INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL
MDV SERIES
MDV
SPREADER SERIES
TM
00122-588-0 3
1-739 R1
NOVEMBER 2009

Advertisement

loading
Need help?

Need help?

Do you have a question about the MDV Series and is the answer not in the manual?

Questions and answers

Related Manuals for Meyer MDV Series

Summary of Contents for Meyer MDV Series

  • Page 1 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES SPREADER SERIES 00122-588-0 3 1-739 R1 NOVEMBER 2009...
  • Page 2 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL POLYHAWK PV SERIES INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL POLYHAWK PV SERIES INDEX SAFETY ALERT ........................3 INSTALLATION & ASSEMBLY INSTRUCTIONS ............... 4 - 8 CENTER HIGH MOUNT STOP LAMP ..................
  • Page 3 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES THE BEST SAFETY DEVICE IS A CAREFUL OPERATOR! SAFETY ALERT SYMBOL ATTENTION! THIS SYMBOL MEANS BECOME ALERT! YOUR SAFETY IS INVOLVED! PLEASE READ AND UNDERSTAND COMPLETELY BEFORE DOING! SAFE EQUIPMENT INSTALLERS and OPERATORS: TURN OFF ALL POwER BEFORE PERFORMINg ANY SERVICE OPERATIONS •...
  • Page 4 2. Attach or lower spinner assembly. The Meyer MDV Spreader can be mounted and stored Position the spreader in the truck bed, just short of as a single unit. The Meyer MDV Spreader will mount on mak- most 15,000 to 20,000 GVW and larger trucks.
  • Page 5 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES To install and remove spreader from truck, lift by us- ing the four (4) hold down supports on the sides of the spreader or fork lift pockets. wARNINg! wARNINg! ALwAYS USE SUFFICIENTLY RATED CHAIN...
  • Page 6 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES INSTALLATION AND ASSEMBLY INSTRUCTIONS OPTIONAL HOLD DOwN KIT 62562 * Photo for hold down reference only, not MDV installation. MDV cannot be installed in pick-up type vehicles. art Number Qty. Description 62602...
  • Page 7 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES INSTALLATION INSTRUCTIONS HYDRAULIC CONTROLS 7. Use hose manufacturers recommendations for wARNINg! fitting reusable hose ends. LEAKINg HIgH PRESSURE FLUIDS CAN INJECT 8. Hydraulic pumps must be mounted so shaft THEMSELVES UNDER THE SKIN OF PERSONS rotates in direction of arrow.
  • Page 8 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES INSTALLATION INSTRUCTIONS DUAL FLOw VALVE/STAND IMPORTANT: A pipe joint sealant compatible with hydraulic oil must be applied to all NPT fittings. Teflon Tape Sealant Is Not Recommended. Do not apply pipe joint sealant to ORB or JIC fittings.
  • Page 9 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES INSTALLATION INSTRUCTIONS CENTER HIgH MOUNT STOP LAMP (CHMSL) 2. When drilling holes, any bare metal should be wARNINg! coated with a rust preventative; use appropriate size grommets and seal hole with appropriate FEDERAL MOTOR VEHICLE SAFETY STAN- sealant.
  • Page 10 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES INSTALLATION INSTRUCTIONS ELECTRIC THROTTLE CONTROLS (FACTORY INSTALLED ACTUATORS) 9. It is recommended that a 12 volt battery with 40 wARNINg! ampere hour rating be installed for winter use. The battery hold downs furnished will accept any BEFORE BEgINNINg ANY INSTALLATION ON 2SM series battery.
  • Page 11 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES SPREADER OPERATION wireless Throttle Control Button Functions (Sequence of Operations) Stop Choke / Throttle Fast Start Conveyor Throttle Slow A. ON/Off System power activated (ready to start). Spreader engine not running. F. TO TURN ENGINE OFF (With or without conveyor Spreader conveyor is not engaged.
  • Page 12 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES Swenson Spreader wireless Controller The wireless controller is a compact unit with two parts. One part is the Base Unit (Receiver) and the other part is the Transmitter (Hand Held Controller). The Transmitter is used to send a corresponding signal to the Base Unit to act as a remote switching device.
  • Page 13 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES “LEARN” Button Programming “red” LED (“black” press button) Antenna (coiled) Male Connector Fig. 3: Base Unit layout (Figure shown without Base Unit Cover) Programming/Reprogramming the Transmitter and the Base Unit: Tools needed: A small “phillips” screwdriver and a small diameter pin (paper clip).
  • Page 14 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES Transmitter Battery Replacement The Transmitter uses a standard CR2032 lithium button cell battery. In normal use it will provide 1 to 2 years of operation. To replace the Transmitter battery, gently press and slide the battery cover off.

  • Page 15: Trouble Shooting

    INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES TROUBLE SHOOTING 1. To verify the Transmitter and Base Unit are working together: Once the base unit has power the “red” LED will come on when the Transmitter buttons are depressed (Cover of Base Unit will need to be removed to see “red”...
  • Page 16 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES SPREADER OPERATION - LOADINg This manual covers vehicles which have been recom- 3. Obtain the Gross Vehicle Weight Rating (GVWR), mended for carrying the hopper spreader. Please see Front Gross Axle Weight Rating (FGAWR), and your local dealer for proper vehicle applications.
  • Page 17 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES SPREADER OPERATION - SPREAD PATTERN GAS ENGINE DRIVE WARNING! A. Start engine and allow engine to warm-up to operating tempeture and engage the clutch. ALWAYS STAND AT A SAFE DISTANCE AWAY The amount of material spread, depends on FROM THE SPINNER WHILE OPERATING.
  • Page 18 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES SPREADER OPERATION - SPREAD PATTERN (Continued) 00122-588-0 3 NOVEMBER 2009 PAGE 18...
  • Page 19 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES SPREADER OPERATON - MAINTENANCE 4. If the spreader is equipped with a gasoline engine, wARNINg! it should be maintained per engine manufacturer's DO NOT ATTEMPT TO LIFT SPREADER BY THE instruction. (Instructions and parts book is CENTER LIFT OR CORNER LIFT HOOKS wITH enclosed.
  • Page 20 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 00122-588-0 3 NOVMBER 2009 PAGE 20...
  • Page 21 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 00122-588-0 3 NOVEMBER 2009 PAGE 21...
  • Page 22 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 15,31 30,32 00122-588-0 3 NOVEMBER 2009 PAGE 22...
  • Page 23 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION SEE CHART BELOW 64139 SKID, SHIPPING 8 FOOT 64140 SKID, SHIPPING 9 FOOT 64141 SKID,SHIPPING 10 FOOT 62657 BOLT, 3/8-16 X 4” CA SS 63558 BOLT, 3/8-16 X 1” HH Zp 62697 BOLT, 3/8-16 X 1”...
  • Page 24 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 13,39,67 1,30,31 3 38 39 31 57 63 21 28 31 42 00122-588- 03 NOVEMBER 2009 PAGE 24...
  • Page 25 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 64142 WELD, ENGINE PLATE, Est 12g CS 64143 WELD, ENGINE PLATE, Est 12g SS 62298 WELD, INVERTED “V” 8 ft. CS 62296 WELD, INVERTED “V” 9 ft. CS 62294 WELD, INVERTED “V”...
  • Page 26 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 58,59,60,76 48,95,96 72,109 72,109 00122-588- 03 NOVEMBER 2009 PAGE 26...
  • Page 27 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 62007 DECAL, CAUTION 62009 DECAL, DANGER, CONVEYOR 63571 DECAL, SERIAL 64066 ENGINE, 10.5 HP B&S 63171 ENGINE, 11 Hp HONDA W/ DECALS 61206 ROD, BATTERY 62767 HOLD DOWN, BATTERY...
  • Page 28 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 21,31,32 28,46,47 11,32 9,28,111 68,70,72 28,66 00122-588- 03 NOVEMBER 2009 PAGE 28...
  • Page 29 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 62270 BAR, PIVOT 7g Cs 63817 BAR, PIVOT 7g S2 63294 FORM, FEED GATE HANDLE, 7g Cs 63828 FROM, FEED GATE HANDLE, 7g S2 62615 BOLT, 3/8-16 X 1-1/4” Ca G5 Zp 62813 BOLT, 3/8-16 X 1-1/4”...
  • Page 30 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 31,57,63 21,28,31,42 00122-588- 03 NOVEMBER 2009 PAGE 30...
  • Page 31 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 20066 BOLT, 3/8-16 x 1 1/4” Hh 62695 BOLT, 3/8-16 X 1 1/4” Hh SS 64160 GUARD, CHAIN, POLY 20353 FLAT WASHER 3/8” U.S.S. Zp 22230 FLAT WASHER 3/8’ U.S.S. SS...
  • Page 32 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 90 92 89 91 92 12 23 64 DETAIL GROUND WIRE ASSEMBLY, BRIGGS & STRATTON 88 85 DETAIL GROUND WIRE ASSEMBLY, hONDA 00122-588- 03 NOVEMBER 2009 PAGE 32...
  • Page 33 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 62187 NUT, 1/4-20 SER FLANGE CS 62690 NUT, 1/4-20 SER FLANGE SS 63188 CHAIN ROLLER #40-55 PITCHES 64 + 61179 SOLENOID, GROUNDED 76 / 114 63304 NUT, 5/16-18 SER FLANGE Zp...
  • Page 34 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 99,76 28,102 49,50 14,78 99,114 28,102 49,50 HONDA 00122-588- 03 NOVEMBER 2009 PAGE 34...
  • Page 35 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 14 ** 20326 LOCK WASHER, 5/16 MED SPLIT Zp 63309 LOCK WASHER 5/16 MED SPLIT SS 20353 FLAT WASHER 3/8” U.S.S. Zp 22230 FLAT WASHER 3/8” U.S.S. SS 61196 KEY, 1/4”...
  • Page 36 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 69,70,71 100,101,104,110 PAGE 36 00122-588- 03 NOVEMBER 2009...
  • Page 37 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 64170 WELD, MDV B&S SHROUD, CS 64171 WELD, MDV B&S SHROUD, S2 64172 WELD, MDV HONDA SHROUD, CS 64173 WELD, MDV HONDA SHROUD, S2 64092 RIVET, 1/8 X 3/8” BLIND...
  • Page 38 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 54,55 00122-588- 03 NOVEMBER 2009 PAGE 38...
  • Page 39 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 63177 SUB-ASSEMBLY, GEARBOX 61201 KEY, 1/4” SQ. 7/8” WOODRUFF 61167 CLUTCH, ELECTRIC 61161 PULLEY, DRIVEN, 20362 LOCK WASHER, 5/16” Zp 62634 SCREW, 5/16” X 5/8” Sh CAP...
  • Page 40 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 21,22,28 21,31 00122-588- 03 NOVEMBER 2009 PAGE 40...
  • Page 41 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 64175 FORM, REAR PLATE Cs 64074 FORM, REAR PLATE S2 62684 BLOCK, SPACER 64083 SUB ASSEMBLY , SPINNER DRIVE SHAFT 1 20066 BOLT, 3/8-16 X 1-1/4” Hh G5 Zp 62695 BOLT, 3/8-16 X 1-1/4”...
  • Page 42 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 2,39,67 44,45 21,31 00122-588- 03 NOVEMBER 2009 PAGE 42...
  • Page 43 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 64176 FORM, CHAIN SHIELD, 8 ft. CS 64177 FORM, CHAIN SHIELD, 9 ft. CS 64178 FORM, CHAIN SHIELD, 10 ft. CS 64179 FORM, CHAIN SHIELD, 8 ft. S2 64188 FORM, CHAIN SHIELD, 9 ft.
  • Page 44 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 00122-588- 03 NOVEMBER 2009 PAGE 44...
  • Page 45 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 63177 SUB-ASSEMBLY, GEARBOX ITEM PART NUMBER GEARBOX PART DESCRIPTION 63123 SET SCREW, 3/8-16 X 3/8” AH 62000 KEY, STRAIGHT, 1/4” SQ. 61163 BEARING, 1-1/4” 63129 PLUG, 1/4’ NPT (Co 4) 61201 KEY, 1/4”...
  • Page 46 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 1,2,3 00122-588- 03 NOVEMBER 2009 PAGE 46...
  • Page 47 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 63409 FLAT WASHER, 3/8” SS 63206 LOCK WASHER, 3/8” SS 62695 BOLT, 3/8-16 X 1-1/4” SS 62006 DECAL, DANGER SPINNER 62007 DECAL, CAUTION 62313 BAR, LINK, S3...
  • Page 48 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 8,11 1,5,12 00122-588- 03 NOVEMBER 2009 PAGE 48...
  • Page 49 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 63409 FLAT WASHER, 3/8” SS 62684 SPACER, UHMW 62691 PIN, 1/8” X 1” COTTER SS 63193 KEEPER, HAIRPIN LG SS 63091 KEEPER, HAIRPIN SM SS 63145 ROD, SPINNER MOUNT...
  • Page 50 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 00122-588- 03 NOVEMBER 2009 PAGE 50...
  • Page 51 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 63768 SHAFT, SPINNER DRIVE 62198 BOLT, 3/8-16 X 2-1/2” Hh SS 63199 LOCK NUT 3/8-16 TOP LOCK SS 63143 FLAT WASHER, RUBBER 63200 PIN, 3/8” X 2-1/4” ROLL 62356 BEARING, 1”...
  • Page 52 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 00122-588- 03 NOVEMBER 2009 PAGE 52...
  • Page 53 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 62696 LOCK NUT 3/8-16 Nl SS 20068 BOLT, 3/8-16 2-1/2” Hh Zp 62356 BEARING, 1” TAPPED BASE 62988 FITTING, ZERK, 90 deg. 61196 KEY, STRAIGHT, 1/4” SQ.
  • Page 54 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 105,106 89,91,92 90,92 00122-588- 03 NOVEMBER 2009 PAGE 54...
  • Page 55 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 14 + 64984 HARNESS, B&S W/ CAPACITOR 64 + 64167 SOLENOID, GROUNDED 83 + 62648 LINKAGE, THROTTLE, B&S 84 + 62645 BRACKET, ACTUATOR, B&S 85 + 62646 SCREW, 10-32 X 5/16”...
  • Page 56 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 77,105,106 76,117 12,25,64 89,91,92 00122-588- 03 NOVEMBER 2009 PAGE 56...
  • Page 57 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 12 ** 62799 BOLT, M5 X 12 Hh SS 25 ** 62800 LOCK WASHER, #10 MED. SPLIT, SS 64 ** 62801 FLAT WASHER, #10, SS 76 **...
  • Page 58 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 14,24 00122-588-01 Revision B OCTOBER 2009 PAGE 58...
  • Page 59 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION SEE CHART BELOW 64139 SKID, SHIPPING 8 FOOT 64140 SKID, SHIPPING 9 FOOT 64141 SKID,SHIPPING 10 FOOT 62657 BOLT, 3/8-16” X 4” CA SS 62611 NUT, 3/8-16 SER. FLANGE Zp 23 62743 NUT, 3/8-16 SER.
  • Page 60 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 3,30,31 18,22,24,35 2,21,57 1,22,24 13,31,57 17 18 24 18 ,24 00122-588-01 Revision B OCTOBER 2009 PAGE 60...
  • Page 61 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 64186 WELD, MOTOR PLATE, HYD CS 64187 WELD, MOTOR PLATE, HYD, S2 64176 FORM, CHAIN SHIELD, 8 ft CS 64177 FORM, CHAIN SHIELD, 9 ft. CS 64178 FORM, CHAIN SHIELD, 10 ft.
  • Page 62 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 22,39,40 9,66 18,24,25 11,25 22,56 12,21,48 59,65 58 64 00122-588-01 Revision B OCTOBER 2009 PAGE 62...
  • Page 63 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 63294 FORM, HANDLE, FEED GATE, 7 g CS 63828 FORM, HANDLE, FEED GATE, 7 g S2 62615 BOLT, 3/8-16 X 1-1/4” CA G5 Zp 62813 BOLT, 3/8-16 X 1-1/4” CA G5 SS 62187 NUT, 1/4-20 SER.
  • Page 64 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 41,42,50 19,22,23 52,53 44,49 24,51 00122-588-01 Revision B OCTOBER 2009 PAGE 64...
  • Page 65 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 20327 LOCK WASHER, 3/8” MED SPLIT Zp 4 63206 LOCK WASHER, 3/8” MED SPLIT SS 20353 FLAT WASHER, 3/8” U.S.S. Zp 22230 FLAT WASHER 3/8” U.S.S. SS 63558 BOLT, 3/8-16 X 1”...
  • Page 66 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 37, 38 00122-588-01 Revision B OCTOBER 2009 PAGE 66...
  • Page 67 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 63733 WELD, DRAG CHAIN, MDV 8 ft. 63734 WELD, DRAG CHAIN, MDV 9 ft. 63735 WELD, DRAG CHAIN, MDV 10 ft. 61174 PIN, CONNECTOR W/ COTTER 63177...
  • Page 68 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 3,12 18,19,20 23,24,25 00122-588-01 Revision B OCTOBER 2009 PAGE 68...
  • Page 69 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 64193 ROD, SPINNER, MTG S3 63214 WELD, LH SPINNER BAFFLE, CS 63910 WELD, LH SPINNER BAFFLE, S2 63215 WELD, RH SPINNER BAFFLE, CS 63911 WELD, RH SPINNER BAFFLE, S2 62697 BOLT, 3/8-16 X 3/4”...
  • Page 70 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 10,11,16 00122-588-01 Revision B OCTOBER 2009 PAGE 70...
  • Page 71 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES ITEM PART NUMBER PRODUCT DESCRIPTION 62313 BAR, LINK S3 63211 WELD, INTERNAL BAFFLE, CS 64180 WELD, INTERNAL BAFFLE, S2 63216 WELD, REAR SPINNER BAFFLE, CS 1 63912 WELD, REAR SPINNER BAFFLE, S2 1...
  • Page 72 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 00122-588-01 Revision B OCTOBER 2009 PAGE 72...
  • Page 73 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES PARTS LIST FOR DUAL HYDRAULIC FLOw CONTROL VALVE (62213) Item Part Number Description 62014 Detent Repair Kit (Consists of 1, 2, 3, 4 & 5) 62099 Kit, Seal for item #9 & 10 (Consists of 6, 7 &...
  • Page 74 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL MDV SERIES 00122-588-01 Revision B OCTOBER 2009 PAGE 74...
  • Page 75 SPREADER ONE YEAR WARRANTY Meyer Products (“Meyer”) warrants to the original purchaser only that it will repair, or, at the sole option of Meyer, replace any part of the new Meyer covered product which proves to be defective in workmanship or material under normal use for a period of one year from the date of delivery to the original purchaser.
  • Page 76 INSTALLATION, OPERATING INSTRUCTION AND PARTS MANUAL SEL INSTALLATION AND OPERATING INSTRUCTION MANUAL MDV SERIES MEYER PRODUCTS, LLC 18513 EUCLID AVE. CLEVELAND, OHIO 44112-1084 PHONE: (216) 486-1313 FAX: (216) 486-9775 email:warranty@meyerproducts.com website: www.meyerproducts.com IMPORTANT INFORMATION ENCLOSED 00122-588-01 Revision B OCTOBER 2009...
