Speco HTD8SCS Series User Manual

540 line color dome camera wall & ceiling mountable

Advertisement

Quick Links

HTD8SCS Series
540 Line Color Dome Camera
Wall & Ceiling Mountable
Please read this manual thoroughly before operation and keep
it handy for further reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTD8SCS Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Speco HTD8SCS Series

  • Page 1 HTD8SCS Series 540 Line Color Dome Camera Wall & Ceiling Mountable Please read this manual thoroughly before operation and keep it handy for further reference.
  • Page 2: Warning And Caution

    WARNING & CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK D O N O T R E M O V E C O V E R ( O R B A C K ) . N O U S E R S E R V I C E A B L E P A R T S I N S I D E R E F E R S E R V I C I N G T O Q U A L I F I E D S E R V I C E P E R S O N N E L .
  • Page 3: Table Of Contents

    Contents Package Contents Precautions Camera Installation Internal Components Features...
  • Page 4 Operating Your Camera SET UP SET UP LENS SHUTTER SPEED CONTROL SHUTTER SPEED CONTROL BACK LIGHT AUTO GAIN (AGC) WHITE BALANCE CAMERA TITLE MIRROR DAY/NIGHT/SYNC MOTION DETECTION PRIVACY GAMMA RESET ADJUST EXIT Specifications Dimensions Warranty...
  • Page 5: Package Contents

    PACKAGE CONTENTS • Please make sure that the following items are included in the package: 1 CAMERA & Easy Mount Plate ACCESSORIES: 4 MOUNTING SCREWS 4 SET SCREWS 1 RUBBER CABLE CAP 1 VIDEO TEST LEAD 1 WRENCH Please leave this manual with the end-user for future reference.
  • Page 6: Precautions

    PRECAUTIONS • THIS DOME CAMERA SHOULD BE ONLY INSTALLED BY QUALIFIED PERSONNEL • TO PREVENT A FIRE OR ELECTRICAL HAZARD PLEASE USE PROPER POWER CABLE • PLEASE USE AN APPROVED REGULATED 12 VOLT DC POWER SUPPLY LIKE THE SPECO PSW-5 •...
  • Page 7: Camera Installation

    CAMERA INSTALLATION 1. Assembly Easy Mount Plate Rubber Cap used when cables Rubber Cap used when cables go through the mount Mounting Screws (4ea) SET Screws (2ea) Camera Base Camera Body OSD Joystick & Video Test Connector Focus & Zoom Controller Front Case SET Screws (2ea) Outer Housing...
  • Page 8 CAMERA INSTALLATION 2. Compatibility 7246WMT CVC-TPEXT “A” type Box “B” type Box BCP(Using 7246WMT) [CVCTPLATE Hole Description] Hole 1 : 7246WMT / CVCTPEXT Hole 2 : Electrical Box “A” type Hole 3 : Electrical Box “B” type...
  • Page 9: Internal Components

    INTERNAL COMPONENTS Video Test Terminal LEFT LEFT DOWN Push the Joy stick for one second, and the OSD appears Push the Joy stick for one second, and the OSD appears on the screen. Move the Joy Stick up, down, left & right to control the OSD functions.
  • Page 10: Features

    Features When the image is in front of strong background lighting, your camera allows you to get a clear image. High Resolution High Resolution Horizontal resolution of 540 TV lines is achieved by using a SONY Double Speed CCD with 410,000 pixels, yielding pictures with a high S/N ratio.
  • Page 11: Osd

    Operating your camera OSD Function LENS MANUAL SHUTTER AUTO FIXED WHITE BAL. FIXED FUNCTION RETURN CAMERA ID MIRROR DAY / NIGHT COLOR AUTO MOTION DET PRIVACY GAMMA 0.05~1.00 USER LANGUAGE ENGLISH 한국어 汉语 RESET ADJUST CONTRAST SHARPNESS CB_GAIN CR_GAIN RETURN RETURN MANUAL MANUAL...
  • Page 12: Set Up

    Operating your camera – SETUP 1) LENS <DC / MANUAL> Selects Lens Type. 2) SHUTTER <AUTO / FLK / FIXED / MANUAL > Adjusts shutter settings. Flicker-less mode (FLK) reduces on-screen flickering. Electronic Shutter Control (AUTO) adjusts brightness level on screen. Manual mode allows you to adjust the shutter speed from1/60~1/120,000 of a second (NTSC), or 1/50~1/100,000(PAL).
  • Page 13: White Balance

    5) WHITE BAL. 5) WHITE BAL <ATC / AWB / FIXED / MANUAL> Controls color on the screen. Select Auto Tracking White Balance (ATW) when the color temp. is 2400°K~12000°K (for example when under a fluorescent light or outdoors). Manual mode allows you to increase or decrease the red or blue factor on screen.
  • Page 14: Mirror

    (6-3) MIRROR <ON / OFF> Produce a horizontal mirror image on screen. (6-4) DAY / NIGHT <AUTO / COLOR / BW> AUTO = Automatically switches between color or black/white. Delay – When the Day & Night function starts or stops (0~15sec) Start Level –...
  • Page 15: Gamma

    AREA SEL = Select a motion detection grid (top left, top ,right, bottom left, bottom right) to modify. AREA STATE = Activate or deactivate the selected grid. LEFT/RIGHT/TOP/BOTTOM = Alter the dimensions of the selected grid. COLOR = Select color of privacy area. (6-7) GAMMA <ON / USER>...
  • Page 16: Specifications

    SPECIFICATIONS ITEM 540TV Lines IR DOME CAMERA Power Requirements 12 Volts DC Image Sensor 1/3”, SONY SUPER HAD CCD 410,000 pixels Effective Pixels 768(H) x 494(V) (NTSC) Maximum Aperture Ratio 1 : 1.3 ~2.0 Scanning System 2 : 1 Interlaced 525 Lines / 60 Fields / 30 Frames Video Output 1.0V [p-p] NTSC Composite, 75Ω...
  • Page 17: Dimensions

    DIMENSIONS * FRONT VIEW * SIDE VIEW...
  • Page 18: Warranty

    WARRANTY...
  • Page 19 MEMO...
  • Page 20 200 New Highway Amityville, NY 11701 631-957-8700 www.specotech.com Rev. 100125 Speco Technologies is constantly developing product improvements. We reserve the right to modify product design and specifications without notice and without incurring any obligation.
