5

External components

Hopper
4 4
shutter
Position
indicator &
7 7
safety block
Ground
10 10
coffee dispenser
Dispenser
11 11
handle
On-Off
14 14
Switch
1 Hopper lid Hopper lid
6.1. General warnings
The installer should read this instruction manual carefully before
Coffee bean Coffee bean
installing the machine. The machine must be installed by qualifi ed,
2
hopper hopper
authorized staff, respecting the applicable safety and hygiene
guidelines.
Hand protector Hand protector
3
Setting roller Setting roller
5
6.2. Important warnings
6 The operator must be a responsible adult and under no cir-
Grind regulator Grind regulator
cumstances a minor or a person unable to deal with said respon-
sibility.
Dispenser lid Dispenser lid
8 When handling the grinder, the following precautions must be
taken into consideration:
Dispenser Dispenser
9
• Do not handle with bare feet
regulator regulator
• Hands or feet must not be wet
• Do not submerge the machine in water
• Do not expose the machine to sunlight or other atmospheric
Tamper Tamper
12
conditions
• Never insert any object into the coffee input or output
openings when the machine is turned on. (Please bear in mind
13 Support crutch Support crutch
that when the grinder stops, the burrs continue to turn for a
few seconds.)
• To disconnect the grinder, always pull out the plug and never
Coffee Coffee
15
the electrical cable, to avoid the possibility of a short circuit.
collection tray collection tray
6

Installation

i
!
