Meyer V-FORCE 7400 Series Operator And Parts Manual

Twin expeller super spreader
Hide thumbs
Table of Contents

Advertisement

Quick Links

OPERATOR'S AND PARTS MANUAL NO. PB-74/7500
TWIN EXPELLER SUPER SPREADER
DO NOT OPERATE EQUIPMENT UNTIL THIS MANUAL HAS BEEN READ AND UNDERSTOOD.
6990633 (1-13)
4 / 2019
MEYER
V-FORCE
MODEL:
US PATENT NO.
5,368,236
5,501,404
MANUFACTURED BY
Meyer Mfg. Corp.
674 W. Business Cty Rd A
P.O. Box 405
Dorchester, Wisconsin 54425-0405
Phone 715-654-5132 • FAX 715-654-5513
1-800-325-9103
www.meyermfg.com
E-mail: sales@meyermfg.com
Printed in U.S.A.
STARTING WITH 2006 MODEL YEAR
7400
7500
© Bobcat Company 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-FORCE 7400 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Meyer V-FORCE 7400 Series

Summary of Contents for Meyer V-FORCE 7400 Series

  • Page 1 US PATENT NO. 5,368,236 5,501,404 DO NOT OPERATE EQUIPMENT UNTIL THIS MANUAL HAS BEEN READ AND UNDERSTOOD. MANUFACTURED BY Meyer Mfg. Corp. 674 W. Business Cty Rd A P.O. Box 405 Dorchester, Wisconsin 54425-0405 Phone 715-654-5132 • FAX 715-654-5513 1-800-325-9103 www.meyermfg.com...

  • Page 2: Important Information

    Always use your serial number when requesting information or when ordering parts. HOW TO READ YOUR SERIAL NUMBER EXAMPLE: SV127500253 Model Type / Model Year / Model / Sequence Of Build 7500 Meyer Manufacturing Corporation 674 W. Business Cty Rd A Dorchester, WI 54425 Phone: 1-800-325-9103 Fax: 715-654-5513 Email: sales@meyermfg.com...

  • Page 3: Pre-Delivery & Delivery Check List

    Owner’s Registration Form. PRE-DELIVERY CHECK LIST DELIVERY CHECK LIST After the New Meyer Spreader has been completely The following check list is an important reminder of set-up, check to be certain it is in correct running order valuable information that MUST be passed on to the before delivering it to the customer.

  • Page 4: 3.0 Introduction

    There is no substitute for quality. That is why thousands of people like you have purchased Meyer farm equipment. They felt it was the best equipment to serve their farming needs, now and in years to come.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS 1.0 IMPORTANT INFORMATION ........... 2 PRE-DELIVERY &...
  • Page 6 MEYER EQUIPMENT WHEEL TORQUE ........

  • Page 7: Manufacturer's Warranty

    Except as stated above, Meyer Mfg. Corp. shall not be liable for injuries or damages of any kind or nature, direct, consequential, or contingent, to persons or property. This warranty does not extend to loss of crop or for any other reasons.
  • Page 8 Meyer Manufacturing Corporation 674 W. Business Cty Rd A Dorchester, WI 54425 Phone: 1-800-325-9103 Fax: 715-654-5513 Email: sales@meyermfg.com Website: www.meyermfg.com PB-74/7500 - 8 -...

  • Page 9: Safety Precautions

    Always install a SMV emblem on spreader for transporting on roadways and keep this emblem clean and bright. MEYER MFG. CORP. PROVIDES GUARDS FOR EXPOSED MOVING PARTS FOR THE OPERATOR’S PROTECTION; HOWEVER, SOME AREAS CANNOT BE GUARDED OR SHIELDED IN ORDER TO ASSURE PROPER OPERATION. THE OPERATOR’S MANUAL AND DECALS ON THE MACHINE ITSELF WARN YOU OF DANGERS AND MUST BE READ AND...

  • Page 10: Safety First

    SAFETY FIRST A brief definition of signal words that are used in this manual is as follows: DANGER indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury. WARNING indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious injury and includes hazards that are exposed when guards are removed.

  • Page 11: Safety Decals

    SAFETY DECALS The Meyer Super Spreader is manufactured with operator safety in mind. Located on the manure spreader are various decals to aid in operation and warn of danger or caution areas. Pay close attention to all decals on the spreader.
  • Page 12 SAFETY DECALS The Meyer Super Spreader is manufactured with operator safety in mind. Located on the manure spreader are various decals to aid in operation and warn of danger or caution areas. Pay close attention to all decals on the spreader.

  • Page 13: Pre-Operation

    FIGURE 1. DRAWBAR & PTO RELATIONSHIP square mount tube and move to the transport storage tube on the left front side of the frame channel. Store WITH INITIAL HOOK-UP TO YOUR NEW MEYER in a horizontal position. SPREADER TEST PTO TRAVEL BY TURNING...

  • Page 14: Transporting

    TRANSPORTING TRACTOR TOWING SIZE REQUIREMENTS Use the following chart for calculating the minimum HYDRAULIC tractor weight. HOSES MINIMUM SPREADER EMPTY MODEL TRACTOR WEIGHT HOSE WEIGHT + LOAD = GW UP TO 20 MPH BRACKET SV2636 6,100 + 2/3 of spreader gross weight SHAFT SV3245...

  • Page 15: Truck Mount Spreaders

    Depending on the make and model of the truck it may addition to traffic rules. You may also be required to be necessary to install a light converter (MEYER install a safety chain device on the spreader. PART #56-0028). Converter will allow signal lights and Check for traffic constantly.
  • Page 16 Clean all manure from rear ends of augers, flow control rear gate and spinners. WARNING: MAKE CERTAIN EVERYONE IS CLEAR OF EQUIPMENT BEFORE APPLYING POWER. FAILURE TO HEED MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH. Slowly engage the PTO. Operate the spreader several minutes to clean manure scrapings and to allow any remaining manure and the spreader to freeze dry.

  • Page 17: Operation

    OPERATION LOADING UNLOADING CAUTION: TO PREVENT DAMAGE TO WARNING: MAKE CERTAIN EVERYONE IS AUGERS, SPINNERS, DRIVE LINES, CLEAR OF SPREADER BEFORE APPLYING FOREIGN OBJECTS (STONES, CONCRETE, POWER. FAILURE TO HEED MAY RESULT IN TIMBER, METAL OR LARGE FROZEN CHUNKS OF SERIOUS PERSONAL INJURY OR DEATH.

  • Page 18: Shear Sprocket Instructions

    Prior to SV117400201) optimum, trouble-free performance it is The Meyer Spreader you have received has been necessary to operate at or near engine PTO equipped with a shear sprocket design on the main speed. auger drive sprockets. The augers are being driven by...

  • Page 19: Storage After Use

    Order replacement bolts and nuts from the chart below. Prior Serial Number SV117400402 SV127500243 and Later Part # Description 831-5020-1.75 1/2”-20 x 1-3/4” Allen Head Cap Bolt 884-5020 1/2”-20 Top Locknut Grade 8 831-5618-1.75 9/16”-18 x 1-3/4” Allen Head Cap Bolt 884-5618 9/16”-18 Top Locknut Grade 8 831-5618-1.75-SL...

  • Page 20: Pto Drive Line

    INACCURACY OF TORQUE SETTINGS COULD SERIOUS PERSONAL INJURY OR DEATH. OCCUR. The Meyer V-Force Spreader is equipped with a If removal of the M-17 hexagon bolt is necessary, use cutout type clutch on the implement half of the PTO the same M-17 6-point socket and loosen bolt 1/2 drive line.

  • Page 21: Pto Lubrication

    14” - 540 RPM 1 3/8-6 or 16” - 1000 RPM 1 3/8-21, or 20” - 1000 RPM 1 3/4- 20. WITH INITIAL HOOK- UP TO YOUR NEW MEYER SPREADER TEST PTO TRAVEL BY TURNING EQUIPMENT IN BOTH DIRECTIONS OBSERVING THE MINIMUM AND MAXIMUM TRAVEL DIMENSIONS AS SHOWN PER DRAWING ON FIGURE 7, PAGE 19.

  • Page 22: Lubrication For Optional Truck Mount Mechanical Drive System

    LUBRICATION FOR OPTIONAL TRUCK MOUNT MECHANICAL DRIVE SYSTEM WARNING: DISENGAGE PTO POWER SOURCE, REMOVE KEY, AND RELIEVE HYDRAULIC PRESSURE BEFORE CLEANING, ADJUSTING, LUBRICATING OR SERVICING THIS MACHINE. FAILURE TO HEED MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH. MONTHLY LUBRICATION DAILY LUBRICATION Keep the upper and lower gearboxes 1/2 full of 75W90 Synthetic oil, capacity approximately 30 oz.

  • Page 23: Adjustments

    ADJUSTMENTS WARNING: DISCONNECT PTO DRIVE SHAFT AND HYDRAULIC HOSES (RELIEVE HYDRAULIC PRESSURE) BEFORE CLEANING, ADJUSTING, LUBRICATING OR SERVICING THIS SPREADER. FAILURE TO HEED MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH. SPINNER MATERIAL GUIDES SHEAR ARM MATERIAL GUIDE ADJUSTMENT Regularly inspect and adjust two spinner material guides located at both the LR and RR of the spreader.

  • Page 24: Front Drive Roller Chains

    WARNING: DISCONNECT PTO DRIVE SHAFT AND HYDRAULIC HOSES (RELIEVE HYDRAULIC PRESSURE) BEFORE CLEANING, ADJUSTING, LUBRICATING OR SERVICING THIS SPREADER. FAILURE TO HEED MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH. FRONT DRIVE ROLLER CHAINS There are five roller chain drives located at the front of the spreader. Regularly check that all tensioning springs are in serviceable condition for automatic roller chain tightening.
  • Page 25 IDLER NYLON ROLLER RH AUGER SPROCKET SPRING LOADED The RH auger chain drive, figure 12, is automatically ADJUSTER tensioned by a spring loaded idler NYLON roller. The extension spring should extend 3/4” from its neutral 4” total length. Manual adjustment for the automatic tensioning idler, NYLON roller assembly is located at the right front lower corner of the spreader tank.

  • Page 26: Lubrication

    LUBRICATION WARNING: DISCONNECT PTO DRIVE SHAFT AND HYDRAULIC HOSES (RELIEVE HYDRAULIC PRESSURE) BEFORE CLEANING, ADJUSTING, LUBRICATING OR SERVICING THIS MACHINE. FAILURE TO HEED MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH. DAILY LUBRICATION (every 8-12 loads) Grease (4) tandem wing pivots. Effectively grease by jacking up the spreader to relieve pressure Grease (2) rear spinner lower bearings.
  • Page 27 MONTHLY LUBRICATION Keep the (3) gearboxes 1/2 full of liquid gear Clean and repack the wheel hubs with axle grease at all times, capacity approximately 30 oz. grease annually. Grease hub through zerk in hub Check regularly for any observable leakage. If leakage monthly.

  • Page 28: Lubrication & Adjustment For 3Rd Auger

    LUBRICATION & ADJUSTMENT FOR 3RD AUGER WARNING: DISCONNECT PTO DRIVE SHAFT AND HYDRAULIC HOSES (RELIEVE HYDRAULIC PRESSURE) BEFORE CLEANING, ADJUSTING, LUBRICATING OR SERVICING THIS MACHINE. FAILURE TO HEED MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH. COVER WEEKLY LUBRICATION (every 25-30 loads) purpose.

  • Page 29: Instructions For Automatic Chain Oiler

    INSTRUCTIONS FOR AUTOMATIC CHAIN OILER When replacing oiler brushes into brush holders, use WARNING: DISCONNECT DRIVE regular 1/2”-20 nuts. Tighten nut finger tight initially as SHAFT HYDRAULIC HOSES (RELIEVE some adjustment may be needed later. For best HYDRAULIC PRESSURE) BEFORE CLEANING, results, place brush holders over top of roller chains ADJUSTING, LUBRICATING OR SERVICING THIS and directly on top of sprockets.

  • Page 30: Repair Parts

    REPAIR PARTS FRONT SHIELD & SIDE SHAFT DRIVE PB-74/7500 - 30 -...
  • Page 31 FRONT SHIELD & SIDE SHAFT DRIVE KEY PART NO. DESCRIPTION 914-3801 1-3/8" Pillow Block Bearing 910-0013 80B18 Sprocket 1-3/8” Bore, 5/16” Keyway 935-0002 5/16 x 5/16 x 2-1/4” Hardened Key 923-3837 SV7500 Front Side Shaft 925-3882 Side Shaft Tightener Assy. Complete 46-3600-12 Operating Procedure Decal 46-3600-14...

  • Page 32: Auger Drive, Primary Reduction

    AUGER DRIVE, PRIMARY REDUCTION PB-74/7500 - 32 -...
  • Page 33 AUGER DRIVE, PRIMARY REDUCTION KEY PART NO. DESCRIPTION 933-3628 Copper Tube Grease Line 25” (includes zerk, fittings) 38-0013 Roll Pin, 5/16” x 1-3/4” 925-3883-1 First Reduction Tightener Assembly Arm Weldment (540, Optional 1000 RPM Kit) 925-5015-1 First Reduction Tightener Assembly Arm Weldment (1000 RPM) 925-5017 Pivot Mount Plate Assy.

  • Page 34: Auger Drive, Secondary Reduction

    AUGER DRIVE, SECONDARY REDUCTION KEY PART NO. DESCRIPTION 14-0031 Bearing, 4 Bolt, 2” Bore 38-0013 Roll Pin, 5/16” x 1-3/4” 910-0063 Welded Sprocket Assy, RH, 80A60 x 80A12 (540 RPM, 1000 RPM Kit) 910-0063-RPM Welded Sprocket Assy, RH, 80A80 x 80A12 (1000 RPM) 851-7510-3Z 3/4"-10x3”...
  • Page 35 This Page Intentionally Blank PB-74/7500 - 35 -...

  • Page 36: Rh Auger Drive, Final Reduction

    RH AUGER DRIVE, FINAL REDUCTION Install (#120-56) Roller Chain, Key #13 W/Connector Link Cotter Pins Facing Towards Front Of Spreader. Auger Drive Shear Sprockets (Key #3) are Standard on all 7500 Models; Op- tional on 7400 Models prior to SV117400201, Standard SV117400201 and Later.
  • Page 37 RH AUGER DRIVE, FINAL REDUCTION (CONT’D) Install (#120-56) Roller Chain, Key #13 W/Connector Link Cotter Pins Facing Towards Front Of Spreader. Auger Drive Shear Sprockets (Key #3) are Standard on all 7500 Models; Op- tional on 7400 Models prior to SV117400201, Standard SV117400201 and Later.

  • Page 38: Lh Auger Drive, Final Reduction

    LH AUGER DRIVE, FINAL REDUCTION Install (#120-72) Roller Chain, Key #21 W/Connector Link Cotter Pins Facing Towards Rear Of Spreader. Auger Drive Shear Sprockets (Key #25) are Standard on all 7500 Models; Optional on 7400 Models prior to SV117400201, and Standard SV117400201 and Later.
  • Page 39 KEY PART NO. DESCRIPTION 925-3880-1 Tightener Pivot Shaft Weldment (Welded to Front Plate) 910-0064 Welded Sprocket Assy, LH, 80A60 x 120A9 (540 RPM, 1000 RPM Kit) 910-0064-RPM Welded Sprocket Assy, LH, 80A80 x 120A9 (1000 RPM) 808-.75-1.25-14 Machine Bushing, 14GA 30-0014 1/8”...

  • Page 40: Box, Augers & Side Shaft

    BOX, AUGERS & SIDE SHAFT PB-74/7500 - 40 -...
  • Page 41 BOX, AUGERS & SIDE SHAFT KEY PART NO. DESCRIPTION 901-3903 Main Welded Body, 7500 901-3915 Main Welded Body, 7400 901-3801-82 Adj. Hitch Plate, 1” Pin 923-3837 SV7000 Front Side Shaft 14-0049 1-3/8” 2-Bolt Bearing 937-0002 Shaft Coupler 1-3/8” 923-3827 Rear Side Shaft 141” 924-5000-F SV74/7500 Front Side Shield 924-5000-R...

  • Page 42: 7400/7500 Unloading Gate & Material Guides

    7400/7500 UNLOADING GATE & MATERIAL GUIDES (7500 PRIOR TO 2011 MODEL YEAR) PB-74/7500 - 42 -...
  • Page 43 7400/7500 UNLOADING GATE & MATERIAL GUIDES (7500 PRIOR TO 2011 MODEL YEAR) KEY PART NO. DESCRIPTION 925-5005 Spinner Deflector Welded Assy. 901-3903-34 Spinner Mount Channel 949-3753 Poly Gate Slides 803-2520-1.25Z 1/4-20 x 1-1/4" Flat Socket Head Screw 815-2520-Z 1/4-20 Nylon Insert Lock Nut 901-3908 Back Gate Welded Assy.
  • Page 44 7400/7500 UNLOADING GATE & MATERIAL GUIDES (CONT’D (7500 PRIOR TO 2011 MODEL YEAR) PB-74/7500 - 44 -...
  • Page 45 7400/7500 UNLOADING GATE & MATERIAL GUIDES (CONT’D) (7500 PRIOR TO 2011 MODEL YEAR) KEY PART NO. DESCRIPTION 75-0413-1A 1-14 x 4” Grade 5 Machine Bolt (Prior to 08 serial #'s) 851-5013-3.5Z 1/2-13 x 3-1/2” Grade 5 Machine Bolt (Prior to 08 serial #'s) 851-3816-3Z 3/8-16 x 3”...

  • Page 46: 7500 Unloading Gate & Material Guides

    7500 UNLOADING GATE & MATERIAL GUIDES (2011 MODEL YEAR & LATER) PB-74/7500 - 46 -...
  • Page 47 7500 UNLOADING GATE & MATERIAL GUIDES (2011 MODEL YEAR & LATER) KEY PART NO. DESCRIPTION 955-0202-ASSY Cylinder w/Bracket and Pipe 955-0202 2-1/2 x 28Hydraulic Cylinder 955-0204 1/2”M x 3/8”F Straight Fitting 955-3605 3/8” 90 Degree Elbow 955-3841 7500 Center Gate Lift Pipe 29” 925-3754 Hydraulic Pipe Holder Weldment 955-0203...

  • Page 48: Spinners & Gearbox Shaft Drive

    SPINNERS & GEARBOX SHAFT DRIVE PB-74/7500 - 48 -...
  • Page 49 SPINNERS & GEARBOX SHAFT DRIVE KEY PART NO. DESCRIPTION 901-3753-10 Spinner Paddle, 2 Per Spinner 901-3753-19 8865/7000 LH Aggressive Spinner Paddle 19-0041 Gearbox, Left, Cast 851-5013-1.5Z 1/2-13 x 1-1/2” Grade 5 M.B. Mount Bolts 828-0050-Z 1/2” SAE Washer (2-per bolt) 806-0050-Z 1/2”...

  • Page 50: Spinner Gear Reducers

    SPINNER GEAR REDUCERS Use Fluid Gear Grease ONLY. DO NOT use Grease For Lubricant. Meyer #48-0055-Gal #48-0055-QT PART NO. DESCRIPTION 19-0022-1-PF Splined Pinion Output Shaft/Gear Assy 19-0018-2 Seal 19-0018-3 Bearing Cone 19-0016-3 Bearing Cup 19-0018-4 Retaining Ring 19-0022-2-PF Center Gearbox Cross Thru Shaft/Gear Assy...

  • Page 51: 19-0047 Upper Gearbox - Truck

    19-0047 UPPER GEARBOX - TRUCK USE 75W90 SYNTHETIC OIL ONLY. MEYER PART #48-0066. CAPACITY 30 OZ. KEY PART NO. DESCRIPTION 19-0047-1-PF Splined Pinion Output Shaft/Gear Assy. W/Groove 19-0018-2 Seal 19-0018-3 Bearing Cone 19-0016-3 Bearing Cup 19-0018-4 Retaining Ring 19-0041-1 LH Gearbox Casting (tapped holes) Cast...

  • Page 52: 19-0038-Syn 2:1 Ratio Gearbox

    #19-0038-SYN 2:1 RATIO GEARBOX LOWER GEARBOX - TRUCK USE 75W90 SYNTHETIC OIL ONLY. MEYER PART #48-0066. CAPACITY 30 OZ. KEY PART NO. DESCRIPTION 19-0034-4 Output Shaft/Gear Assembly 19-0018-2 Seal 19-0018-3 Bearing Cone 19-0016-3 Bearing Cup 19-0018-4 Retaining Ring 19-0034-3 Input Shaft/Gear Assembly...
  • Page 53 This Page Intentionally Blank PB-74/7500 - 53 -...

  • Page 54: Hubs, Axle & Tandem Axle Assembly

    HUBS, AXLE & TANDEM AXLE ASSEMBLY PB-74/7500 - 54 -...
  • Page 55 HUBS, AXLE & TANDEM AXLE ASSEMBLY KEY PART NO. 7500 PART NO. 7400 DESCRIPTION 75-0207 75-0205 Hub Assembly Complete 75-0207-2 75-0205-2 Seal 75-0207-3 75-0205-3 Bearing Cone 75-0207-4 75-0205-4 Bearing Cup 75-0202-4 75-0202-4 Bearing Cup 75-0202-3 75-0202-3 Bearing Cone 75-0205-7-H 75-0205-7-H Washer 75-0205-8 75-0205-8...

  • Page 56: Third Auger

    THIRD AUGER PB-74/7500 - 56 -...
  • Page 57 THIRD AUGER KEY PART NO DESCRIPTION 929-3601 Extension Spring 35-0008 1/2” x 1/2” x 2” Square Key 910-0050 80B26 Sprocket 2” Bore, 1/2” Keyway 14-0031 Bearing, 4-Bolt Flange, 2” B 925-3866 Chain Tightener Bracket Weldment 911-0033 #80-36 Roller Chain w/Connector 35-0026 3/8”...

  • Page 58: Oil-Kit

    OIL-KIT PB-74/7500 - 58 -...
  • Page 59 Plunger, Brass Adj End Cap 952-0001-1-32 1/8” Hex Head Pipe Plug 952-0001-1-18 Reservoir Two Quart Tank 952-0001-1-35 Tank, Cap Only 952-0001-1-19 Hydraulic Hose Assembly Meyer Mfg. 952-0001-1-20 Tubing 5/8” ID Clear Polybraid 952-0001-1-21 Tubing 5/32” Nylon (Feet) 952-0001-1-25 Brush Assembly No 5/32 Insert 813-5020-Z...

  • Page 60: V-Force Lighting

    V-FORCE LIGHTING PB-74/7500 - 60 -...
  • Page 61 V-FORCE LIGHTING KEY PART NO. DESCRIPTION 56-0030 Dual Light LH w/4-Plug 56-0030-TR Truck Mount Dual Light LH w/4-Plug 56-0031 Dual Light RH w/4-Plug 56-0031-TR Truck Mount Dual Light RH w/4-Plug 52-0032-LED-PKG Ag Light Harness W/Module LED Update 56-0004 #1232 4-Way Socket 4-Pin 56-0005 Coil Cable Assy.

  • Page 62: 918-0312 Pto Drive Shaft Assembly

    918-0312 PTO DRIVE SHAFT ASSEMBLY 540 RPM 1-3/8 - 6 SPLINE YOKE WWE2480 (80 DEGREE C.V.) (Prior to SN SV177400202) (SN SV177400271 Through SN SV177400292) PB-74/7500 - 62 -...
  • Page 63 918-0312 PTO DRIVE SHAFT ASSEMBLY 540 RPM 1-3/8 - 6 SPLINE YOKE WWE2480 (80 DEGREE C.V.) (Prior to SN SV177400202) (SN SV177400271 Through SN SV177400292) KEY PART NO. DESCRIPTION 918-0212-1-1 Yoke 1-3/8”-6 Splined Assembly 918-0208-1-2 Grease Zerk in item 3 918-0208-1-3 Double Yoke 918-0208-1-4...

  • Page 64: 918-0312 Pto Drive Shaft Assembly

    918-0312 PTO DRIVE SHAFT ASSEMBLY 540 RPM 1-3/8 - 6 SPLINE YOKE WWE2480 (80 DEGREE C.V.) (SN SV177400202 Through SN SV177400270) (SN SV177400293 & Later) PB-74/7500 - 64 -...
  • Page 65 918-0312 PTO DRIVE SHAFT ASSEMBLY 540 RPM 1-3/8 - 6 SPLINE YOKE WWE2480 (80 DEGREE C.V.) (SN SV177400202 Through SN SV177400270) (SN SV177400293 & Later) KEY PART NO. DESCRIPTION 918-0212-1-1 Yoke 1-3/8”-6 Splined Assembly 918-0208-1-2 Grease Zerk in item 3 918-0208-1-3 Double Yoke 918-0208-1-4...

  • Page 66: 540 Rpm 1-3/8 - 6 Spline Yoke

    540 RPM 1-3/8 - 6 SPLINE YOKE WWE2480 ( 80 DEGREE C.V.) (PRIOR TO SERIAL #SV087500201) KEY MEYER PART NO. DESCRIPTION 918-0308-2-2-1 Housing 918-0208-2-3-3 918-0208-2-3-4 Spring Pack 1900NM 918-0208-2-3-5 Washer 918-0208-2-3-6 Retaining Ring 918-0208-2-3-7 Sealing Ring 918-0208-2-3-1 Clamp Cone Assembly...

  • Page 67: 1000 Rpm Kit

    1000 RPM KIT SVS-RPM-KIT KEY PART NO. DESCRIPTION QTY. KEY PART NO. DESCRIPTION QTY. 19-0002-17 Vent Plug 925-3890-1 Chain Tightener Weldment Less Roller 29-0015 Tightener Spring 925-3891-1 Front Cover Plate Welded 33-0012 Retaining Ring 1-1/4” Assembly 33-0021 Retaining Ring 1-1/2” 925-3892-10 2-1/8”...

  • Page 68: 918-0209 Pto Drive Shaft Assembly

    918-0209 PTO DRIVE SHAFT ASSEMBLY 1000 RPM 1-3/8” 21 SPLINE (STANDARD) 918-0211 PTO DRIVE SHAFT 1000 RPM 1-3/4” 20 SPLINE (OPTIONAL) WWE2480 (80 DEGREE C.V.) PRIOR TO 08 SERIAL NUMBERS WITH 1000 RPM ADD-ON KIT NOTE: PTO IS 6" SHORTER THAN STANDARD 540 OR 1000 RPM PTO.
  • Page 69 1000 RPM 1-3/8” 21 SPLINE (STANDARD) 918-0211 PTO DRIVE SHAFT 1000 RPM 1-3/4” 20 SPLINE (OPTIONAL) WWE2480 (80 DEGREE C.V.) PRIOR TO 08 SERIAL NUMBERS WITH 1000 RPM ADD-ON KIT KEY MEYER PART NO. DESCRIPTION 918-0208-1-1 Yoke 1-3/8”-21 Splined Assembly-Standard 918-0210-1-1 Yoke 1-3/4”-20 Splined Assembly-Optional...

  • Page 70: 918-0209 Pto Drive Shaft Assembly

    918-0209 PTO DRIVE SHAFT ASSEMBLY 1000 RPM 1-3/8” 21 SPLINE (STANDARD) 918-0211 PTO DRIVE SHAFT 1000 RPM 1-3/4” 20 SPLINE (OPTIONAL) CUTOUT CLUTCH PRIOR TO 08 SERIAL NUMBERS WITH 1000 RPM ADD-ON KIT KEY MEYER PART NO. DESCRIPTION 918-0208-2-3-2 Housing 918-0208-2-3-3 918-0208-2-3-10...
  • Page 71 This Page Intentionally Blank PB-74/7500 - 71 -...

  • Page 72: 918-0309 Pto Drive Shaft Assembly

    918-0309 PTO DRIVE SHAFT ASSEMBLY 1000 RPM 1-3/8” 21 SPLINE S.P. (STANDARD) 918-0311 PTO DRIVE SHAFT ASSEMBLY 1000 RPM 1-3/4” 20 SPLINE (OPTIONAL) WWE2480 (80 DEGREE C.V.) SERIAL NUMBERS 08 AND LATER WITH 1000 RPM ADD-ON KIT NOTE: PTO IS 4” SHORTER (1-3/4 20) 6” SHORTER (1-3/8 21 THAN STANDARD 540 OR 1000 RPM PTO.
  • Page 73 1000 RPM 1-3/8” 21 SPLINE S.P. (STANDARD) 918-0311 PTO DRIVE SHAFT ASSEMBLY 1000 RPM 1-3/4” 20 SPLINE (OPTIONAL) WWE2480 (80 DEGREE C.V.) SERIAL NUMBERS 08 AND LATER WITH 1000 RPM ADD-ON KIT KEY MEYER PART NO. DESCRIPTION 918-0208-1-1 Yoke 1 3/8”-21 Splined Assembly-STANDARD 918-0210-1-1 Yoke 1 3/4”-20 Splined Assembly-Optional...

  • Page 74: 918-0309 Pto Drive Shaft Assembly

    918-0309 PTO DRIVE SHAFT ASSEMBLY 1000 RPM 1-3/8” 21 SPLINE S.P. (STANDARD) 918-0311 PTO DRIVE SHAFT ASSEMBLY 1000 RPM 1-3/4” 20 SPLINE (OPTIONAL) CUTOUT CLUTCH SERIAL NUMBERS 08 AND LATER WITH 1000 RPM ADD-ON KIT KEY MEYER PART NO. DESCRIPTION 918-0208-2-3-2 Housing 918-0208-2-3-3 918-0208-2-3-10...
  • Page 75 This Page Intentionally Blank PB-74/7500 - 75 -...

  • Page 76: 918-0308 Pto Drive Shaft Assembly

    918-0308 PTO DRIVE SHAFT ASSEMBLY 1-3/8” 21 SPLINE S.P. (FACTORY BUILT 1000 RPM, NOT KIT EQUIPPED) WWE2480 (80 DEGREE C.V.) 918-0310 PTO DRIVE SHAFT ASSEMBLY 1-3/4” 20 SPLINE S.P. (OPTIONAL) (FACTORY BUILT 1000 RPM, NOT KIT EQUIPPED) WWE2480 (80 DEGREE C.V.) PB-74/7500 - 76 -...
  • Page 77 WWE2480 (80 DEGREE C.V.) 918-0310 PTO DRIVE SHAFT ASSEMBLY 1-3/4” 20 SPLINE S.P. (OPTIONAL) (FACTORY BUILT 1000 RPM, NOT KIT EQUIPPED) WWE2480 (80 DEGREE C.V.) KEY MEYER PART NO. DESCRIPTION KEY MEYER PART NO. DESCRIPTION 918-0208-1-1 Yoke 1-3/8”-21 Splined 918-0208-2-9 Screw-In Item 15,16 &...

  • Page 78: 918-0150 Vertical Driveline, Truck Mount Mechanical Drive

    #918-0150 VERTICAL DRIVELINE, TRUCK MOUNT MECHANICAL DRIVE KEY PART NO. DESCRIPTION QTY. 918-0150-1-1 V-Max/Force Top Lemon Profile Tube 618-0001-2-2 Walt#019519 Inboard Yoke 2a Lemon Profile 918-0208-1-6 Walt#020617 Spring Pin 10 x 75 918-0208-2-1 Walt#312410 Cross & Bearing Kit 918-0240-1-1 Walt#319208 Clamp Yoke 2400 1-3/8” 6 SPLINE AGKF 918-0150-2-1 V-Max/Force Lower Lemon Profile Tube 618-0001-1-2...

  • Page 79: Optional Truck Gearbox Drive Package

    OPTIONAL TRUCK GEARBOX DRIVE PACKAGE #SV-GBD NOTE: If rotation is oppposite of expected, flip gearbox to have opposite end of shaft go into knuckle. KEY PART NO. DESCRIPTION QTY. 19-0047 Mech Trk Mnt Upper Gearbox V-Max/VForce, 1:1 w/Syn Oil 19-0038-SYN Gearbox 2:1 w/Syn Oil 49-0032 6”...

  • Page 80: Troubleshooting

    MEYER SUPER SPREADER TROUBLESHOOTING SYMPTOM PROBLEM SOLUTION AUGERS Augers shake or chatter Stiff roller chains - dry Lubricate roller chains Loose roller chains Tighten roller chains Worn sprockets/chains Replace sprockets/chains Dry auger trough Load auger trough w/manure Worn auger shaft bushings Replace auger shaft bushings Augers wobble/lift up &...
  • Page 81 MEYER SUPER SPREADER TROUBLESHOOTING SYMPTOM PROBLEM SOLUTION ROLLER CHAINS Excessive chain wear Lack of lubrication Lubricate/align/tighten Out of alignment/loose AND SPROCKET Roller chain breakage Loose roller chain Tighten roller chains Worn sprockets Replace sprockets Sprocket teeth tipped over Worn roller chain...

  • Page 82: Meyer Equipment Wheel Torque

    MEYER EQUIPMENT WHEEL TORQUE PRESS FORMED HEAVY DUTY BOLT/STUD SIZE SOCKET SIZE BOLT TYPE WHEEL CENTER WHEEL CENTER 15/16 100 ft lbs Bevel or 160 ft lbs 1-1/16 Flange Nut 1-1/8 Flange Nut 378 ft lbs 1-1/2 TIRE INFLATION TIRE SIZE 12.5L-15...

  • Page 83: Specifications

    FARM EQUIPMENT BUYERS TRUST THE NAME MEYER! Meyer Super Spreader SPECIFICATIONS V-FORCE 7400 V-FORCE 7400 V-FORCE 7500 V-FORCE 7500 TRAILER MODEL TRUCK MODEL TRAILER MODEL TRUCK MOUNT CAPACITY Bushels Heaped Gallons/Cu.Ft. (struck) 1,870 / 250 1,870 / 250 2433 / 324 2433 / 324 Cu.
  • Page 84 This Page Intentionally Blank PB-74/7500 - 84 -...
  • Page 85 NOTES...
  • Page 86 NOTES...

  • Page 87: Maintenance Record

    MODEL NO. ________________________________ SERIAL NO. _______________________________ DATE SERVICE PERFORMED DATE SERVICE PERFORMED Manufactured by: Meyer Mfg. Corp. 674 W. Business Cty Rd A Dorchester, WI 54425 Phone: 1-800-325-9103 Fax: 715-654-5513 Email: sales@meyermfg.com Website: www.meyermfg.com Farm Equipment Buyers Trust the Name Meyer!
  • Page 88 Meyer Manufacturing Corporation 674 W. Business Cty Rd A Dorchester, WI 54425 Phone: 1-800-325-9103 Fax: 715-654-5513 Email: sales@meyermfg.com Website: www.meyermfg.com...
