- Page 1 HTD8FFi 580 Line Color Dome Camera Intensifier 2 Series, Focus Free Wall & Ceiling Mountable Please read this manual thoroughly before operation and keep it handy for further reference.
- Page 2 WARNING & CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK D O N O T R E M O V E C O V E R ( O R B A C K ) . N O U S E R S E R V I C E A B L E P A R T S I N S I D E R E F E R S E R V I C I N G T O...
-
Page 3: Table Of Contents
CONTENTS Package Contents Precautions Camera Installation 6-10 Features 11-12 OSD Menu Tree OSD Menu Details 14-17 Troubleshooting 18-19 Specifications Dimensions Warranty... -
Page 4: Package Contents
PACKAGE CONTENTS Please make sure that the following items are included in the package: 1 HTD8FFi Series Camera 4 Mounting Screws 1 Video test Connector 1 Rubber Cap 1 Wrench Please leave this manual with the end-user for future reference. -
Page 5: Precautions
PRECAUTIONS • THIS CAMERA SHOULD BE ONLY INSTALLED BY QUALIFIED PERSONNEL • TO PREVENT A FIRE OR ELECTRICAL HAZARD PLEASE USE PROPER POWER CABLE • DO NOT CELAN THE DOME COVER WITH AN ABRAISIVE CLEANING MATERIAL - PLEASE USE A SOFT CLOTH OR TISSUE TO CLEAN THE DOME COVER •... -
Page 6: Camera Installation
CAMERA INSTALLATION CONNECT POWER CABLE 1. WHEN USING 12 VOLTS DC (constant voltage 500 mA) Power Input :RED Center : (+) DC 12V Power Supply 2. WHEN USING 24 VOLTS AC (40 Volt Amps) RED(+) AC 24V BLACK:(-) Power Supply 3. - Page 7 CAMERA INSTALLATION ASSEMBLY Easy Mount Plate Rubber Cap used when cables go through the mount SET Screws (2ea) Camera Base Mounting Screws (4ea) Camera Body OSD Joystick & Video Test Connector built-in Front Case SET Screws (4ea) Outer Housing...
- Page 8 CAMERA INSTALLATION COMPATIBILITY 7246WMT CVCTPEXT “A” type Box “B” type Box Hole 1 : 7246WMT : CVCTPEXT Hole 2 : Electrical Box “A” type Hole 3 : Electrical Box “B” type...
- Page 9 CAMERA INSTALLATION CONTROL BOARD DETAILS Zoom In & Out Joystick Heater Heater Video Test Connector OSD button (Up, Down, Left, Right, Setup) Press each button (Up, down, left & right , Setup) to control the OSD functions.
- Page 10 CAMERA INSTALLATION DIP Switch Setting for RS-485 (Pelco-D) Address Baud Rate 1) Address Setting to set Camera Address, place switches based on below chart. 2) Baud rate Setting to set Baud rate, please refer the chart below.
-
Page 11: Features
1/3 inch density CCD and digital processor permit high quality Pictures to be captured in very low light condition. SPECO DNR The Intensifier camera has a DSP chip that can remove image noise efficiently showing clean images in low light conditions. - Page 12 FEATURES All camera functions are menu driven for easy use. When the image is in front of strong background lighting, your camera allows you to get the clear image. HLC (High Light Compensation) This function reverses bright spots in the picture (such as headlights).
-
Page 13: Osd Menu Tree
ADJUST LENS DC IRIS INTENSIFIER E SHUTTER AUTO GAIN INTENSIFY RETURN COLOR TEMP INDOOR OUTDOOR AWC SET MANUAL WDR SET SPECO DNR DAY & NIGHT COLOR AUTO TWEAK VIDEO STILL PIX V-REVERSE H-REVERSE RETURN DIGI-ZOOM CLARITY PAGE 2 V MOTION... -
Page 14: Osd Menu Details
OSD MENU DETAILS 1. INTENSIFIER [OPTION : E SHUTTER / AUTO GAIN / INTENSIFY / RETURN] - E SHUTTER * FLK - Flicker-less mode (FLK) reduces on-screen flickering. * ESC - Electronic Shutter Control (AUTO) adjusts brightness level on screen. - AUTO GAIN Adjusts value of AGC gain and increases the GAIN level to brighten the picture. - Page 15 OSD MENU DETAILS 3. WDR SET [OPTION : SLC / HLC / OFF] - SLC (Speco Light Compensation) Provides light level control to overcome severe back light condition. - HLC (High Light Compensation) High Light Compensation removes the high light and makes possible to view the image clearly.
- Page 16 OSD MENU DETAILS 7. CAM TITLE [OPTION : ON / OFF] - Display a name and/or number on the monitor you prefer. 8. SYNC TYPE [OPTION : INT / LL] - INTERNAL : When line lock is not required. - LINELOCK : Adjust the vertical phase (VPH) from 000~ 359 (factory default is 0).
- Page 17 OSD MENU DETAILS 10. PRIVACY [OPTION : ON / OFF] - Mask up to 8 areas of the screen from video monitoring. - AREA SEL : Select up to 8 motion detection area. - AREA mode : Activate or deactivate the selected area. - MASK COLOR : Select area color.
-
Page 18: Troubleshooting
TROUBLESHOOTING If you have trouble operating your camera, refer to the following Problem Solution Nothing appears on ● Check that the power cord and line connection the screen. between the camera and monitor are proper ● Check that you have properly connected VIDEO cable the camera VIDEO output jack. - Page 19 TROUBLESHOOTING Problem Solution The color of the ● Check that you have properly set the picture is not ‘ WHITE BALANCE ’ menu matched. The image on the ● Is the camera facing to direct sunlight or fluorescent screen flickers. lighting? Change the camera position.
-
Page 20: Specifications
SPECIFICATIONS ITEM HTD8FFi Power Source 12VDC & 24VAC ( Dual Voltage ) Power Consumption 500mA (DC) / 6.6W (AC) Image Sensor 1/3”, SONY SUPER HAD CCD, 410,000 pixels Total Pixels 811(H) x 508(V) , 1/3” CCD Effective Pixels 768(H) x 494(V) , 1/3” CCD Focus Free Lens 2.8~10mm... -
Page 21: Dimensions
DIMENSIONS * FRONT VIEW * SIDE VIEW... -
Page 22: Warranty
WARRANTY... - Page 23 NOTES...
- Page 24 200 New Highway Amityville, NY 11701 631-957-8700 www.specotech.com VER. 090629 This manual is based on the date as shown in the right and specifications are subject to Change without notice for quality improvement.
