SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL
SEL SERIES ELECTRIC
TAILGATE SPREADER
00122-51 7 -01 SEPTEMBER 2009
WWW.MEYERPRODUCTS.COM

Advertisement

loading
Need help?

Need help?

Do you have a question about the SEL SERIES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Meyer SEL SERIES

Summary of Contents for Meyer SEL SERIES

  • Page 1 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL SEL SERIES ELECTRIC TAILGATE SPREADER 00122-51 7 -01 SEPTEMBER 2009 WWW.MEYERPRODUCTS.COM...

  • Page 2: Table Of Contents

    SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL INCLUDED IN THIS MANUAL: Safety Instructions ------------------------------------- --------------- - ---------- --- ---------- ----------- - 3-5 Control Electric Specifications & Installation -------------------- ------- --------------------------- 6 H arness and Wiring Diagram ------------------------------- --------------------- --------------------- 7- 9 Trough mounting instructions ----------------------------------- ------------------------ -------------- 10-11 Spinner Assembly and Installation ------------------------------ ----- ------------------------- 12-14 Spinner Spread Pattern Instructions ------------------------------ ---- ----------------------------- 15-16...

  • Page 3: Safety Precautions

    SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL SAFETY PRECAUTIONS The best safety device is a careful operator! This symbol means ATTENTION! Become Alert! Your safety is involved! Please read and understand completely before doing! BEFORE PERFORMING MAINTENANCE OPERATIONS, PARK VEHICLE ON LEVEL GROUND. SET PARKING BRAKE, SHUT OFF ALL POWER, AND MAKE SURE ALL MOVEMENT HAS STOPPED.
  • Page 4 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL NOTICE! Your spreader is equipped with a safety interlock device. This device must be disconnected before the spreader trough bottom door and the spreader trough top cover can be opened exposing the auger. This device positively disconnects all electric power from the auger drive motor to prevent accidental bodily injury due to contact with a turning auger.
  • Page 5 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL SAFETY DECAL LOCATIONS SERIOUS PERSONAL INJURY OR DEATH CAN RESULT IF THE SAFETY INTERLOCK DEVICE - AS INSTALLED ON THIS SPREADER: IS ALTERED IN ANY WAY FROM ITS ORIGINAL INTENT AS SHOWN IS NOT MAINTAINED SO AS TO OPERATE ACCORDING TO ITS ORIGINAL INTENT AS SHOWN ELECTRICAL COUPLING CONNECTED ELECTRICAL COUPLING NOT CONNECTED...
  • Page 6 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 6...
  • Page 7 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL ELECTRIC CONTROL INSTALLATION (Continued) 63963 WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 7...
  • Page 8 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 8...
  • Page 9 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL PARTS LIST CONT’D 64019 (CS TROUGH ASSY) 64020 (SS TROUGH ASSY) 64021 (CS CD TROUGH ASSY) 64022 (SS CD TROUGH ASSY) ITEM PRODUCT DESCRIPTION 64015 MOTOR, 12 V 1650RPM 60A 1/2 HP 64023 CLAMP, CUSHIONED 3/4” WIDE 1/2” 63245 CLAMP, CUSHIONED 3/8”...
  • Page 10 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL NOTES WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 10...

  • Page 11: Trough Mounting Instructions

    SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL TROUGH MOUNTING INSTRUCTIONS Hairpin Keeper (Large) Hinge Pin Brace pin Hairpin Keeper (Large) Hanger Iron Brace Brace pin Spreader Detach Bracket Truck Dump Body 1/2” X 1 1/4” Bolts Quick Detach Plate WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 11...
  • Page 12 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL TROUGH MOUNTING INSTRUCTIONS (Continued) GENERAL: This spreader is designed to mount rigidly on the rear of the truck dump body, below the tail- gate, and supported by brackets bolted to the rub rails of the dump body. Instructional drawing is included in this manual to show the details on page 1 1 .
  • Page 13 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL INSTALLATION OF SPINNER ASSEMBLY ON “SEL” SERIES SPREADERS SUPPORT SPINNER ASSEMBLY SOLIDLY WHEN DANGER MOUNTING ON SPREADER. SPINNER ASSEMBLY PROCEDURE: 1 . Attach spinner disc to hub with 5/16” x 1 1/2” bolts, flatwashers and flange nuts. 2 .
  • Page 14 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 14...
  • Page 15 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 15...
  • Page 16 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL SpreadÊpatternÊadjustment,Êcont'd WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 16...

  • Page 17: Operating Instructions

    SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL OPERATING INSTRUCTIONS DANGER WHEN STARTING UP NEW EQUIPMENT, BE SURE EVERYONE IS STANDING CLEAR, WATCH FOR ANYTHING THAT MAY REQUIRE SHUTTING SYSTEM DOWN. EQUIPMENT MUST BE STARTED UP SLOWLY AND WATCHED FROM A SAFE DISTANCE. WATCH FOR ANYTHING THAT MAY BE HITTING SOMETHING THAT IT SHOULD NOT BE HITTING, AND LISTEN FOR SOUNDS THAT ARE ABNORMAL.
  • Page 18 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL OPERATING INSTRUCTIONS (Continued) PREPARING SPREADER FOR USE: Position spreader cover plate vertically and secure with latches. With dump body empty, unlatch dump body tailgate from bottom and open as wide as possible but not bearing against cover plate, set the stop (or spread) chains. Loosen spinner lock and slide spinner assembly to far left and retighten lock.

  • Page 19: Recommended Regular Maintenance

    SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL RECOMMENDED REGULAR MAINTENANCE DANGER SERIOUS PERSONAL INJURY CAN RESULT FROM BEING CAUGHT IN A TURNING AUGER, A TURNING SPINNER, OR OTHER OPERATING TRUCK EQUIPMENT. BEFORE PERFORMING MAINTENANCE OPERATIONS, PARK VEHICLE ON LEVEL GROUND. SET PARKING BRAKE, SHUT OFF ALL POWER, AND SHUT OFF TRUCK ENGINE.
  • Page 20 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 20...
  • Page 21 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 21...

  • Page 22: Parts List

    SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL PARTS LIST 64019 (CS TROUGH ASSY) 64020 (SS TROUGH ASSY) 64021 (CS CD TROUGH ASSY) 64022 (SS CD TROUGH ASSY) ITEM PART NUMBER DESCRIPTION 1 CS 64025 WELD, TROUGH, 10G CS CS C/D 64026 WELD, TROUGH, 10 GA CS CENTER DROP 64027 WELD, TROUGH 10 G S2...
  • Page 23 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 23...
  • Page 24 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL PARTS LIST CONT’D 64019 (CS TROUGH ASSY) 64020 (SS TROUGH ASSY) 64021 (CS CD TROUGH ASSY) 64022 (SS CD TROUGH ASSY) ITEM PART NUMBER QTY. DESCRIPTIONS 7 CS 20049 BOLT, 3/8-16 X 1 HH G5 ZP 62697 BOLT, 3/8-16 X 1 HH SS 12 CS...
  • Page 25 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 25...
  • Page 26 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL PARTS LIST CONT’D 64019 (CS TROUGH ASSY) 64020 (SS TROUGH ASSY) 64021 (CS CD TROUGH ASSY) 64022 (SS CD TROUGH ASSY) ITEM PART NUMBER DESCRIPTION 61163 BEARING, 1 1/4” 11 CS 20066 BOLT, 3/8-16 Z 1 1/4” HH G5 ZP 62695 BOLT, 3/8-16 X 1 1/4”...
  • Page 27 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL DRIVE END VIEW 64019 (CS TROUGH ASSY) 64020 (SS TROUGH ASSY) 64021 (CS CD TROUGH ASSY) 64022 (SS CD TROUGH ASSY) 127 Walnut Street Lindenwood, IL 61049 (888) 825-7323 May be covered by one or more of these patents: 3189355 3332691 3510066...
  • Page 28 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL PARTS LIST CONT’D 64019 (CS TROUGH ASSY) 64020 (SS TROUGH ASSY) 64021 (CS CD TROUGH ASSY) 64022 (SS CD TROUGH ASSY) ITEM PRODUCT DESCRIPTION 64029 REDUCER, GEAR 29.4:1 64030 BOLT, M10-1.5 X 20 SCH SS 63993 SCREW, M8-1.25 X 20 SCH SS 64015...
  • Page 29 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL Assembled Spinner Image 9 12 13 14 WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 29...
  • Page 30 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL Assembled Spinner Image Parts Listing ITEM PRODUCT DESCRIPTION 63271 ROD, HINGE, S3 22083 PIN, LYNCH 63447 ROD, CARRIAGE SUPPORT S3 62769 COLLAR, SET 1” 62459 LOCK, SPINNER, S3 6 CS 64009 WELD, SPINNER FRAME 10G CS 64010 WELD, SPINNER FRAME 10G SS 7 CS...
  • Page 31 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL CARRIAGE MOUNTING EXPLODED VIEW WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 31...
  • Page 32 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL FRONT MOUNTED SPINNER CARRIAGE ASSEMBLY PARTS LIST ITEM PRODUCT DESCRIPTION 63271 ROD, HINGE, S3 22083 PIN, LYNCH 63447 ROD, CARRIAGE SUPPORT S3 62769 COLLAR, SET 1” 5 CS 64009 WELD, SPINNER FRAME 10G CS 64010 WELD, SPINNER FRAME 10G SS 6 CS...

  • Page 33: Name Plate Information

    XXXXXX Description: P, SJDS - MEYER SPREDER Part Number: XXXXX Serial Number: XXXXX CALL YOUR AUTHORIZED MEYER PRODUCTS DEALER FOR PARTS AND SERVICE MEYER PRODUCTS (216) 486-1313 FAX (216) 486-9775 email: warranty@meyerproducts.com NOTICE: INSTRUCTIONAL MATERIAL AND PARTS LISTS INCLUDED IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE.

  • Page 34: Warranty

    SPREADER ONE YEAR WARRANTY Meyer Products (“Meyer”) warrants to the original purchaser only that it will repair, or, at the sole option of Meyer, replace any part of the new Meyer covered product which proves to be defective in workmanship or material under normal use for a period of one year from the date of delivery to the original purchaser.
  • Page 35 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL NOTES WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 35...
  • Page 36 SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL MEYER PRODUCTS, LLC 18513 EUCLID AVE. CLEVELAND, OHIO 44112-1084 PHONE: (216) 486-1313 FAX: (216) 486-9775 email:warranty@meyerproducts.com website: www.meyerproducts.com IMPORTANT INFORMATION ENCLOSED WWW.MEYERPRODUCTS.COM 00122-517-01 SEPTEMBER 2009 PAGE 36...
