2.4.3

Stand for transmitted light polarization

Key to Fig. 2-2:
1 Basic stand
2 Stage carrier for rotary stages (also suitable for mechanical stages)
3 Light intensity control
4 Focusing drive – fine adjustment (right side, finger wheel)
5 Focusing drive – coarse adjustment (right side)
6 Drive knob for vertical adjustment of condenser (right side)
7 Centering screw for condenser (right side)
8 Luminous-field diaphragm
9 Locking screw for rotary table (arrests rotation)
10 Condenser with aperture diaphragm (optional with modulator disk)
11 Rotary stage lock in stage carrier
12 Rotary stage Pol with specimen guide
13 Nosepiece 4x H Pol (3 eyes centering, 1 eye fixed)
14 Slot for 6x20 slider
15 Eyepieces
16 Binocular section of tube
17 Binocular tube/photo tube
18 Carrying handle
19 Centering screw for condenser (left side)
20 Drive knob for vertical adjustment of condenser (left side)
21 Focusing drive – coarse adjustment (left side)
22 Focusing drive – fine adjustment (left side)
23 ON/OFF switch
24 Tool flap/cable holder
25 Transmitted light lamp in stand base
28
DESCRIPTION OF THE INSTRUMENT
Control and functional elements on microscope
