
Waking the System Up The IPC-R2is / IPC-E2is can wake up from power saving mode in response to a command from any of the following: • the power button, • the network (Wake on LAN) • the mouse • the keyboard... -
Page 20: Ipc-R2Is / Ipc-E2Is Bios Introduction
IPC-R2is / IPC-E2is BIOS introduction The AMI BIOS provides a Setup utility program for specifying system configurations and settings. The BIOS ROM of the system stores the Setup utility. When you turn on the computer, the AMI BIOS is immediately activated. Pressing the <F2> or <DEL> key allows you to enter the Setup utility. -
Page 21: Appendices
Appendices DOC ID: 16001100 Page | 20... -
Page 22: A - Cybernet's Recycling Program
A - Cybernet’s Recycling Program B - Getting Help Corporate Headquarters UK & European Inquiries Cybernet Manufacturing Cybernet Europe 5 Holland #6, Groveland Business Centre Irvine, California 92618 Boundary Way Free: (888) 834-4577 Hemel Hempstead, HP2 7TE Phone: (949) 600-8000...
